- Page 1 GP1260 SIP Phone User Guide Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 1 -...
-
Page 2: Table Of Contents
Dialplan Settings................. 24 5.2.6. System Settings.................. 27 5.2.7. Phone Book ..................29 5.2.8. Digit Maps ..................29 USING GP1260 SIP PHONE ................31 6.1. Placing Phone Calls ..................31 6.1.1. Off-hook, On-hook and Speaker-phone Mode ........31 6.1.2. Dial Directly ..................31 6.1.3. - Page 3 6.2. Answering calls ..................... 33 6.2.1. Answering a call ................. 33 6.2.2. Call Hold ..................... 33 6.2.3. Call Waiting ..................33 6.2.4. Switch between two calls..............33 6.3. Call Transfer....................34 6.3.1. Blind Transfer ..................34 6.3.2. Attended Transfer ................34 6.4.
-
Page 4: Product Overview
Using IP phone, you will save tremendously on international calls and long distance calls. GP1260 SIP IP phones provide an affordable IP phone system with ease of use, superior voice quality, economic physical design, advanced services, and features. -
Page 5: Software Features
● Program Memory—2 MB Flash memory ● Display LCD—128 X 64 Graphics Dot. ● Ethernet Port—2X 10/100M Connectors 2.2. Software Features ● DHCP support for LAN or Cable modem ● PPPoE dialup ● Built in web server for configuration and upgrade ●... -
Page 6: Standard And Protocol
● Call Transfer (Attended & Blind) ● Call Forwarding – Unconditional, No Answer, On Busy ● Auto-Answer ● Do-Not-Disturb ● Configurable Dial Plan Support ● Phone Book with 100 entries ● Speed Dialing Support (10 entries) ● Call History: Missed, Answered, Dialed Numbers with call time (10 each) ●... -
Page 7: Electric Requirements
● RTCP：Real-time Transport Control Protocol ● DHCP：Dynamic Host Configuration Protocol ● DNS：Domain Name Server ● TFTP：Trivial File Transfer Protocol ● HTTP：Hyper Text Transfer Protocol ● SNTP：Simple Network Time Protocol ● Syslog：The BSD syslog Protocol 2.4. Electric Requirements ●Voltage: 9V DC ●Power: 4.5W (max.) 2.5. -
Page 8: Installation
Check this following list before installation to make sure that you have received all items. If any item is not included in the package, please contact the distributor. 1) One GP1260 SIP Main Case 2) One Handset 3) One Universal Power Adapter... -
Page 9: Gp1260 Appearance
4. GP1260 APPEARANCE 4.1. GP1260 SIP Phone Illustration ● GP1260 SIP Phone Front Illustration (Refer to Fig 4.1.1)： Power Network1 Network2 LCD Display Mute/ Speed dial Transfer M1---M10 Hold VOL+/UP Message Right Menu Left... -
Page 10: Function Keys
Network connect 1 Network connect 2 Power Jack Fig 4.1.2 GP1260 SIP Phone Back 4.2. Function Keys Keys Function Keys Function MENU Speed-Dial key, each corresponds to When phone is idle, M1-M10 a speed dial number which will be press this key to enter called by a single press. -
Page 11: Led Functions
Press this key to complete a blind Toggle DND on and TRANSFER MUTE/DND transfer or attended transfer. off when phone idle or mute local voice when in a call. 4.3. LED Functions On: The connection is all right. On: The connection is all right. Flashing: Data Flashing: Data transmitting and NETWORK1... - Page 12 screen will display “Phone Book”. Please refer to Fig 5.1.1. Fig 5.1.1 Main Menu and Phone Settings Menu Structure 2. Scroll the menu Press UP（▲）, DOWN（▼） key to scroll through menu items. 3. Enter the submenu Press OK key to enter the next level of the menu. 4.
-
Page 13: Viewing System Info
changes and return to idle mode. 8. Save/Abandon the changes After the parameters have been modified, 1. Press CANCEL key several times to go back to the main menu, LCD will display “Save xxxx?”. 2. Press OK key. The phone will save the modified contents and reboot. Or press CANCEL key, the phone will abandon all modifications and stay in menu mode. -
Page 14: Network Settings
5.1.3. Network Settings Fig 5.1.2 Network submenu Please check the Web Configuration 5.2.2 for details about these items. 5.1.4. Voice Settings Fig 5.1.3 Voice submenu Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 14 -... -
Page 15: Protocol Settings
Please check the Web Configuration 5.2.3 for details about these items. 5.1.5. Protocol Settings Please check the Web Configuration 5.2.4 for details about these items. Fig 5.1.4 Protocol submenu Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 15 -... -
Page 16: Dialplan Settings
5.1.6. Dialplan Settings Fig 5.1.5 Dialplan submenu Please check the Web Configuration page 5.2.5 for details about these items. 5.1.7. System Settings Fig 5.1.6 System submenu Please check the Web Configuration 5.2.6 for detail about these items. 5.2. Configuration with Web Browser Open a web browser and input the IP address of the phone into address bar Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 16 -... -
Page 17: Network Settings
(default IP: 192.168.1.200). Then put password of the phone into the following page. Default password is empty. Fig 5.2.1 http settings NOTE: Make sure that the phone is in idle mode when viewing or setting GP1260 SIP Phone with web browser. 5.2.1. Network Settings The first several lines of this page give some basic information about this phone, including Phone Model, MAC address, OEM tag and Version No.. - Page 18 Fig 5.2.2 Network Setting Static IP：Select this item to let users to set IP address, subnet mask and router IP address manually. Connection Type DHCP：Have IP address and other network parameters assigned by the DHCP server. Set IP address of the phone manually when Connection Type is IP Address set to Static IP.
-
Page 19: Voice Settings
Set the User PIN of the PPPoE when Connection Type is set to PPPoE User PIN PPPoE. Automatically Get Have DHCP server assign the IP address of DNS server DNS Server IP automatically. Use following DNS Set the IP address of DNS server manually. Server IP Primary DNS Set the IP address of the first DNS server. -
Page 20: Basic Protocol Settings
GP1260 supports up to 7 different Voice Codec types including Preferred Voice PCMU, PCMA, G.726-32, GSM 6.10, iLBC, Speex, G.729 Codec Null Selecting disables the corresponding voice codec. Voice Frames Set the number of voice frames transmitted per packet. The... - Page 21 Fig 5.2.4 Basic Protocol Settings Enable/disable registration with SIP server. To make calls SIP Registration through SIP Proxy Server, please check this box; otherwise, only IP to IP calls is allowed. SIP Server Fill in the IP address or URI of SIP Proxy Server. SIP Server Port Fill in the port of SIP Proxy Server.
-
Page 22: Advanced Protocol Settings
SIP Authenticate ID Fill in the authentication ID. Usually the same as SIP User ID. SIP Authenticate PIN Fill in the authentication password. Fill in the user name that will be displayed to the other party. This User Name is optional. 5.2.4. - Page 23 Set the interval of refreshing registration with SIP Proxy Server in Register expiration seconds. The minimum value is 10s, maximum value is 65535s. Default is 60s. This parameter specifies how often the phone sends a dummy Keep alive interval UDP packet to the SIP server in order to keep the port mapping on the NAT device active.
-
Page 24: Dialplan Settings
Support PRACK Enable/disable PRACK (100rel, RFC3262) support. Subscribe for MWI Enable/disable MWI（Message waiting Indication）support. Fill in the Proxy-Require header filed specified by SIP proxy Proxy Require server. Usually leave this field blank. Select the scheme used to traverse NAT device. Available NAT Traversal options include disabled, use STUN server and use NAT IP. - Page 25 Fig 5.2.6 Dialplan Settings Forward-to Number Enter the number to which you want to forward the call. Forward Enable/Disable unconditional call forwarding. If set to yes, all Forward-to Number Unconditionally incoming calls will be forwarded to Enable/disable call forwarding on busy. If set to yes, the incoming Forward-to Number Forward when busy call will be forwarded to...
- Page 26 timeout Set the time in seconds before the phone answer the call No answer timeout automatically or forward the calls to another party. Enable/disable auto answer. If set to yes, incoming calls will be Auto Answer answered automatically if user doesn’t answer in a certain period No answer timeout of time - Enable/disable call waiting.
-
Page 27: System Settings
Time to wait before sending out the number user dialed when Use digit maps Digit maps timeout is enabled. The minimum value is 3 and the maximum value is 60, with the unit of second. Use “#” To Call Enable/disable “#” to equate “CALL” key 5.2.6. - Page 28 Syslog IP Set the syslog server IP address. Handset input volume Set the input volume of the handset, ranging from 0 – 7. Handset output volume Set the output volume of the handset, ranging from 0 – 31. Speaker output volume Set the output volume of the speaker, ranging from 0-31.
-
Page 29: Phone Book
5.2.7. Phone Book Fig 5.2.8 Phone Book The first 10 entries (001-010) in PHONE BOOK are mapped to speed dial keys (M1-M10). Press M1-M10 will immediately call these numbers. 5.2.8. Digit Maps Fig 5.2.8 Digit Map Digit map is a set of rules to determine when the user has finished entering digits. - Page 30 X represents any number between 0 and 9. 13xxxxxxxxx: Any 11 digits number starting with 13. 013xxxxxxxxx: Any 12 digits number starting with 013. 02[0-57-9] xxxxxxxx: Any 11 digits number starting with 02, the third number could be any digit between 0 and 5 and between 7 and 9. 03[02-689] xxxxxxxx: Any 11 digits number starting with 03, the third number is 0, between 2 and 6, 8, 9.
-
Page 31: Using Gp1260 Sip Phone
On-hook Speaker-phone Mode With GP1260 on-hook, it can switch to the off-hook mode by picking up the handset. Press SPEAKER key and put down handset, the phone switches to the speaker-phone mode. With GP1260 on-hook, press SPEAKER key to enter the speaker-phone mode. -
Page 32: Call From Call History
6.1.4. Call from CALL HISTORY 1. Press MENU key. Scroll to “Call History” and press OK key to select the desired call record type: “Missed Calls”, “Received Calls” and “Dialed Numbers”. 2. Press OK key to view the detailed information of each call record. The first line is the time of the call, and second line is the name and number of the other party. -
Page 33: Answering Calls
6.2. Answering calls 6.2.1. Answering a call Pick up the handset or press the SPEAKER key to answer a call. Put down the handset or press the SPEAKER key to hang up. 6.2.2. Call Hold During a call, press HOLD key to put the other party on hold and send hold music to the other party. -
Page 34: Call Transfer
Phone Book. You can press Speed dial key M1-M10 to replace the number of you want to transfer the call. If Digitmap check box of GP1260 phone was selected, you can dispense with the press CALL key to complete a blind transfer. -
Page 35: Call Forward
6.4. Call Forward 6.4.1. Forward Unconditionally When Forward Unconditionally is set to yes, all incoming calls will be forwarded to Forward-to Number. 6.4.2. Forward when busy When Forward When Busy is set to yes, If a new call comes when the line is busy, the new call will be forwarded to Forward-to Number. -
Page 36: Do Not Disturb (Dnd)
will light up, indicating that the other party cannot hear you. Press MUTE key again to resume the conversation, the mute LED will turn off. 6.7. Do Not Disturb (DND) When phone is on-hook, press MUTE key to put the phone into DND status. -
Page 37: Edit Phone Book
4. Save a call record: 1). Press OK key and scroll to “Add to Phonebook” item. 2). Press OK key to confirm. 3). Press CANCEL key twice. “Save Phonebook?” will show up. 4). Press OK to save the phone book. E.g. -
Page 38: Modify A Contact
Or when any contact is displayed on LCD, press OK key and scroll to “Add Newly?” item. 3. When “Enter name” shows on LCD, enter the name through the keypad. Press OK key to confirm. Then “Enter Number” will show up on display. Enter the number through the keypad. -
Page 39: Delete A Contact Entry
6.10.4. Delete a contact entry 1. Press MENU key. Scroll to “Phone Book” and press OK key to enter. 2. Scroll to the desired contact and press OK key to select the action to be taken next. 3. Scroll to “Delete ?” and press OK key to enter. 4. -
Page 40: Firmware Upgrade
7. FIRMWARE UPGRADE 7.1 Manually upgrade Select Upgrade item in the login page and enter the upgrade page below. Fig 7.1.1 manually upgrade 7.1.1. Select upgrade item The available options include Firmware, Settings, Phonebook, Ring tone and Call Hold Music. 7.1.2. -
Page 41: Start Upgrade
2. Scroll to “Load Defaults” and press OK key. Will be displayed on LCD. Press OK key to confirm. GP1260 SIP IP phone will reboot and come up with the factory default settings. 8.2 Store Defaults Settings 1. - Page 42 GP1260 SIP IP phone will reboot and store the current settings to the factory default settings. Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 42 -...
- Page 43 Annex: GP1260 IP phone digital-character key map ninth Keys Once Twice Thrice quartic quintic sixth seventh eighth ： space Room 1004, Building 2, Phoenix Building, 2008 ShenNan Ave., Futian District,Shenzhen ,China - 43 -...
