OWNER'S MANUAL
1610/1630
LASER/RADAR DETECTOR
TM

Advertisement

Table of Contents
loading

Related Manuals for Whistler 1610

Summary of Contents for Whistler 1610

  • Page 1 OWNER’S MANUAL 1610/1630 LASER/RADAR DETECTOR...
  • Page 2 If you have questions concerning the operation of this Whistler product please call consumer relations: 1-800-531-0004 Hours: Monday - Friday 8:00 am - 5:00 pm CST Please keep the receipt in a safe place. If the unit is returned without a dated proof of purchase an out of warranty service charge applies.
  • Page 3 The Whistler 1630 also offers the benefit of the VG-2 mode. To fully acquaint yourself with the operation of the Whistler radar detector and to better understand the differences between detecting radar, laser and safety radar signals, we recommend reading this entire manual.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Topic Page Model Features Summary ............3 - 5 Installation ................6 - 8 • Mounting Guidelines • Dash/Visor/Windshield Mounting • Power Connection And Fuse Replacement Operation ................9 - 12 • Power On And Self-Test • Feature Engaged Confirmation •...

  • Page 5: Model Features Summary

    WHISTLER FEATURES Whistler 1630 shown Whistler’s ergonomic and user-friendly design provides a new level of operating convenience. Special features include: 1. Rear Laser Antenna (1630 only) – An integrated optical waveguide provides superior detection of laser signals transmitted from behind.
  • Page 6 WHISTLER FEATURES 5. VG-2 Button (1630 only) – Engages (one beep) or dis- engages (2 beeps) VG-2 Cloaking Technology™ for non- detectibility. 6. CITY Button – Reduces the annoyance of false alerts typically encountered in urban driving areas. 7. Speaker – Provides distinct audio warnings for X, K, Ka band radar, safety radar, laser and the VG-2.
  • Page 7 WHISTLER FEATURES Accessories Accessories included are highly functional and easy to use. Power Cord - Connects to the unit’s power jack and your vehicle’s lighter socket. Windshield Bracket - Allows installation of unit on your vehicle’s windshield. Hook & Loop Fasteners - Designed to secure the unit on...

  • Page 8: Installation

    INSTALLATION Mounting Guidelines • Mount the unit as low as possible near the center of the windshield. • Do not mount your unit behind wipers, ornaments, mir- rored sunscreens, etc. These obstructions have metal sur- faces which can affect radar and laser signals and reduce crit- ical warning time.
  • Page 9 INSTALLATION shield bracket. Press the bracket release button and remove the detector before bending. Dash Mounting • Make sure the mounting location you have chosen is relatively level and is clean and dry. Clean with isopropyl alcohol if necessary to remove any waxes or polishes. •...

  • Page 10: Installation

    INSTALLATION Visor Mounting (optional accessory) • Slide the visor bracket into the bracket mounting slot. • Clip the visor bracket onto the visor making sure it is relatively level and has a clear view of the road. Slide on view Insert into bracket mounting slot.

  • Page 11: Operation

    After the laser alert the 1st and 4th (3rd on 1610) alert LEDs flash and the Safety Radar alert is sounded. At the end of the self-test sequence the unit is in the highway mode.

  • Page 12: Feature Engaged Confirmation

    OPERATION Feature Engaged Confirmation Each time a button is pressed one beep confirms feature “on”, two beeps confirm feature “off”. Quiet Mode The QUIET Button accesses one of two muting options. • Manual Quiet: When an audio alert is sounded, you can silence the alarm by pressing QUIET.

  • Page 13: City Mode

    OPERATION City Mode Whistler’s City Mode is designed to reduce the annoyance of automatic door openers, intrusion alarms and other devices which share frequencies with police radar. • Press City to engage City. Display shows: Model 1630 Model 1610 • Pressing City a second time cancels City Mode.

  • Page 14: Vehicle Battery Saver Mode

    OPERATION Vehicle Battery Saver Mode (1630 only) The Vehicle Battery Saver Mode automatically shuts off your detector within 3 hours if you forget to turn it off. The timer is reset if the detector is turned off, unplugged or any button is pressed before the 3 hours have expired.

  • Page 15: Radar, Laser And Vg-2 Alerts

    RADAR ALERTS Radar Audio And Visual Alerts When your Whistler detector encounters traffic radar, it pro- vides a distinctive audio tone for the specific radar band detected: X, K, or Ka. At the same time, LEDs illuminate sequentially from left to right (see page 9). The green and amber LEDs are cancelled during an alert.

  • Page 16: Laser Audio/Visual Alerts

    When your Whistler detects a laser signal, the laser audio alert is sounded and the four red LEDs (three red LEDs on 1610) illuminate from right to left for as long as the signal is present, or for a minimum of three seconds.

  • Page 17: Detection Mode

    VG-2 ALERTS VG-2 Detection Mode (1630 only) The VG-2, also known as a “radar detector detector,” is a special receiver used by police to detect signals radiated by a radar detector. Press the VG-2 button once to engage, unit beeps once. Pressing a second time cancels VG-2 detection mode, unit beeps twice and the VG-2 LED is disengaged.

  • Page 18: Safety Alerts

    When your Whistler detector detects a safety radar signal, it provides a distinctive audio tone and illuminates the first LED and the last LED in the signal strength display.

  • Page 19: Care And Maintenance

    CARE & MAINTENANCE Care And Maintenance During the summer months, avoid prolonged exposure to direct sunlight by removing your unit from the dash when your vehicle is parked for an extended period of time. Do not spray water, cleaners or polishes directly onto the unit.

  • Page 20: Troubleshooting Guide

    PROBLEM: No display or audio. • Check fuse in Whistler plug; replace if necessary with a 2 amp 3AG type. • Check fuse for lighter socket; replace if necessary.

  • Page 21: Are Detectors Legal

    ARE DETECTORS LEGAL? In Most States YES! Laser detectors are completely legal in every state when used in automobiles or light trucks (under 10,000 lbs.). Similarly, when used in automobiles or light trucks, radar detectors are legal in almost every state. Exceptions are Virginia and Washington, D.C., which have local regula- tions restricting the use of radar receivers in any vehicle.

  • Page 22: Speed Monitoring Technologies

    For best protection, keep these points in mind: • Because your vehicle’s license plate or headlights are the laser gun’s primary targets, mounting your Whistler detector on the dashboard can improve laser detection at short range. • Do not follow closely behind any vehicle you cannot see through. If you can’t see past a vehicle ahead of you, chances are your detector won’t...

  • Page 23: Other Speed Detection Systems

    Having a radar detector capable of detecting the VG-2 may alert you to the presence of a speed trap. Be Advised: Model 1610 radar detector does not detect or hide from the VG-2. Only model 1630 provides VG-2 pro- tection.

  • Page 24: Warranty Information

    All express or implied warranties for this product are limited to one year. Whistler is not liable for damages arising from the use, misuse, or operation of this product.
  • Page 25 WARRANTY INFORMATION IMPORTANT: Whistler will not assume responsibility for loss or damage incurred in shipping. Therefore, please ship your unit insured with return receipt requested. 2. Include with your unit the following information, clearly printed: • Your name and street address (for shipping via UPS), and a daytime telephone number.

  • Page 26: Warranty Information

    • The unit has been abused, modified, installed improper- ly, or had its housing removed. The minimum out of warranty service fee for your Whistler detector is $45.00 (U.S.). If you require out of warranty serv- ice, please return your unit as outlined in the section “Service Under Warranty”...

  • Page 27: Specifications

    SPECIFICATIONS • Dimensions: 1.25"H x 2.7"W x 3.9"L • Weight: 5.5 oz. • Laser Wavelength: 905 ± 50 nanometers (nm) • Radar Frequencies: 10.500 - 10.550 GHz (X Band) 24.050 - 24.250 GHz (K Band ) 33.400 - 36.000 GHz (Ka Superwideband) •...

  • Page 28: Accessories

    ACCESSORIES The following accessories can be ordered directly from Whistler by calling 1-800-531-0004. Order Description Price Code 202138 Visor Bracket $ 6.95 202140 Windshield Bracket Kit $ 9.95 206294 *Modular Lighter Plug $ 7.95 (Requires 206550 or 206551) 206550 *Modular Straight $ 6.95...
  • Page 29 NOTES...
  • Page 30 NOTES...
  • Page 31 NOTES...
  • Page 32 TEL (501) 273-6012 FX (501) 273-2927 PRODUCT DEVELOPMENT CENTER 25 Industrial Ave. Chelmsford, MA 01824 TEL (978) 244-1400 FX (978) 244-1492 CUSTOMER RETURN CENTER 1201 N. Dixieland Rd. Rogers, AR 72756 Consumer Relations Tel (800) 531-0004 P/N 203139/2, © WHISTLER 2000...
