Self Propelled Wheelchair
Lift up,
padded armrests
Grip rings
Quick release
24" (610 mm)
rear drive wheels
Detachable, swing away footrests
We recommend you keep this User Guide in a safe place for future reference.
We recommend you keep this User Guide in a safe place for future reference.
user guide
user guide
Prior to use please read all instructions.
Prior to use please read all instructions.
Profiled grip attendant handles
Padded seat and backrest
Height adjustable frame
Nylon heel loops
Park brakes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BetterLiving and is the answer not in the manual?

Questions and answers

Related Manuals for Novis BetterLiving

Summary of Contents for Novis BetterLiving

  • Page 1 Self Propelled Wheelchair Profiled grip attendant handles Padded seat and backrest Lift up, Height adjustable frame padded armrests Grip rings Park brakes Quick release 24” (610 mm) rear drive wheels Nylon heel loops Detachable, swing away footrests user guide user guide Prior to use please read all instructions.
  • Page 2 Available in two different seat damaged or missing components should be widths, the height adjustable frame is equipped reported to your authorised dealer or Novis with comfortable profiled grip handles for safe Healthcare. attendant propulsion and padded armrests that Prior to use, remove all packaging and plastic lift up for easy lateral transfer.
  • Page 3 Set Up Unfold the wheelchair To unfold the wheelchair, place on a stable surface and stand behind the wheelchair. Use both hands to press down on the outer edges of the seat frame to unfold. It may help to gently tilt the wheelchair back to lift the front wheels off the floor.
  • Page 4 Adjustments Adjusting the handle height To move the attendant handles up or down, turn the lock lever (located on the back of the seat directly beneath each handle) anti-clockwise until loose. Adjust the handles to the required height (level with the attendant’s wrist height when standing), then tighten by turning the lock lever clockwise.
  • Page 5 Adjustments Adjusting the brakes When fully released, the maximum distance between the brake latch and the tyre should be no more than 40 mm. To adjust the brakes, loosen the bolt at the top of the brake (refer to picture) and slide the metal bracket left or right to set the correct distance.

  • Page 6: Operation

    Operation Transferring in and out the wheelchair When transferring in or out of the wheelchair, place the wheelchair as close as possible to the transfer destination. Ensure that the front wheels are in the forward position and both footplates are folded up. Always secure the wheelchair by engaging both left and right brake levers.
  • Page 7 Operation Propelling the wheelchair The wheelchair should be self-propelled forward and backward using the grip rings located on the side of the wheels only. Do not manoeuvre the wheelchair by pushing directly on the wheels as this may result in personal injury.

  • Page 8: Transportation And Storage

    Transportation & Storage Folding the wheelchair To fold the wheelchair, firstly fold up the footplates. If needed, the footrests can be removed for easy storage; to remove the footrests, pull the lever on the back of the leg support and swing the footrests outwards, then simply lift up on the footrest assembly to remove.

  • Page 9: Safety And Maintenance

    Safety & Maintenance General Safety Precautions Do not use the wheelchair as a seat in a handicap vehicle. A risk assessment should always be carried Do not tip the wheelchair back beyond its point › › out to ensure the product is suitable for a new of balance or the wheelchair may overbalance.

  • Page 10: Care And Cleaning

    Care & Cleaning Regular Maintenance Cleaning Professional inspection of the wheelchair is Do not use high pressure recommended at least once a year. cleaners or harsh, caustic chemicals for cleaning. Any service or repairs, especially to the brakes, must be performed by a trained professional. Frame Any unauthorised repairs or service may void your warranty.

  • Page 11: Warranty

    Novis Healthcare to comply with Limited Liabilities a consumer guarantee under the Australian Our liability under this manufacturer’s warranty is Consumer Law.

  • Page 12: Specifications

    Seat depth 410 mm Seat back height 180 mm (solid) Front wheels 610 mm (pneumatic) Rear drive wheels Novis Healthcare Manufacturer Novis Healthcare 45 102 735 491 12/12 Mars Road Lane Cove 2066 New South Wales Australia 1300 738 885 .
