Standard Wheelchair
Profiled grip attendant handles
Detachable,
height adjustable
Padded backrest
padded armrests
Grip rings
Park brakes
Quick release
24" (610 mm)
rear drive wheels
Nylon heel loops
Detachable, swing away footrests
user guide
Prior to use please read all instructions.
We recommend you keep this User Guide in a safe place for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BL5148 BetterLiving and is the answer not in the manual?

Questions and answers

Related Manuals for Novis BL5148 BetterLiving

Summary of Contents for Novis BL5148 BetterLiving

  • Page 1 Standard Wheelchair Profiled grip attendant handles Detachable, height adjustable Padded backrest padded armrests Grip rings Park brakes Quick release 24” (610 mm) rear drive wheels Nylon heel loops Detachable, swing away footrests user guide Prior to use please read all instructions. We recommend you keep this User Guide in a safe place for future reference.
  • Page 2 Lightweight non-corroding aluminium or missing components should be reported to your frame equipped with comfortable profiled grip authorised dealer or Novis Healthcare. handles, detachable height adjustable padded Prior to use, remove all packaging and plastic armrests, sturdy park brakes and anti-tip wrapping and check the wheelchair for any wheels for added safety.
  • Page 3 Set Up Unfold the wheelchair To unfold the wheelchair, place on a stable surface and stand behind the wheelchair. Use both hands to press down on the outer edges of the seat frame to unfold. It may help to gently tilt the wheelchair back to lift the front wheels off the floor.
  • Page 4 Adjustments Adjusting the armrest height To adjust the height of the armrests, press and rotate the rectangular lever (located directly below the armrest) to unlock. Adjust each armrest individually by moving the armrest T-bar up or down the armrest shaft. Once preferred height is set, rotate the rectangular lever back to lock the armrest into position.
  • Page 5 Adjustments Adjusting the footrest height Correct leg position is achieved when the occupant’s feet can be placed flat on the footplates when his/her thighs are resting horizontally on the seat. To adjust the height of the footrests, use the Allen Key (provided in the toolkit) to remove the bolt and washer from the footrest.

  • Page 6: Operation

    Operation Transferring in and out the wheelchair When transferring in or out of the wheelchair, place the wheelchair as close as possible to the transfer destination. Ensure that the front wheels are in the forward position and both footplates are folded up. Always secure the wheelchair by engaging both left and right brake levers.
  • Page 7 Operation Propelling the wheelchair The wheelchair should be self-propelled forward and backward using the grip rings located on the side of the wheels only. Do not manoeuvre the wheelchair by pushing directly on the wheels as this may result in personal injury.

  • Page 8: Transportation And Storage

    Transportation & Storage Folding the wheelchair To fold the wheelchair, firstly fold up the footplates. If needed, the footrests can be removed for easy storage; to remove the footrests, pull the lever on the back of the leg support and swing the footrests outwards, then simply lift up on the footrest assembly to remove.

  • Page 9: Safety And Maintenance

    Safety & Maintenance General Safety Precautions Do not use the wheelchair as a seat in a motor vehicle. A risk assessment should always be carried When travelling in the wheelchair the › › out to ensure the product is suitable for a new occupant must not lean forward;...

  • Page 10: Care And Cleaning

    Care & Cleaning Regular Maintenance Cleaning Professional inspection of the wheelchair is Do not use high pressure recommended at least once a year. cleaners or harsh, caustic chemicals for cleaning. Any service or repairs, especially to the brakes, must be performed by a trained professional. Frame Any unauthorised repairs or service may void your warranty.

  • Page 11: Warranty

    Novis Healthcare to comply with Limited Liabilities a consumer guarantee under the Australian Our liability under this manufacturer’s warranty is Consumer Law.

  • Page 12: Specifications

    Seat depth 410 mm Seat back height 152 mm (solid) Front wheels 610 mm (pneumatic) Rear drive wheels Novis Healthcare Manufacturer Novis Healthcare 45 102 735 491 12/12 Mars Road Lane Cove 2066 New South Wales Australia 1300 738 885 .
