Unvented Gas Log Heater
or Vented Decorative
Applianc
e
Models: 18TPB, 24TPB, 30TPB
Natural Gas or Propane/LPG
Control type Milli-Volt
Installation and Operating
Instructions
This appliance may be installed in an aftermarket,
permanently located, manufactured (mobile)
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases.
This is an unvented gas-fired heater. It uses air
(oxygen) from the room in which it is installed.
Provisions for adequate combustion
and ventilation air must be provided.
Refer to page 7.
READ AND SAVE THESE INSTRUCTIONS
WARNINGS
If the information in this manual is not followed
exactly, a fire or explosion may result causing
property damage, personal injury or loss of
life.
–
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
–
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
–
Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
70D0005 12/09 Rev. 7
Advertisement
Table of Contents
Related Manuals for Majestic 18TPB
Summary of Contents for Majestic 18TPB
- Page 1 Unvented Gas Log Heater or Vented Decorative Applianc Models: 18TPB, 24TPB, 30TPB Natural Gas or Propane/LPG Control type Milli-Volt Installation and Operating Instructions WARNINGS This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) If the information in this manual is not followed exactly, a fire or explosion may result causing home, where not prohibited by local codes.
-
Page 2: Table Of Contents
CONTENTS TPB Gas Log Set Thank you and congratulations on your purchase of a Gas Log Set PLEASE READ THE INSTALLATION AND OPERATION INSTRUCTIONS BEFORE USING THE APPLIANCE! IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. Important Safety Information ........ -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION TPB Gas Log Set INSTALLER OWNER Please leave these instructions with the appliance. Please retain these instructions for future reference. IMPORTANT Read these instructions carefully before installing or trying to operate this vent-free gas heater. • Any change to this heater or its controls can be dangerous. •... -
Page 4: Codes
Never connect unit to private (non-utility) only: gas wells. This gas is commonly known Please see pages 40 & 41 for as wellhead gas. additional information. 18TPB, 24TPB, 30TPB Certified To ANSI Z21.11.2a-2008 Unvented Heaters & Z21.60b - 2004; CSA 2.26b - 2004... -
Page 5: Product Features And Specifications
GETTING STARTED - FEATURES and SPECIFICATIONS TPB Gas Log Set GAS PRESSURES Gloves are recommended when handling Natural* LP** ceramic fiber logs to prevent skin irritation Pilot Regulator 3.5" w.c. from loose fibers. Logs are fragile — handle Gas Inlet Pressure Minimum 5"... -
Page 6: General Installation Information
GENERAL INSTALLATION INFORMATION TPB Gas Log Set ADEQUATE COMBUSTION AND VENTILATION AIR This heater shall not be installed in a confined space or unusually tight construction unless provi- sions are provided for adequate combustion and ventilation air. The National Fuel Gas Code, (ANSI Z223.1/NFPA 54), defines a confined space as a space whose volume is less than 50 cubic feet per 1,000 BTU per hour (4.8 m per kw) of the aggregate input rating of all appliances installed in that space. -
Page 7: Fireplace And Hearth Dimensions
Gas Fired Decorative Type Unvented Room Heaters per IAS Requirement No. 2-97 ANSI Z21.91-2001 (typically referred to as a "Universal Firebox"), as long as firebox hearth dimen- sions meet the minimum hearth dimensions shown below. Model 18TPB 26" 13" 18"... -
Page 8: Placement In A Fireplace W/ Restrictive Barrier
TPB Gas Log Set PLACEMENT IN A FIREPLACE WITH A RESTRICTIVE BARRIER IMPORTANT INFORMATION FOR THE INSTALLATION OF THIS GAS LOG SET The following are guidelines for placing a gas log set in a fireplace that has a restrictive barrier along the bottom front opening of the fireplace. -
Page 9: Clearances And Height Requirements
CLEARANCES HEIGHT REQUIREMENTS TPB Gas Log Set The dimensions shown in Figures 4 through 12 and defined in the fireplace manufacturer's instructions are minimum clearances to maintain when installing this heater. Left and right clearances are determined when facing the front of the heater. - Page 10 CLEARANCES and HEIGHT REQUIREMENTS TPB Gas Log Set Heat resistant material (minimum requirements) with no wooden mantel or other combustible projection: To install the gas logs into a fireplace with no wooden mantel, shelf or other combustible projection above the fireplace opening, measure the heat resistant material height, per Figure 5, then see TABLE A. Heat resistant materials such as slate and marble must be at least 1/2”...
- Page 11 CLEARANCES and HEIGHT REQUIREMENTS TPB Gas Log Set Heat resistant material (minimum requirements) with wooden mantel or other combus- tible projection: To install the heater with a wooden mantel, shelf or other combustible projection above, first measure the heat resistant material shown in Figure 6, then refer to Table B. 8"...
- Page 12 14" above the opening, and a maximum of 6" at a Heater in minimum of 20 " above the opening. Fireplace or Firebox Figure 7 - Minimum Mantel Clearance with No Hood -18TPB 12" 10" 8" 6" "...
- Page 13 CLEARANCES HEIGHT REQUIREMENTS TPB Gas Log Set 10" or less Heat Resistant Material 12" min. 28" Heater in Fireplace or Firebox Example: The bottom of the mantel may project from the wall a maximum of 10" at a minimum of 28" above the opening. Figure 9 - Minimum Mantel Clearance with No Hood —...
-
Page 14: Floor Clearance
FLOOR CLEARANCE TPB Gas Log Set The gas log heater must be installed at least 1 " above any combustible flooring material, such as carpet- ing or tile, which is closer than 14" to the base of the fireplace. The minimum distance must be maintained from the top surface of carpeting, tile, etc. -
Page 15: Fireplace Preparation
FIREPLACE PREPARATION TPB Gas Log Set BEFORE FULLY INSTALLING THE UNIT: • Turn OFF the gas supply to the fireplace or firebox. • Seal any fresh air vents and/or ash clean-out doors located on the floor or wall of the fireplace. If left unsealed, drafting may cause pilot outage or sooting. -
Page 16: Installing Vented Applications
TPB Gas Log Set INSTALLING VENTED APPLICATIONS PLACING AND SECURING APPLIANCE You must secure the gas log heater to the fireplace floor. If not, the entire unit may move when you adjust the controls. Movement of unit may cause shifting of the gas logs which leads to sooting and improper burning. -
Page 17: Connecting The Gas
CONNECT THE GAS TPB Gas Log Set NOTICE: A qualified gas appliance installer must connect the heater to the gas supply. Consult all local codes. Use new black iron or steel pipe. Internally tinned copper or copper tubing can be used per National Fuel Code, section 2.6.3, providing gas meets hydrogen sulfide limits, and where permitted by local codes. -
Page 18: Check Gas Pressure
TPB Gas Log Set CHECk GAS PRESSURE The heater gas inlet connection is a " NPT at the valve. On all control type units, the inlet connection is on the right side of Connecting directly to an unit. To connect from the opposite side, route the pipe around unregulated propane/LPG tank the back portion of the unit. -
Page 19: Electrical Wiring (Milli-Volt)
ELECTRICAL WIRING (MILLI-VOLT) TPB Gas Log Set The milli-volt valve is a self-powered combination gas control THAT DOES NOT REQUIRE 110 VAC TO OPERATE. Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. -
Page 20: Connecting Remote Receiver
ELECTRICAL WIRING (MILLI-VOLT) TPB Gas Log Set CONNECTING REMOTE RECEIVER 1. Set remote receiver. See instructions included in receiver kit. 2. Connect the two (2) 1/4" female connectors to the TP/TH and TH terminals on the control valve. Remote Wire Connectors Do not let wires touch grate or... -
Page 21: Blazing Oak Log Placement
LOG PLACEMENT TPB Gas Log Set Before you begin — This unit is supplied with six (6) ceramic fiber logs. Do not handle these logs with your bare hands. Always wear gloves to prevent skin irritation from ceramic fibers. After handling the logs, wash your hands gently with soap and water to remove any traces of fibers. -
Page 22: Log Placement
TPB Gas Log Set LOG PLACEMENT 3. Place left base log (#3) on two pins on left side of grate. see Figure 21. Left Base Log (#3) Pins Figure 21 - Installing Left Base Log (#3) Right top log (#4) 4. - Page 23 LOG PLACEMENT TPB Gas Log Set 5. Place right end of left top log (#5) on bottom center grate pin. Rest the left end of left top log (#5) on the left base log. see Figure 23. Left Top Log (#5) Left Base Log (#3)
- Page 24 LOG PLACEMENT TPB Gas Log Set 6. Place right front log (#6) on two pins on the right front of grate. see Figure 25. Right Front Log (#6) Right Front Pins Figure 25 - Installing Right Front Log (#6) PLACING ROCk WOOL After installing logs, place TPB18-RW (Rock Extrusions Wool) in dime-size pieces evenly across the...
-
Page 25: Riser And Steel Bar Installation
TPB Gas Log Set RISER AND STEEL BAR GRATE INSTALLATION OPTIONAL RISER INSTALLATION An optional riser is available. Place the riser in your firebox or fireplace in the desired location. Place burner on riser. Attach burner to riser with two screws provided. see Figures 27 and 28. Screws Riser Screw Holes... -
Page 26: Optional Cast Iron Grate And Andirons Installation
OPTIONAL CAST IRON GRATE AND ANDIRON INSTALLATION TPB Gas Log Set CAST IRON GRATE INSTALLATION An optional cast iron grate is available. The grate will set in front of the riser on the fireplace floor. The grate may be used with or without the riser. see Figure 31. Legs Cast Iron Grate... -
Page 27: Flame Appearance
FLAME APPEARANCE TPB Gas Log Set PLACING THE DECORATIVE ROCk DO NOT sprinkle volcanic rock on the logs, around the pilot, or on or near burners. This may cause sooting. Place volcanic rock only on the floor of the fireplace. During initial operation of the new heater, burning logs will give off a paper burning smell and orange flames will be present. -
Page 28: Checking Burner Flames
CHECkING THE BURNER FLAME TPB Gas Log Set In normal operation at full rate after 15 minutes, the following flame appearances should be observed: Figure 35 - Correct Appearance of Rear Flames of Blazing Oak Burner will have a random pattern of yellow flames as shown in Figure 35. There should be glowing embers on the front burner. -
Page 29: Operating Instructions
OPERATING INSTRUCTIONS TPB Gas Log Set FOR YOUR SAFETY READ BEFORE LIGHTING If you do not follow these instruction exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with a piezo ignition device which lights the pilot. If piezo is not working properly see Match lighting instructions, page 33. -
Page 30: Milli-Volt Control Lighting Instructions
TPB Gas Log Set OPERATING INSTRUCTIONS MILLI-VOLT CONTROL LIGHTING INSTRUCTIONS 1. STOP! Read the safety information label. 2. Make sure the manual shutoff valve is fully open. 3. This gas log set is equipped with an ignition device (piezo) which automatically lights the pilot. If piezo ignitor does not light the pilot, refer to instructions for Match lighting instructions, page 29. -
Page 31: Match Lighting Instructions
OPERATING INSTRUCTIONS CLEANING AND SERVICING TPB Gas Log Set MATCH LIGHTING INSTRUCTIONS 1. Remove any items necessary for easy access to the pilot (for example: logs, screens, etc.). 2. Follow appropriate lighting instructions found previously. Instead of pushing and releasing the piezo button, light a match and hold the flame to the end of the pilot and ignite the pilot. -
Page 32: Troubleshooting
TROUBLESHOOTING TPB Gas Log Set Turn appliance OFF and allow to cool before servicing. Only a qualified service person should service and repair the heater. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ignitor button is 1. - Page 33 TROUBLESHOOTING TPB Gas Log Set If the gas quality is bad, your pilot may not stay lit, the burners may produce soot and the heater may backfire when lit. If the gas quality or pressure is low, contact your local gas supplier immediately.
-
Page 34: Replacement Parts
REPLACEMENT PARTS TPB Gas Log Set BURNER ASSEMBLY Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. 70D0005... - Page 35 REPLACEMENT PARTS LIST TPB Gas Log Set BURNER ASSEMBLY 18TPB 24TPB 30TPB Ref. Description Qty. Natural Propane Natural Propane Natural Propane 1. Piezo Ignitor 14D0503 14D0503 14D0503 14D0503 14D0503 14D0503 2. Piezo Wire 00K0632 00K0632 00K0632 00K0632 00K0632 00K0632 3. Burmer...
-
Page 36: Logs
REPLACEMENT PARTS LIST TPB Gas Log Set REPLACEMENT PARTS ARE AVAILABLE THROUGH YOUR RETAILER. BLAZING OAk LOGS Item Description BOCL18 BOCL24 BOCL30 Right Base Log 70D0131 70D0041 70D0231 Rear Log 70D0132 70D0042 70D0232 Left Base Log 70D0133 70D0043 70D0233 Right Top Log 70D0134 70D0044 70D0234... - Page 37 TPB Gas Log Set 70D0005...
-
Page 38: Massachusetts Residents Only
Massachusetts Residents Only — Please read and follow these special requirements TPB Gas Log Set NOTE REGARDING VENTED PRODUCTS detector with an alarm shall be installed. This product must be installed by a licensed plumber or 2. Approved Carbon Monoxide Detectors. Each carbon gas fitter when installed within the Commonwealth of monoxide detector as required in accordance with the above Massachusetts. -
Page 39: Warranty
LIMITED LIFETIME WARRANTY POLICY TPB Gas Log Set LIFETIME WARRANTY The following components are warranted for life to the original owner, subject of proof of purchase: Firebox, Combustion Chamber, Heat Exchanger, Grate, and Stainless Steel Burners. FIVE YEAR WARRANTY The following components are warranted for 5 years to the original owner, subject of proof of purchase: Vent Free Ceramic Fiber Logs and Aluminized Burners. - Page 40 MHSC 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com...
