Summary of Contents for Magnadyne M1-NAV
- Page 1 M1-NAV 8/4/08 1:27 PM Page 1 Operation and Installation Manual NAVIGATION BOX M1-NAV Navigation Module...
-
Page 2: Safety Instructions
Your first priority while driving should always be the safe operation of your vehicle. Magnadyne will not accept any responsibility whatsoever for accidents and/or injuries resulting from failure to observe these precautions or safety instructions. -
Page 3: Table Of Contents
M1-NAV 8/4/08 1:27 PM Page 3 Index Safety Instructions..............2 Caution. -
Page 4: Voice Control Set-Up
M1-NAV 8/4/08 1:34 PM Page 4 Voice Control Set-up Navigation Voice Control: You can specify if you want the navigation’s voice to interrupt the audio of another source and give turn directions. For example, with a navigation destination selected and the Navigation Voice is On and you switch the source to the radio, the radio will be interrupted to give navigation turn directions. -
Page 5: Selecting A Different Source From Navigation Screen
M1-NAV 8/4/08 1:34 PM Page 5 Selecting a Different Source from Navigation Screen Selecting a Different Source: Press the button to leave the navigation source and return to the last selected source. Calibrating the Screen When you first connect the GPS box to the stereo receiver you should adjust the screen to the center position and calibrate the touch screen. -
Page 6: Loading A Map
M1-NAV 8/4/08 1:35 PM Page 6 Calibrating the Screen 5. You will see a displayed on the screen. Touch the firmly, the will continue to move until the screen is aligned. Continue to touch the firmly until OK appears on the screen. -
Page 7: Getting Started
M1-NAV 8/4/08 1:35 PM Page 7 Loading a Map (Continued) 4. Locate the map containing your state by using buttons. Press the Select button to load the map. 5. The navigation unit will then automatically display the Main Map screen and show your location on the map. - Page 8 M1-NAV 8/4/08 1:35 PM Page 8 Getting Started (Continued) Options Menu: From the Destinations menu press the Next button. 1. Day/Night Mode: The Day/Night button adjusts the display for either day or night driving. (See Maps Views on page 10).
-
Page 9: Main Map
M1-NAV 8/4/08 1:40 PM Page 9 Main Map Direction Bar Current Location Zooms Display Compass Quick Nav No Function Direction Bar: When you have calculated a route, press the Direction Bar to display the Turn-by-Turn screen for a complete list of directions. -
Page 10: Map Views
M1-NAV 8/4/08 1:40 PM Page 10 Map Views 2D Views: Day Map View Night Map View Point on the Map You can navigate to any point by touching its location directly on the Main Map screen in both 2D and 3D map views. -
Page 11: Destinations Menu
M1-NAV 8/4/08 1:40 PM Page 11 Destinations Menu Address: The Address button lets you navigate to an address by inputting an address. 1. Press the Address button. 2. Use the buttons to select the state. You can also select the state by entering the first few letters of the state. - Page 12 M1-NAV 8/4/08 1:40 PM Page 12 Destinations Menu (Continued) Address: (continued) 6. Press the GO button and the navigation sys- tem will calculate driving directions. Note: The Quick option selects the route that takes the least amount of time. Quick is the default setting.
-
Page 13: Recent Location
M1-NAV 8/4/08 1:40 PM Page 13 Destinations Menu (Continued) Address: (continued) Action Button: When you have specified an address, press the Action button to select from the following com- mands. Set as Origin: Lets you designate the select- ed location as the route origin. You would use this command when calculating a route from a point other than your current location. - Page 14 M1-NAV 8/4/08 1:43 PM Page 14 Destinations Menu (Continued) Recent Locations: (continued) 4. Press the Go button to calculate your route. Show Button: You can display the selected Recent Locations by pressing the Show button. A map appears showing the specified location. Press the Go button to calculate the route.
-
Page 15: My Favorites
M1-NAV 8/4/08 1:43 PM Page 15 Destinations Menu (Continued) My Favorites: My Favorites is a group where you can store destination for easy retrieval. My Favorites group is the default group where all favorites are stored unless you create another group. Creating other groups allow for easy organizing of your favorite destinations. - Page 16 M1-NAV 8/4/08 1:44 PM Page 16 Destinations Menu (Continued) My Favorites: (continued) 6. Press the Save button. 7. Press the Back button to return to the Destinations screen. Note: Press the Action button to access a screen to Add a Group, Edit a Group or Delete a Group.
- Page 17 M1-NAV 8/4/08 1:44 PM Page 17 Destinations Menu (Continued) My Favorites: (continued) Favorite Alerts Alerts let you know that you are within a certain distance of a favorite location. Favorite Alerts 1. Press the Alerts button. 2. Set the distances for the 1st and 2nd Alerts.
-
Page 18: My Favorites
M1-NAV 8/4/08 1:44 PM Page 18 Destinations Menu (Continued) My Favorites: (continued) 2. Select your favorite location then press the Next button. 3. Select either the Quick or Short button then press the Go button to calculate your route. Note: The Quick option selects the route that takes the least amount of time. -
Page 19: Poi (Points Of Interest)
M1-NAV 8/4/08 12:30 PM Page 19 Destinations Menu (Continued) POI (Points of Interest) The Points of Interest is a collection of hundreds of interesting or useful places organized by easy-to-find categories. For example, you can use the navigation system to guide you to a shopping center, hotel, restaurant or gas station. - Page 20 M1-NAV 8/4/08 12:30 PM Page 20 Destinations Menu (Continued) POI (Points of Interest): Points of Interest Features: Icons Not Displayed on Main Map Icons Displayed on Main Map ( )*** * If the automatic search feature does not find the specified search entry, use the Find button to conduct a sub-search, particularly useful when the address name consists of two or more words.
-
Page 21: Cancel Route
M1-NAV 8/4/08 12:30 PM Page 21 Destinations Menu (Continued) POI (Points of Interest): Subcategories: Many categories have subcategories to provide for an even greater list of choices. For example, gas station, may have many subcategories each representing a particular brand name. The same is also true for hotels. -
Page 22: Route Manager Menu
M1-NAV 8/4/08 12:30 PM Page 22 Route Manager Menu Turn by Turn List: 1. In the Options menu press the Route Manager button. 2. In the Route Manager menu press the Turn by Turn button. 3. The Turn-by-Turn directions will be displayed. -
Page 23: Route Summary
M1-NAV 8/4/08 12:30 PM Page 23 Route Manager Menu Turn by Turn List: (continued) Avoid Turn: The Avoid button lets you avoid the selected turn in the directions list. The navigation sys- tem will the automatically recalculate the route excluding the selected turn. - Page 24 M1-NAV 8/4/08 12:30 PM Page 24 Route Manager Menu Avoid Roads: (continued) 3. You can avoid or allow the road categories by pressing the Allow or Avoid button to include or exclude all item located in the group. Note 1: My Roads to Avoid is a default folder that lets you store roads to avoid.
- Page 25 M1-NAV 8/4/08 12:31 PM Page 25 Route Manager Menu Avoid Roads: (continued) 7. Select the State then press the Next button. 8. Select the City then press the Next button. 9. Select the Street then press the Next button. 10. Select the Street then press the Next button.
-
Page 26: Route Playback
M1-NAV 8/4/08 12:31 PM Page 26 Route Manager Menu Avoid Roads: (continued) Creating a New Group of Roads to Avoid Group: 1. Press the Action button in the “Select or Add Avoid Groups” screen. 2. Press the Add Group button. - Page 27 M1-NAV 8/4/08 1:22 PM Page 27 Route Manager Menu Route Playback: 3. To stop recording, return to the Route Playback screen and press the Stop button. Playing Back a Recorded Route 1. Select the data file and press the Play but- ton.
-
Page 28: Quick Navigation
M1-NAV 8/4/08 1:22 PM Page 28 Route Manager Menu Quick Navigation: When the QuickNav button is pressed on the Main Map screen you will navigate to a predetermined location. For example, if you have selected your home as the QuickNav destination, when you click the QuickNav button on the Main Map screen, the navigation creates a route to your home. -
Page 29: Map Manager Menu
This feature lets you browse the map without the GPS receiver returning you to your current loca- tion. Press the Free Map Browsing button to dis- connect from the GPS receiver and press again to reconnect to the GPS receiver. Units of Measure: You can press the Units of Measure button to specify the measurement system you want to use. -
Page 30: Extra Menu
M1-NAV 8/4/08 1:23 PM Page 30 Extras Menu In the Options menu press the Extras button. A secondary menu will appear that contains a tutorial button which will familiarize you with operation of the navigation system. Also the Multistop planner button for planning a route with up to twelve stops. - Page 31 M1-NAV 8/4/08 1:23 PM Page 31 Extras Menu Multistop Planner: (continued) 5. With the newly created Multistop Route Group visible in the list press the Next but- ton. 6. Add stop to the Multistop Route Group by selecting the Add Stop button.
-
Page 32: Navigation Setting Menu
M1-NAV 8/4/08 1:23 PM Page 32 Extras Menu Multistop Planner: (continued) 9. Select either the Quick or Short button to cal- culate your route then press the Go button. Note: The Quick option selects the route that takes the least amount of time. Quick is the default setting. -
Page 33: Installation
M1-NAV 8/4/08 1:23 PM Page 33 Installation Windshield Antenna Warning! Do not mount in such a manner that it obstructs the driver’s view. • The windshield antenna mounts on the wind- shield (inside). • We suggest you mount it on the lower left- hand side of the windshield. -
Page 34: Connections
M1-NAV 8/4/08 1:23 PM Page 34 Connections Navigation Connection Cable to M1-LCD or M1-LCD2 Antenna Cable... -
Page 35: Feature Locations
M1-NAV 8/4/08 1:23 PM Page 35 Feature Locations 1. RGB/Video Switch: Leave the switch in the RGB mode. Video mode has no function. 2. Reset Button: The navigation system may fail to function normally due to the vehicle’s battery condition, and could require resetting the navi- gation microprocessor if: •... -
Page 36: Warranty
Warranty ONE (1) YEAR LIMITED WARRANTY Magnadyne Corporation or its authorized agents will within one year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the Magnadyne Corporation or its authorized agents, if said product or part is found defective in materials or workmanship, when properly connected and operating on the correct power requirements designated for the specific product.
