Summary of Contents for Precision Drone Onset
- Page 1 User's Manual Onset/Scout Model 2014...
-
Page 2: Table Of Contents
Table of Contents (1) Warnings..................2 (2) What's in the case?.................4 (3) Detailed Components..............5 (4) Getting Everything Charged.............9 (5) GPS Recalibration................10 (6) Pre-Flight..................11 (7) Flight....................12 (8) Post-Flight..................14 (9) Crop Health Imaging..............14 (10) Rotation Diagrams.................15 Page 1... -
Page 3: Warnings
WARNINGS Obey all federal, state, and local regulations Do not fly in rain or other harsh conditions Do not fly in wind more than 20mph Do not fly faster than 10 m/s (22.5mph) Operating in temperatures below 50° Fahrenheit (10° Celsius) will result in decreased flight times ... - Page 4 *Failure to exercise caution while using this product and comply with the warnings above could result in product malfunction, electrical issues, excessive heat, fire, and ultimately injury, property damage, or death. Never allow use of this product by anyone without providing them with these instructions.
-
Page 5: What's In The Case
What's in the case? List of Case Components 1x Precision Drone Onset OR Scout 3x 4000mAh 3S LiPo Battery (Onset model) OR 4x 5000mAh 3S LiPo Battery (Scout model) 1x Live Feed Monitor (Scout model) 1x Live Feed Monitor Charger (Scout model) -
Page 6: Detailed Components
Components DX8 Controller: Page 5... - Page 7 Battery Charger: Page 6...
- Page 8 Live Feed Monitor: Page 7...
- Page 9 Precision Vision Camera: Page 8...
-
Page 10: Getting Everything Charged
The Scout comes equipped with 5000 mAh 3s LiPo batteries. The Onset comes equipped with 4000 mAh 3s LiPo batteries. It is important that the batteries are charged with these settings. Failure to do so could result in machine under performance or damage to the battery. -
Page 11: Gps Recalibration
Repeat this “cycle” 11 times. The LED indicator on arm 4 of the drone will immediately turn a solid blue. 7. Grab the Scout by arm 5, arm 3 on the Onset, lift it straight up from the ground and hold above the waist 8. -
Page 12: Pre-Flight
Pre-Flight Checklist Drone Controller Live Feed Monitor Batteries 1) Check the drone for any signs of damage or loose cables/straps 2) Make sure all components are fully charged. 3) Check that the propeller direction of rotation is correct. 4) Check that the propellers are tight and won't slip. 5) Make sure motor leads are fastened securely into the ESCs. -
Page 13: Flight
Flight Manual: IMPORTANT: If the drone has difficulty standing still while in hover, it will need a GPS recalibration, refer to page 10 for the instructions 1) Follow all of the steps under the Pre-Flight section first 2) Refer to the FAA guidelines for safe and proper drone operation •... - Page 14 Precision Vision 1 Crop Health System (If equipped) • If your Scout or Onset came equipped with the Precision Vision 1 Crop Health System, make sure both the IR and RGB cameras are charged.
-
Page 15: Post-Flight
Crop Health Imaging (If Equipped) If you optioned your Scout or Onset with the Precision Vision 1 crop health imaging system, follow these steps to get a Precision Vision crop health video from the system. 1. Copy the videos from the SD cards into the same folder. -
Page 16: Rotation Diagrams
Scout Motor Rotation Diagram Page 15... - Page 17 Onset Rotation Diagram Page 16...
