Installation and
Operation Manual
POWER
EJECT
DIM
ELAPSE
LOUD
AS/PS
PULL OPEN
4 X 50W
MARINE CD RECEIVER
SHIFT
MODE
SCAN
U
PGM
EQ
SHIFT
CH
TRK
TRK
BAND
DISP
SEL
MUTE
TUNE
TUNE
MONO
1
2
3
4
5
MEM
PGM
RPT
RDM
INT
M5100CD
Waterproof
AM/FM/WB and CD Stereo Receiver
A Registered Trademark of Magnadyne Corporation
US Patent Number D 500,303 S
Advertisement
Table of Contents
Related Manuals for Magnadyne M5100CD
Summary of Contents for Magnadyne M5100CD
-
Page 1: Operation Manual
ELAPSE LOUD AS/PS PULL OPEN 4 X 50W MARINE CD RECEIVER SHIFT MODE SCAN SHIFT BAND DISP MUTE TUNE TUNE MONO M5100CD Waterproof AM/FM/WB and CD Stereo Receiver A Registered Trademark of Magnadyne Corporation US Patent Number D 500,303 S... - Page 2 2/1/05 4:58 PM Introduction Your new M5100CD entertainment system has been designed to give you many years of listening pleasure. Take a moment to read through this manual and become familiar with the operations and features of this outstanding product.
- Page 3 M5100CDUMFinal 2/1/05 4:58 PM Location and Function of Controls at a Glance 8. Multi-Function Button 3/RPT: Radio: Recalls a memorized radio station, and programs a radio station into memory (See Radio Operation for more information). Continuously repeats the same track (See CD Operation for more information). 9.
-
Page 4: Radio Operation
M5100CDUMFinal 2/1/05 4:58 PM Radio Operation Listening to the Radio 1. Push the “POWER” button (1) once to turn the unit on. 2. Press the “BAND” button (11) to select a radio band: FM1, FM2, FM3, AM or WX (weather band). 3. -
Page 5: General Operations
M5100CDUMFinal 2/1/05 4:58 PM General Operations Setting the Clock 1. Press DISP button (13) for more than 3 seconds until the clock shown in the display area is flashing. 2. Press the TRK/TUNE DN button to adjust the hours 3. Press the TRK/TUNE UP button to adjust the minutes. -
Page 6: Cd Player Operation
M5100CDUMFinal 2/1/05 4:58 PM CD Player Operation Inserting and Ejecting a Disc Pull the tab at the top of the CD Door, and the door will open. Push a disc into the CD Slot (19), label side up, and the disc will begin to play. The disc will eject automatically when the CD Door is opened. - Page 7 M5100CDUMFinal 2/1/05 4:58 PM Waterproof Wired Remote General Operations (Optional) POWER 1. Power Button: Press and release the button (1) to turn on/off the unit. To program the initial volume level, adjust the volume to the desired level, then press the POWER button for more than 3 seconds.
-
Page 8: Installation Procedures
This unit is a wired remote control made using a modified controller or similar layout. It is capable of operating the specified functions on the M5100CD receiver. The body, buttons, controls and display are UV and water-resistant. It includes a LCD and an illumination circuit. - Page 9 M5100CDUMFinal 2/1/05 4:58 PM Wiring Step 1: The radio chassis is designed to be “Panel Mounted” through a opening in the mounting panel. See the installation part of this manual for panel mounting. Step 2: Bring all wiring for the connection of the unit (including the antenna) through the mounting hole.
-
Page 10: Wiring Diagram
Speaker White Wire with Black Stripe Left Green Wire Rear Speaker Green Wire with Black Stripe Page 10 M5100CD RCA Connectors Set 1 Connect to Line Input of Optional Amplifier RCA Connectors Set 2 Connect to Line Input of Optional Amplifier... -
Page 11: Auxiliary Connection
M5100CDUMFinal 2/1/05 4:58 PM CD Changer Connection M5100CD 8-Pin Din Connector Auxiliary Connection M5100CD Auxiliary Audio Input RCA with Yellow Cables Wired Remote Connection M5100CD Female 8-Pin Mini Din Connector Page 11 Male to Male 8-Pin Din Cable (Supplied with CD changer) -
Page 12: Installation
M5100CDUMFinal 2/1/05 4:58 PM Installation Remove Transportation Screws Before installing the unit, remove the two screws shown in the illustration below. Remove screws before installation Note: If this unit is to be installed in a boat or a spa, you should use the two pieces of plastic film (30 mm X 20 mm) supplied to seal the two holes after removing the screws. -
Page 13: Troubleshooting
M5100CDUMFinal 2/1/05 4:58 PM Installation Trouble Shooting Before going through the trouble shooting table below, check the wiring connection. If the problem persist, consult your nearest service dealer. SYMPTOM CAUSE No power The ACC Power Supply is not connected. The fuse is blown. Disc cannot be loaded, Presence of disc inside the player. -
Page 14: Specifications
ONE (1) YEAR LIMITED WARRANTY Magnadyne Corporation or its authorized agents will within one year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of... - Page 15 M5100CDUMFinal 2/1/05 4:58 PM Page 16 A Registered Trademark of Magnadyne Corporation © Copyright 2003 Magnadyne Corporation M5100CDUM Rev. B 2-05...
