Page 1: Sip Phone
GP1266 SIP Phone User Guide Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 1 -... -
Page 2: Table Of Contents
Dialplan Settings................. 24 5.2.6. System Settings.................. 25 5.2.7. Phone Book ..................27 5.2.8. Digit Maps................... 28 USING GP1266 SIP PHONE ................29 6.1. Placing Phone Calls ..................29 6.1.1. Off-hook, On-hook and Speaker-phone Mode ........29 6.1.2. Dial Directly ..................29 6.1.3. - Page 3 6.2.1. Answering a call ................. 31 6.2.2. Call Hold ..................... 31 6.2.3. Call Waiting ..................31 6.2.4. Switch between two calls..............32 6.3. Call Transfer....................32 6.3.1. Blind Transfer ..................32 6.3.2. Attended Transfer ................32 6.4. Call Forward....................33 6.4.1.
-
Page 4: Product Overview
Using IP phone, you will save tremendously on international calls and long distance calls. GP1266 SIP IP phones provide an affordable IP phone system with ease of use, superior voice quality, economic physical design, advanced services, and features. -
Page 5: Software Features
● Program Memory—2 MB Flash memory ● Display LCD—128 X 64 Graphics Dot. ● Ethernet Port—2X 10/100M Connectors ● Power Over Ethernet (POE) (Optional) 2.2. Software Features ● DHCP support for LAN or Cable modem ● PPPoE dialup ● Built in web server for configuration and upgrade ●... -
Page 6: Standard And Protocol
● Call Transfer (Attended & Blind) ● Call Forwarding – Unconditional, No Answer, On Busy ● Auto-Answer ● Do-Not-Disturb ● Configurable Dial Plan Support ● Phone Book with 100 entries ● Speed Dialing Support (10 entries) ● Call History: Missed, Answered, Dialed Numbers with call time (10 each) ●... -
Page 7: Electric Requirements
● RTP: Real-time Transport Protocol ● RTCP：Real-time Transport Control Protocol ● DHCP：Dynamic Host Configuration Protocol ● DNS：Domain Name Server ● TFTP：Trivial File Transfer Protocol ● HTTP：Hyper Text Transfer Protocol ● SNTP：Simple Network Time Protocol ● Syslog：The BSD syslog Protocol 2.4. Electric Requirements ●Voltage: 48V DC (POE Type);... -
Page 8: Installation
Check this following list before installation to make sure that you have received all items. If any item is not included in the package, please contact the distributor. 1) One GP1266 SIP Main Case 2) One Handset 3) One Universal Power Adapter... -
Page 9: Gp1266 Appearance
4. GP1266 APPEARANCE 4.1. GP1266 SIP Phone Illustration ● GP1266 SIP Phone Front Illustration (Refer to Fig 4.1.1)： Power Network1 Network2 LCD Display Mute/ Speed dial Transfer M1---M10 Hold VOL+/UP Message Right Menu Left VOL-/Down Cancel Redial Speaker Flash Call ig 4.1.1 GP1266 Phone Front... -
Page 10: Function Keys
Fig 4.1.2 GP1266 SIP Phone Back 4.2. Function Keys Keys Function Keys Function MENU Speed-Dial key, each corresponds to When phone is idle, M1-M10 a speed dial number which will be press this key to enter called by a single press. -
Page 11: Configuration Guide
Off: Network cable is transmitting and disconnected or network error. receiving. Off: Network cable is disconnected or network error. On: the power supply is all right. HOLD LED On: The call is on POWER LED Off: power supply hold . disconnected. - Page 12 Fig 5.1.1 Main Menu and Phone Settings Menu Structure 2. Scroll the menu Press UP（▲）, DOWN（▼） key to scroll through menu items. 3. Enter the submenu Press OK key to enter the next level of the menu. 4. Edit and confirm Press OK key to enter the edit mode, when current menu item has no submenu.
-
Page 13: Viewing System Info
8. Save/Abandon the changes After the parameters have been modified, 1. Press CANCEL key several times to go back to the main menu, LCD will display “Save xxxx?”. 2. Press OK key. The phone will save the modified contents and reboot. Or press CANCEL key, the phone will abandon all modifications and stay in menu mode. -
Page 14: Network Settings
5.1.3. Network Settings Fig 5.1.2 Network submenu Please check the Web Configuration 5.2.2 for details about these items. 5.1.4. Voice Settings Fig 5.1.3 Voice submenu Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 14 -... -
Page 15: Protocol Settings
Please check the Web Configuration 5.2.3 for details about these items. 5.1.5. Protocol Settings Fig 5.1.4 Protocol submenu Please check the Web Configuration 5.2.4 for details about these items. Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 15 -... -
Page 16: Dialplan Settings
5.1.6. Dialplan Settings Fig 5.1.5 Dialplan submenu Please check the Web Configuration page 5.2.5 for details about these items. 5.1.7. System Settings Fig 5.1.6 System submenu Please check the Web Configuration 5.2.6 for detail about these items. Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 16 -... -
Page 17: Configuration With Web Browser
(default IP: 192.168.1.200). Then put password of the phone into the following page. Default password is empty. Fig 5.2.1 http settings NOTE: Make sure that the phone is in idle mode when viewing or setting GP1266 SIP Phone with web browser. 5.2.1. Network Settings The first several lines of this page give some basic information about this phone, including Phone Model, MAC address, OEM tag and Version No.. - Page 18 Fig 5.2.2 Network Setting Static IP：Select this item to let users to set IP address, subnet mask and router IP address manually. Connection Type DHCP：Have IP address and other network parameters assigned by the DHCP server. Set IP address of the phone manually when Connection Type is IP Address set to Static IP.
-
Page 19: Voice Settings
Set the User PIN of the PPPoE when Connection Type is set to PPPoE User PIN PPPoE. Automatically Get Have DHCP server assign the IP address of DNS server DNS Server IP automatically. Use following DNS Set the IP address of DNS server manually. Server IP Primary DNS Set the IP address of the first DNS server. -
Page 20: Basic Protocol Settings
GP1266 supports up to 7 different Voice Codec types including Preferred Voice PCMU, PCMA, G.726-32, GSM 6.10, iLBC, Speex, G.729. Codec Selecting Null disables the corresponding voice codec. Voice Frames Set the number of voice frames transmitted per packet. The... -
Page 21: Advanced Protocol Settings
Enable/disable registration with SIP server. To make calls SIP Registration through SIP Proxy Server, please check this box; otherwise, only IP to IP calls is allowed. SIP Server Fill in the IP address or URI of SIP Proxy Server. SIP Server Port Fill in the port of SIP Proxy Server. - Page 22 Fig 5.2.5 Advanced Protocol Settings Fill in the local port registered with SIP server. The phone will Local SIP Port send and receive SIP messages from this port. The default value is 5060. Fill in the local port to send and receive for RTP. This is an even Local RTP Port number between 1024 and 65535.
- Page 23 Select the scheme used to send DTMF signals, including inband Send DTMF audio, rfc 2833 and sip info. Fill in the RTP payload type value of DTMF event. The range of DTMF payload type this value is 96-127. Default is 101. G726-32 payload Fill in the RTP payload type value of G726-32 codec.
-
Page 24: Dialplan Settings
With NAT Traversal set to use STUN server, fill in IP address or STUN sever URI of STUN server here. STUN server port Fill in the service port of STUN server. Default is 3478 5.2.5. Dialplan Settings Fig 5.2.6 Dialplan Settings Forward-to Number Enter the number to which you want to forward the call. -
Page 25: System Settings
timeout. Set the time in seconds before the phone answer the call No answer timeout automatically or forward the calls to another party. Enable/disable auto answer. If set to yes, incoming calls will be Auto Answer answered automatically if user doesn’t answer in a certain period of time - No answer timeout. - Page 26 Fig 5.2.7 System Setting Password to access settings, with the maximum length of Administration Password 32 characters. Syslog IP Set the syslog server IP address. Handset input volume Set the input volume of the handset, ranging from 0 – 7. Handset output volume Set the output volume of the handset, ranging from 0 –...
-
Page 27: Phone Book
server. Fill in the port of the auto-provisioning sever. Default is 80 Auto-provisioning port (we use HTTP to do auto-provisioning). Set the interval of auto-upgrade in minute. The maximum Auto-upgrade interval value is 65535 minutes. SNTP Server Fill in the URI or IP address of the SNTP server. Time Zone Select the time zone in list box with user location. -
Page 28: Digit Maps
5.2.8. Digit Maps Fig 5.2.8 Digit Map Digit map is a set of rules to determine when the user has finished entering digits. With digit map, users don’t have to press "call" key after dialing. Fig 5.2.8 gives an example of digit map. X represents any number between 0 and 9. -
Page 29: Using Gp1266 Sip Phone
On-hook Speaker-phone Mode With GP1266 on-hook, it can switch to the off-hook mode by picking up the handset. Press SPEAKER key and put down handset, the phone switches to the speaker-phone mode. With GP1266 on-hook, press SPEAKER key to enter the speaker-phone mode. -
Page 30: Redial
2. Dial the desired number or IP address (Press for“ “). 3. Press CALL to complete the call. To make a direct IP address call, disable the” SIP Registration” option. 6.1.3. Redial 1. Pick up handset or press SPEAKER key. 2. -
Page 31: Speed Dial
3. Scroll to “Call ?” item and press OK key to call this contact. 6.1.6. Speed dial When phone is in off-hook or speaker-phone mode, press speed dial key (M1-M10) to call the number associated with each speed dial key. When phone is in idle mode, press M1-M10 to view the name and number information of each speed dial entry. -
Page 32: Switch Between Two Calls
current call, press FLASH key to place the current call on hold and answer the new incoming call. 6.2.4. Switch between two calls Press FLASH key to switch between two calls. You can also press the hook to end current call and retrieve the on-hold call. 6.3. -
Page 33: Call Forward
dial tone. Enter the number to which you want to transfer the call and press CALL key to make a consulting call. After consulting with the third party, Press TRANSFER key to complete the transfer. If the third party is busy or nobody answers, press FLASH key or hook once to resume the original call. -
Page 34: Mute
period of time (defined by No Answer Timeout), the new call will be answered automatically which means the speaker phone will be automatically turned on. 6.6. Mute During a call, press MUTE key to mute local voice. The mute LED will light up, indicating that the other party cannot hear you. -
Page 35: Edit Phone Book
1. Press MENU key. Scroll to “Call History” and press OK key to enter. 2. Select the desired call record type from “Missed Calls”, “Received Calls”, and “Dialed Numbers”. 3. Delete all call records：Press OK key and scroll to “Delete ALL?” item. Then press OK to delete all call records. -
Page 36: Add A Contact
the modifications, or press CANCEL key to reject all modifications. 6.10.2. Add a contact 1. Press MENU key. Scroll to “Phone Book” and press OK key to enter. 2. Scroll to “—End of List—“. Press OK key to select “Add Newly?” item. Or when any contact is displayed on LCD, press OK key and scroll to “Add Newly?”... -
Page 37: Delete A Contact Entry
Use UP key or LEFT key to delete unwanted input. Press OK key to confirm. Then “Enter number” item will be displayed on LCD, enter the phone number through keypad. Press OK key to confirm. 4. Repeat step 2 and 3 to modify more contacts. E.g. -
Page 38: Firmware Upgrade
2. Press OK key to select the action to be taken next. 3. Scroll to “Delete All?” item and press OK key to confirm. E.g. 7. FIRMWARE UPGRADE 7.1 Manually upgrade Select Upgrade item in the login page and enter the upgrade page below. Fig 7.1.1 manually upgrade 7.1.1. -
Page 39: Locate Upgrade File
2. Scroll to “Load Defaults” and press OK key. Will be displayed on LCD. Press OK key to confirm. GP1266 SIP IP phone will reboot and come up with the factory default settings. 8.2 Store Defaults Settings Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China... - Page 40 2. Scroll to “Store Defaults” and press OK key. Will be displayed on LCD. Press OK key to confirm. GP1266 SIP IP phone will reboot and store the current settings to the factory default settings. Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China...
- Page 41 Annex: GP1266 IP phone digital-character key map ninth Keys Once Twice Thrice quartic quintic sixth seventh eighth ： space Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 41 -...
