JL Audio 12W3v3-2 Owner's Manual page 3

SUBWOOFER
Volume
(net int.)
1.250 ft³
12W3v3-2
35.4 litres
1.125 ft³
12W3v3-4
31.8 litres
1.250 ft³
12W3v3-8
35.4 litres
SUBWOOFER
Volume
(net int.)
1.75 ft³
12W3v3-2
49.6 litres
1.75 ft³
12W3v3-4
49.6 litres
1.75 ft³
12W3v3-8
49.6 litres
1/4" (6.5mm)
5/8" (16mm)
All enclosure volumes listed are net internal volumes!
two
double
amplified system
passive crossover (coil), as this
JL AUDIO 12W3v3-2/12W3v3-4/12W3v3-8
All specifications are subject to change without notice.
RECOMMENDED SEALED ENCLOSURES
External Dimensions
(Width x Height x Depth)
23 in. x 14 in. x 10 in.
584 mm x 356 mm x 254 mm
23 in. x 14 in. x 9.25 in.
584 mm x 356 mm x 235 mm
23 in. x 14 in. x 10 in.
584 mm x 356 mm x 254 mm
Enclosure External Dimensions
(Width x Height x Depth)
29 in. x 14 in. x 12.625 in.
737 mm x 356 mm x 321 mm
29 in. x 14 in. x 12.625 in.
737 mm x 356 mm x 321 mm
29 in. x 14 in. x 12.625 in.
737 mm x 356 mm x 321 mm
external
3/4" (19mm)
5/8" (16mm)
two times the
Prolonged exposure to sound pressure levels in excess of 100dB can cause permanent hearing loss. This high-performance
speaker can exceed this level. Please exercise restraint in its operation in order to preserve your ability to enjoy its fidelity.
bi-
When installing a subwoofer in your vehicle, it is extremely important to secure the enclosure firmly. We recommend
bolting the enclosure through the metal of the floorpan or the frame of the vehicle with large diameter washers for
reinforcement. If an enclosure is not firmly attached, it can become a projectile in a collision. This is particularly important
in a hatchback, station wagon, sports utility vehicle, or van.
F3 Fc
(Hz) (Hz)
41.8 50.4
43.7 50.2
41.5 50.5
RECOMMENDED PORTED ENCLOSURES
Slot Port Specs
Slot Area x Slot Length
17.1875 sq. in. x 26.125 in.
17.1875 sq. in. x 26.125 in.
17.1875 sq. in. x 26.125 in.
Qtc
0.96
0.83
0.91
Rec. Slot Port Internal Dimensions
Slot Width x Slot Height x Slot Length
1.375 in. x 12.5 in. x 26.125 in.
35 mm x 318 mm x 664 mm
1.375 in. x 12.5 in. x 26.125 in.
35 mm x 318 mm x 664 mm
1.375 in. x 12.5 in. x 26.125 in.
35 mm x 318 mm x 664 mm
"EL" (Port Extension Length)
12W3v3-2: 13.5 in. (343 mm)
12W3v3-4: 13.5 in. (343 mm)
12W3v3-8: 13.5 in. (343 mm)
Tune to: F3
(Hz) (Hz)
30.0 36.0
30.0 35.0
30.0 35.0
3
