  • Page 1 Helios Products Series OPERATION MANUAL 3120 3720 HD\SD 3920 3930 HD\SD 3960 5970 8800 6X-1090K Technical Manual www.CohuHD.com info@CohuHD.com July 15, 2014...
  • Page 2: Table Of Contents

    Table of Contents About this document Additional information and documents related to the camera system FCC compliance Support services Returns 1.0 Getting Started 1.1 Factory Default IP Address and Settings 1.2 System Requirements 1.3 Recommended Computer Specifications 1.4 3960 /3960 /5970 Interconnection Diagram 1.5 3930...
  • Page 3: About This Document

    About this document The Operation Manual is a combined document for the CohuHD™ Helios™ products and contains informa- tion on how to configure and operate camera systems using Helios Web Interface for 3960 /3960 /3930 3920 /3920 /3720 / 3120 /8800 series.
  • Page 4: Returns

    Returns This item was thoroughly tested and carefully packed at the factory prior to shipping. Upon acceptance by the carrier, the carrier assumes responsibility for the item’s safe arrival. If you receive the item in a damaged condition, apparent or concealed, a claim for damage must be made to the carrier. If a visual inspection shows damage upon receipt of this shipment, it must be noted on the freight bill or express receipt and the notation signed by the carrier’s agent.
  • Page 5: Getting Started

    1.0 Getting Started NOTE: All graphics contained within this document, including screenshots and other displays, are for reference use only and are subject to change. Installation and testing of the camera system can be performed with the built-in Helios Web Interface ap- plication.
  • Page 6: 3960 Hd /3960 Sd /5970 Sd Interconnection Diagram

    1.4 3960 /3960 /5970 Interconnection Diagram Figure 1 shows an interconnection diagram for the 3960 /3960 / 5970 series cameras. NOTE: If your PC has a GigE network interface, you can bypass the switch and plug the camera system RJ45 cable directly into the GigE port on your computer. This diagram represents a typical installation.
  • Page 7: 3930 Hd Interconnection Diagram

    1.5 3930 Interconnection Diagram Figures 2 and 3 show interconnection diagrams for 3930 • Figure 2 shows a setup of the camera system with PoE-enabled switch. • Figure 3 shows a setup of the camera system using the PoE injector with non-PoE switch. NOTE: If your PC has a GigE network interface, you can bypass the switch and plug the camera system RJ45 cable directly into the GigE port on your computer.
  • Page 8 Properly secure the camera system Default IP Address before the power is applied. 192.168.2.150 System Cable (CAT5e) Grounding Stud 16 AWG Wire Earth Router/ Ground Router/Switch non-PoE Switch Out In PoE Injector Earth Network Ground Switch 100-240 Vac Power Power Cord Figure 3.
  • Page 9: Hd Sd

    1.6 3920 /3920 Interconnection Diagram Figures 4 and 5 show interconnection diagrams for the 3920 /3920 series cameras: • Figure 4 shows a setup of the camera system using IP output. • Figure 5 shows a setup of the camera system using analog and IP output. NOTE: If your PC has a GigE network interface, you can bypass the switch and plug the camera system RJ45 cable directly into the GigE port on your computer.
  • Page 10: 3120 Hd /3720 Hd Interconnection Diagram

    1.7 3120 /3720 Interconnection Diagram Figures 6, 7 and 8 show interconnection diagrams for the 3120 and 3720 series camera systems: • Figure 6 shows a setup of the camera system using IP output. • Figure 7 shows a setup of the camera system with PoE-enabled switch. •...
  • Page 11 Power over Ethernet The 3120 and 3720 camera systems are compliant with the IEEE 802.3at standard. Power to the cam- era system is supplied through the network cabling. Two types of PoE implementations are specified by the standard: • Endspan PoE: Power is applied directly by the switch to the Camera. This method requires the deployment of a PoE-enabled switch.
  • Page 12: 8800 Hd Interconnection Diagram

    1.8 8800 Interconnection Diagram The figure below shows interconnection diagrams for the 8800 series camera systems. NOTE: If your PC has a GigE network interface, you can bypass the switch and plug the camera system RJ45 cable directly into the GigE port on your computer. These diagrams represent typical installations.
  • Page 13: Assigning The Static Ip Address

    1.9 Assigning the Static IP Address IMPORTANT: In order to make changes in network settings and install ActiveX® controls in the local ma- chine the user must be logged in as Administrator. Please contact your local IT department if you do not have Admin privileges.
  • Page 14 3. You will see the Internet Protocol (TCP/IP) dialog box. Select the Use the following IP ad- dress button in the General tab. Enter IP address: the IP address range is 192.168.2.1 through 192.168.2.254 except the IP address that already is used by the camera system. The subnet mask must be 255.255.0.0.
  • Page 15: Accessing The Camera Using The Helios Web Interface

    2.0 Accessing the Camera Using the Helios Web Interface The Helios Web Interface works with Internet Explorer (IE) 8 or 9. Microsoft ActiveX® is required to view and control video in the Helios Web Interface. MPORTANT: In order to make changes in network settings and install ActiveX® controls in the local ma- chine the user must be logged in as Administrator.
  • Page 16 • The Home page will be displayed. • Press the Start Live Video button ( ) to start the video stream. IMPORTANT: Upon delivery, the first time you access the camera you are logged in as an Admin and have unre- stricted access to the camera’s configuration and operation.
  • Page 17: Assigning The New Camera Ip Address

    Assigning the New Camera IP Address No two devices on a single Ethernet network can have the same IP address. Use the following steps to change a Camera IP address before a second camera is added to the subnet. • Set your computer IP address to the same subnet as the Camera IP address.
  • Page 18: Using The Cohuonvifdiscovery Software To Discover The Camera

    Using the CohuONVIFDiscovery Software to Discover the Camera • Download the software. See Section 4.5. Run the CohuONVIFDiscovery.exe file. Click to start it. • The CohuONVIFDiscovery window will be displayed. NOTE: Auto discovery feature uses network multicast packets and may not work through network rout- ers.
  • Page 19: Helios Web Interface Home

    2.1 Helios Web Interface Home Page Overview The main window provides information about the user type, name of the camera, software revision and ac- cess to configuration/control functions. Control area: 1. The current user level logged into the camera. See Sections 2.2.1.6 and 2.2.2. 2.
  • Page 20: Video Control Area

    2.1.1 Video Control Area The video control area is used for viewing video as well as allowing mouse control of the camera. Changing the Video Display The video display can be expanded to the full screen by clicking the F11 key on the keyboard. To exit from full screen display, press F11 again.
  • Page 21: Setup

    2.2 Setup With appropriate user permission, Setup menu allows you to change the network settings, properties settings and upgrade firmware. Click the Setup button to display buttons from the drop-down menu: • Configuration. See Section 2.2.1. • Change Password. See Section 2.2.2. •...
  • Page 22: Communication

    2.2.1.1 Communication The user must be logged in as Admin in order to make changes in the Communications tab. • Click the Setup button. • Click the Configuration button. • Click the Communications tab. The Communications tab is used for performing network configuration of the camera. Changes to this tab can only be made by the Admin account.
  • Page 23: Stream

    2.2.1.2 Stream 1 The user must be logged in as Administrator in order to make changes in the Stream 1 tab. • Click the Setup button. • Click the Configuration button. • Click the Stream 1 tab. Use The Stream 1 tab to set up the transport mode and parameters of the video stream one.
  • Page 24: Stream 2

    Constrained Mode: UDP video for cellular/wireless networks. Check the box to enable constrained mode for all the RTP over UDP video streams. With H.264 (not MJPEG) UDP video, CohuHD supports a constrained mode of operation. Constrained mode can greatly improve the reliability of a video stream over cellular and wireless/radio networks that are more prone to network interruptions and may have smaller buffers for handling UDP video packets.
  • Page 25 Streamimg: Four supported transport modes can be used for stream one: unicast, multicast, RTP/TCP, and RTP/HTTP/ TCP. Selecting Multicast allows you to specify a multicast address to use. In all cases the packet size to use can be specified as 550, 1400 or 8192 bytes. Transport Mode: Choose from the drop down menu: •...
  • Page 26: Osd (On-Screen Display)

    2.2.1.4 OSD (On-Screen Display) The user must be logged in as Administrator in order to make changes in the OSD tab. • Click the Setup button. • Click the Configuration button. • Click the OSD tab. The OSD (On-Screen Display) menu allows the user to display the text overlays such as Camera Title, Date Time, Preset, Az/Elev/Zoom, Event, etc.
  • Page 27: Time

    Logo Files Logo File Limitations: • HD: 96 x 96 pixels in size; .bmp format; required to be at 32 pixel boundary for both length and width. • SD: 64 x 64 pixels in size. Logo 1: Applies to Stream 1. Check the box to load a logo. Browse to find the file. Click the Load button. Logo 2: Applies to Stream 2.
  • Page 28: User Settings

    2.2.1.6 User Settings The user must be logged in as Admin in order to make changes in the User Settings tab. • Click the Setup button. • Click the Configuration button. • Click the User Settings tab. This tab is used to create and manage user capability and to control user access to the camera. The Web Interface supports several levels of authentication.
  • Page 29 The following authentication options are available: 1. Administrator: Requires authentication for administrators only. The button allows free access to the camera at the Priv, User and Guest levels but requires login to perform Admin functions. 2. Privileged: Requires authentication for Administrator and Privileged users. The button allows free access to the camera at the User and Guest levels.
  • Page 30: Change Password

    2.2.2 Change Password • Click the Setup button. • Click the Change Password but- ton. The new page will appear. The main func- tions of the page are: Help, Logout, and Password change. • Home: Allows user to get back to the Home page.
  • Page 31: Properties

    2.2.3 Properties 2.2.3.1 Properties (Applies to 3960 /3960 /3920 /3920 /3930 /3720 /3120 The user must be logged in as Admin or Priv. in order to make changes in the Properties tab. The Properties menu allows user to configure the camera settings. •...
  • Page 32 White Balance Auto: The camera will automatically compensate for changing lighting conditions to maintain correct color reproduction, especially during the transition from day to night or from night to day Manual: Prevents the white balance compensation from compensating for changing lighting conditions, and allows the operator to manually change the red and blue levels for a specific lighting condition.
  • Page 33: Properties

    2.2.3.2 Properties (Applies to 5970 The user must be logged in as Admin or Priv. in order to make changes in the camera Properties tab. The camera Properties menu allows user to configure the camera settings. • Click the Setup button. •...
  • Page 34 Polarity Polarity: The 5970 camera detects and images the temperatures in a given scene. The Polarity setting programs the specific palette of colors to represent the temperature in the image. Within the camera, these temperatures are mapped to a range of 0 to 127 values. In a black and white display mode, this range is converted to shades of grey with, for example, 0 being totally black and 127 being totally white.
  • Page 35 2.2.3.2.2 Flat Field Correction Flat-field correction (FFC) is a technique used to improve quality in digital imaging. During FFC, a shutter briefly blocks the detector array, presenting a uniform temperature (a flat field) to every detector element. The video image is frozen during the process, which takes less than a half second, and resumes automati- cally thereafter.
  • Page 36 2.2.3.2.3 Automatic Gain Automatic Gain Control automatically op- timizes the image contrast and brightness based on a histogram-equalization algo- rithm. Values for the Plateau Value, ITT (Im- age Transfer Table) Mean, and Max Gain are user programmable. Plateau Value: The Plateau Value sets the limit for the number of pixels in each bin. When this number is small, the Automatic AGC will approach a linear algorithm that preserves a linear mapping between the 14-bit and 8-bit data.
  • Page 37 2.2.3.2.4 Region of Interest (ROI): The ROI sets the area of the detector that the AGC will react to. The ROI can only be configured as a rectangular shape. It is cre- ated by clicking and dragging a box over the area that is most important.
  • Page 38: Properties

    2.2.3.3 Properties (Applies to 8800 • Click the Setup button. • Click the Properties button. • The Properties window will open up. 2.2.3.3.1 Day/Night Mode Determines if the image is color or monochrome and whether in- frared wavelengths are used in producing an image. NOTE: There may be a several second delay when switching be- tween Day/Night modes.
  • Page 39 integration time of the sensor significantly increases the camera sensitivity, but also significantly increase motion blur. Setting the Min Value to “Off” prevents the camera from entering the long term integration mode, and is the recommended mode for most applications. Max AGC: This section is only active when the Shutter mode is in Auto.
  • Page 40: Upgrade

    2.2.4 Upgrade The user must be logged in as Admin in order to upgrade firmware. • Click the camera Setup button from the camera configura- tion/control menu. • Click the Upgrade button. Clicking the Upgrade button will open the Cohu camera Information &...
  • Page 41: Firmware Upgrade

    2.2.4.1 Firmware Upgrade • Click the Browse button in the camera firmware section and find the previously saved new firmware upgrade file. • Click the Start Upgrade button. CAUTION: Make sure to install the correct file of the firmware dur- ing the upgrade process.
  • Page 42: Web Interface Upgrade

    2.2.4.2 Web Interface Upgrade • Click the Browse button in the Web Interface section and find the previously saved new Web Inter- face upgrade file. • Click the Start Web Update button. CAUTION: Make sure to install the correct file of the Web Inter- face during the upgrade process.
  • Page 43: Stream

    2.3 Stream The Stream control selection is available to User, Priv, and Admin users. The Stream button allows user to choose between two streams if the cam- era is configured for two streams in the video format tab in the configura- tion window.
  • Page 44 • Zoom In: Press the In button to zoom until zoom stops at the optical zoom limit. • Zoom Out: Press the Out button to set the camera to the max field of view. • Focus Near/Far: Press the Near or Far buttons to control focus. •...
  • Page 45: Tours

    2.5 Tours (Applies to 3960 /3960 /3920 /3920 /5970 /3720 /3120 / 8800 Privileged User and Administrator are allowed to configure the tours. A tour is a group of presets that are visited in a defined sequence. • The system supports eight tours (only four tours for 3120 3720 •...
  • Page 46: Patterns (Applies To 3720 Hd /3120 Hd )

    2.6 Patterns (Applies to 3720 /3120 Privileged User and Administrator are allowed to configure patterns. Patterns are created by stepping the camera through desired series of locations and imaging states. • The system supports 4 recordable/selectable patterns. • Each pattern records the following operator commands for later recall: Pan, Tilt, Zoom, Autofocus •...
  • Page 47: Park (Applies To 3960 Hd /3920 Hd /3720 Hd /3120 Hd )

    2.8 Park (Applies to 3960 /3920 /3720 /3120 Privileged User and Administrator are allowed to establish the park position. Cameras can be set to automatically move to a preset or start a tour after a selected interval of inactivity. The time can be programmed in seconds, minutes, or hours. 2.9.
  • Page 48 Show Temperature/Pressure (Applies to 3960 /3960 /3920 /3920 /3930 /8800 /5970 /3120 Allows display of the existing status of temperature and pressure inside the camera in the left corner of the video display area. This is intended as a maintenance aid, and allows remote monitoring of the nitrogen charge pressure of the camera barrel.
  • Page 49: Sector (Applies To 3960 Hd /3960 Sd /3920 Hd /3920 Sd /5970 Sd /3120 Hd )

    2.10 Sector (Applies to 3960 /3960 /3920 /3920 /5970 /3120 Privileged User and Administrator are allowed to configure sectors. A sector is a programmed pan area with set boundaries and an identifying label. • System supports 16 sectors. NOTE: For a sector label to be displayed, Sector/Privacy Zones element must be selected in the OSD Configura- tion Menu.
  • Page 50: Privacy Zones (Applies To 3960 Hd /3960 Sd /3920 Hd /3920 Sd )

    2.11 Privacy Zones (Applies to 3960 /3960 /3920 /3920 Privileged User and Administrator are allowed to establish privacy zones. Privacy zones are used to conceal user-defined privacy areas. Up to eight privacy zones can be estab- lished. NOTE: For privacy zones to be displayed, Sector/Privacy Zones element must be selected in the OSD Configuration Menu.
  • Page 51: Back Focus

    2.12 Back Focus (Applies to 8800 The Back Focus function allows user to a have sharply focused image all the time, including during conditions of reduced light levels. Click on far or near buttons to adjust the camera focus accordingly. The focus will continue to change until the button is released or until the focus reaches the limit of its travel.
  • Page 52: Micro Nudge

    IR Illuminator, Night Mode (Future Option): 1. Verify that the lens extender is OUT. 2. While viewing the night scene, verify that the camera is locked in the Night mode (Setup> Properties>Day/NightMode>Mono). 3. Verify that the illuminator is ON. 4. Verify the iris is fully open (Lens, select and hold Iris Open until iris is fully open). 5.
  • Page 53: Event

    2.14 Event (Applies to 3960 /3960 /3920 /3920 /5970 /3720 /3930 / 8800 /3120 The Helios cameras can be configured to perform actions when different events happen. Helios products support the following events: • External Inputs: Inputs for external signals, such as door contacts. See Section 2.14.1 •...
  • Page 54: Ftp (File Transfer Protocol) And Email

    2.14.2 FTP (File Transfer Protocol) and Email The Helios camera can be configured to capture a snapshot in response to a camera event and transfer the image to an FTP site or email ad- dress. To set up FTP: • Click on the FTP and Email tab.
  • Page 55: Auxiliary

    2.14.3 Auxiliary Auxiliary Settings The Auxiliary tab contains controls to configure additional settings that are required to handle camera events. The settings include parameters for operation of the periodic timer (see 2.14.4) and controls to configure the format of snapshot file names.
  • Page 56: Event Actions

    Snapshot Filename Format Snapshot filenames can be configured to include the Host Name, IP Address, Event Type, Date, Time, User Text or Sequence Number. In order to create a unique filename for each snapshot, the filename format must include items that vary. In this case, the only two items that vary are the Time or Sequence Number. If you want to overwrite the snapshot file each time, omit these choices from the format.
  • Page 57: Privacy Mask

    2.15 Privacy Mask (Applies to 3120 /3930 with 720p30x Zoom In) Privileged User and Administrator are allowed to configure the privacy masks. Privacy Masks are used to conceal user-defined privacy areas. Below are steps for setting a privacy mask: • Click the Privacy tab from the left side menu on the Home page.
  • Page 58 NOTES: • A privacy mask can overlap with another privacy mask. • A maximum of 8 privacy masks are programmable for cameras with the pan/tilt support. • A maximum of 4 privacy masks are programmable for the fixed cameras. • A maximum of 4 privacy masks can be programmed in a single field of view (FOV).
  • Page 59: Appendix 1: Region Of Interest (Roi)

    Appendix 1: Region of Interest (ROI) The ROI sets the area of the detector that the AGC will react to. Changing the ROI to ignore an unimportant area of the scene can often improve image quality in the more important area of the scene. Since the AGC algorithm looks for the number of pixels with a given value and distributes those pixels evenly, disregarding unimportant pixels may have a beneficial effect on the output.
  • Page 60: Warranty

    3.0 Warranty Please refer to the CohuHD website for product warranty information: http://www.CohuHD.com/warranty/WarrantyStatement.pdf. Revision History Revision Date Comments • initial release 2/17/10 8/02/10 the manual is revised to • add 3960 series 11/12/10 the manual is revised to • add 3930 and replace the CohuHD Helios Viewer with Cohu Helios Web Interface description...
