Summary of Contents for Whistler 1580
- Page 1 If you have questions concerning the op- eration of this Whistler product please call customer technical service: 1-800-531-0004 Hours: Monday - Friday 9:00 am - 5:00 pm EST...
- Page 2 Whistler’s 1580/1585 also offers a digital display with safety message icons to keep you informed while you drive. To fully acquaint yourself with the operation of the Whistler 1580/ 1585 and to better understand the differences between detect- ing radar, laser and safety radar signals, we recommend reading this entire manual.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Topic Page Model Features Summary 3 - 5 Installation 6 - 8 • Mounting Guidelines • Dash/Visor/Windshield Mounting • Power Connection And Fuse Replacement Operation 9 - 15 • Power On And Self-Test • Memory/Beep Confirmation • Audio Level Adjustment •... -
Page 4: Model Features Summary
WHISTLER FEATURES Whistler 1580/1585 R G N C Y Whistler’s ergonomic and user-friendly design provides a new level of operating convenience. Special features include: 1. Bracket Release Button - Provides quick and easy re- lease of the mounting bracket. 2. Power Jack - Provides connection for the power cord. - Page 5 WHISTLER FEATURES 7. Mute/Menu Button - Pressing MUTE before a signal is detected engages Auto Quiet Mode which automatically reduces the audio level after the initial warning to a low audio level setting. Pressing MUTE during a radar/laser encounter silences audio alerts, while allowing visual alerts to keep you informed.
- Page 6 Fasteners - Designed to secure the unit on a level dashboard. Hardwire Kit (1585 only) - 10 ft. hardwire connects directly to vehicle’s fuse box. Protective Travel Case (1585 only) - Designed for conve- nience storage of your Whistler Radar Detector.
-
Page 7: Installation
INSTALLATION Mounting Guidelines • Mount the unit as low as possible near the center of the windshield. • Do not mount your unit behind wipers, ornaments, mirrored sunscreens, etc. These obstructions have metal surfaces which can affect radar and laser signals and reduce critical warning time. -
Page 8: Dash Mounting
INSTALLATION the detector before bending. IMPORTANT: Some newer cars have a plastic safety coat- ing on the inside of the windshield. The windshield bracket may leave permanent marks on this type of surface. To find out if your vehicle has this type of windshield, check the owner’s manual or ask your dealer. -
Page 9: Installation
INSTALLATION Visor Mounting (optional accessory) • Slide the visor bracket into the bracket mounting slot. • Clip the visor bracket onto the visor making sure it is rela- tively level and has a clear view of the road. Slide on visor Insert into bracket mounting slot Power Connection... -
Page 10: Operation
OPERATION Power On And Self-Test Each time your Whistler detector is turned on, an automatic self-test sequence confirms that the speaker and visual dis- plays are functional and displays the engaged features. • Press (Power) or apply Power. Display reads:... -
Page 11: Audio Level Adjustment
OPERATION Audio Level Adjustment The audio levels can be adjusted high to low, or low to high, in four steps: (1) is the lowest audio level, (4) the highest. • Press Volume to increase audio level. • Press Volume to decrease audio level. As audio level is adjusted, beeps are provided and the dis- play indicates volume level. - Page 12 City/City 1 Mode Whistler’s two-stage City Modes are designed to reduce the annoyance of automatic door openers, intrusion alarms and other devices which share frequencies with police radar. • Press (City) to engage City.
-
Page 13: Dim/Dark Mode
OPERATION Dim/Dark Mode Dim/Dark Mode reduces the illumination of the display. • Press (Power) once to reduce illumination to a Dim setting. Display reads: • Pressing a second time reduces illumination to a dim- mer setting. Display reads: DARK Dim or dark can be engaged during an alert. In Dark Mode, the display goes dark for as long as a signal is being de- tected and for 20 seconds after, then the display returns to the dimmer setting. - Page 14 OPERATION If a button was not pressed within 3-5 seconds alarm sounds and the display reads: GET REST • Press (Power) to exit. WARNING!!! Stay Alert is NOT intended as a substitute for adequate rest. You should NOT operate a vehicle if you are drowsy.
-
Page 15: Option Select Mode
OPERATION Option Select Mode Entering Option Select Mode allows you to personalize Tone Select, Real Voice, Abbreviated Power Up Sequence and VG- 2 Mode. When selecting options, the must be pressed within 20 seconds or options mode will automatically be exited. To enter: Press Display To Change, Option:... -
Page 16: Teach/Tutorial Mode
OPERATION Teach/Tutorial Mode Provides simulated alerts for each type of signal. • Press (City) and (Mute) simultaneously and release. Display reads: TEACH City and Mute modes can also be accessed while Teach/ Tutorial mode is engaged. • Press to exit. -
Page 17: Speed Radar Audio/Visual Alerts
RADAR ALERTS Speed Radar Audio/Visual Alerts When X, K or Ka is detected the band ID and signal strength is displayed. The audio alert is continuous and has a geiger counter-like pattern. The faster the beep the closer the radar source. - Page 18 SAFETY RADAR ALERTS Safety Warning System displays over 60 text messages. When Safety Radar is detected the audio alert is geiger counter- like. Safety Warning System Text Example: Poor Road Surface: CAUTION POOR ROAD SURFACE Note: Safety Warning System consists of 60 text messages. See insert for full description and abbreviations.
-
Page 19: Laser Audio/Visual Alerts
LASER/VG-2 ALERTS Laser Audio/Visual Alerts When a laser signal is detected the word “Laser” and signal strength is displayed, the audio alert is continuous for a mini- mum of 3 seconds. Example: LASER The more “ ” the closer the laser source. VG-2 Audio/Visual Alerts When a VG-2 signal is detected, the detector “hides”... -
Page 20: Reset Features/Care Maintenance
RESET FEATURES/CARE & MAINTENANCE Reset Features All user features can be reset to factory set positions. • Remove Power from unit. • Press and hold (Power) and (Mute). • Apply power to the unit. • Wait for 2 beeps. • Release . -
Page 21: Troubleshooting Guide
PROBLEM: No display or audio. • Check fuse in Whistler plug; replace if necessary with a 2 amp 3AG type. • Check fuse for lighter socket; replace if necessary. -
Page 22: Are Detectors Legal
ARE DETECTORS LEGAL? In Most States YES! Laser detectors are completely legal in every state when used in automobiles or light trucks (under 10,000 lbs.). Similarly, when used in automobiles or light trucks, radar detectors are legal in almost every state. Exceptions are Virginia and Washington, D.C., which have local regulations restricting the use of radar receivers in any vehicle. -
Page 23: Speed Monitoring Technologies
For best protection, keep these points in mind: • Because your vehicle’s license plate or headlights are the laser gun’s primary targets, mounting your Whistler detector on the dashboard can improve laser detection at short range. • Do not follow closely behind any vehicle you cannot see through. -
Page 24: Other Speed Detection Systems
SPEED MONITORING TECHNOLOGIES Other Speed Detection Systems Several techniques other than radar or laser are used to mea- sure vehicle speeds. When these methods are being used, no detector can provide a warning. These techniques include: • Pacing - A patrol car drives behind you and matches your driving speed. -
Page 25: Warranty Information
All express or implied warranties for this product are limited to three years. Whistler is not liable for damages of any type arising from the use, misuse, or operation of this product. - Page 26 WARRANTY INFORMATION IMPORTANT: Whistler will not assume responsibility for loss or damage incurred in shipping. Therefore, please ship your unit insured with return receipt requested. 2. Include with your unit the following information, clearly printed: • Your name and street address (for shipping via UPS), and a daytime telephone number.
-
Page 27: Warranty Information
• The unit has been abused, modified, installed improperly, or had its housing removed. The minimum out of warranty service fee for your Whistler detector is $55.00 (U.S.). If you require out of warranty ser- vice, please return your unit as outlined in the section “Ser- vice Under Warranty”... -
Page 28: Specifications
SPECIFICATIONS • Dimensions: 1.1"H x 2.7"W x 4.6"L • Weight: 6.5 oz. • Laser Wavelength Detection Range: 50 nanometers (nm) • Radar Frequencies: 10.500 - 10.550 GHz (X Band) 24.050 - 24.250 GHz (K Band ) 33.400 - 36.000 GHz (Ka Superwideband) •... -
Page 29: Accessories
ACCESSORIES The following accessories are available through Whistler retailers or can be ordered directly from Whistler by call- ing 1-800-531-0004. Order Description Price Code 202138 Visor Bracket $6.95 202139 Windshield Bracket $9.95 206294 *Modular Lighter Plug $7.95 (Requires 206550 or... - Page 30 Sales Tax (if Applicable) Shipping and Handling 3.00 Total Enclosed SEND ORDER FORM WITH CERTIFIED CHECK OR MONEY ORDER TO: Whistler CTS 16 Elizabeth Drive Chelmsford, MA 01824 IF PAYING BY MASTERCARD OR VISA PLEASE PROVIDE: Type Of Card _____ MasterCard...
