  • Page 1 ® D I S P L AY S...
  • Page 2: Fcc Information

    Part 15 of FCC rules. These his own expense. Changes or limits are designed to provide modifications not expressly reasonable protection against approved by Z Microsystems harmful interference when D I S P L AY S could void user’s authority to equipment is operating in operate the equipment.
  • Page 3: Table Of Contents

    Display Image Has Vertical Bars ................22 Display Image Appears Fuzzy ................22 Replacing Parts .......................23 Appendix .........................24 Specifications for GCS17T ..................24 Schematic Outline for GCS17T ................25 Specifications for GCS21T ..................26 Schematic Outline for GCS21T ................27 Specifications for GCS24T ..................28 Schematic Outline for GCS24T ................29 Disclaimer .......................30...
  • Page 4: Introduction

    This Manual is also available on the Z Microsystems website (www.zmicro.com). We recommend you read this manual carefully and follow the instructions in the Installation chapter for verification of system functions and control settings. Safety precautions DANGER: To avoid shock hazard: •...
  • Page 5: Product Description

    introDUCtion proDUCt DESCription The GCS (Ground Control Station) series is designed with unique flexible mounting options, an ultra-high performance modular video processor and touch panel options built into a light-weight flexible package. The GCS Displays are designed around a state of the art in-house developed video processor that is married to high end LCD electronics producing an advanced picture quality and customization.
  • Page 6: Installation Instructions

    inStaLLation required tools • Philips Screwdriver • 3/32” Allen Key to adjust friction hinges preparations In preparation to install the GCS, turn off the electrical power to your computer. NOTE: For the fastest and easiest installation of the GCS, follow these steps in the sequence they are presented.
  • Page 7 inStaLLation inStaLLation inStaLLation 1. Attach the filler panel at the top of the 2. Extend slides from mounting rack. mounting rack using a Philips screwdriver 3. With the aid of a second person for 4. When Chassis is secure, extend the unit assistance, lift the chassis frame assem- out for easy access to rear connectors and bly onto the slide rails.
  • Page 8: Cable Connections

    inStaLLation 8. When all display alignment pins have 7. Lift and hold the hold the display to the been aligned, hold the display firmly frame and align the display’s pins with the against the frame, and close the quick corresponding holes in the display frame. release latch on the rear.
  • Page 9: Adjusting Angle Of The Displays

    aDjUStinG DiSpLaY anGLES ViEwinG anGLE aDjUStmEnt on top winG DiSpLaY 2.Once the display is free to adjust, use 1. Loosen the hinge slack mechanism in your hands to position the GCS 17 inch the rear of the GCS 17 inch display frame. display unit at the desired angle.
  • Page 10: Preparation For Transport

    prEparation For tranSport piLot anD SEnSor DiSpLaYS tranSport moDE SEtUp 1. Loosen Top display hold-down captive 2. Rotate top display to full vertical position fastener from its storage position. to align display frame with the lock down mechanism. 3. When the display is aligned with the captive fastener, screw captive fastener into display frame to secure display in transport mode.
  • Page 11 prEparation For tranSport 2. When unlocked, carefully fold the 1. Release the angle lock mechanism on display to the full down position so that it the rear of the top-wing display. hangs in front of the exterior lower display. 3. Release the locking mechanism from 4.
  • Page 12 prEparation For tranSport 2. When finished, the system should look as shown below. 27-0043UM REV A 03/10...
  • Page 13: Common View Displays Transport Mode Setup

    prEparation For tranSport Common ViEw DiSpLaYS tranSport moDE SEtUp 1. To secure the center common view 2. To lock the display in the vertical display, rotate the display to the vertical position, turn the knurled nut on the position. left and right hinge arm to extends the locking pins.
  • Page 14: Operations

    opErationS DiSpLaY panEL ControLS The GCS features push-button controls on the lower front of the front bezel. To setup the display, use the following controls to fine tune the image on the screen: Green LED Status (Channel 1) (Red/Green/Amber) Input Select Exit Menu/Select Green LED...
  • Page 15: Display Panel Setup

    opErationS DiSpLaY panEL SEtUp NOTE: If the touch screen option has been purchased for the GCS, the touch screen manufacturer’s software must first be installed on the computer being used with the GCS. Follow manufacturer’s instructions and user manual for software installation and use.
  • Page 16: Onscreen Menus

    opErationS onSCrEEn mEnUS To access the onscreen display main menu, press the menu button on the MAIN MENU front of the panel. All GCS functions R. 52 are controlled using the Main Menu’s subtopics. PICTURE ADJUST GRAPHIC MODE COLOR BAL ANCE CONFIGURATION INFORMATION These submenus can be accessed...
  • Page 17: Graphics Mode

    opErationS main Screen Graphics mode Use the + and - buttons to highlight the “Graphics Mode” option. Press the “Menu” button to access the “Graphics Mode” submenu. (NOTE: The Horz Coarse and Horz Fine options are not applicable for DVI channels). “Graphics Mode”...
  • Page 18: Configuration Screen

    opErationS ConFiGUration SCrEEn menu timeout: CONFIGURATION The amount of time the menu will appear MAIN while not in use before it times out. When the menu times out, it MENU TIMEOUT disappears from the main screen. fACTORY SETTINGS CHANNEL 1 T YPE: ANALOG reset Default Settings: CHANNEL 2 T YPE:...
  • Page 19: Advanced Options Screen

    SCrEEn inFormation Use the + and - buttons to highlight the INFORMATION “Information” option. Press the “Menu” button to access the “Information” MAIN submenu. Z MICROSYSTEMS, INC. WWW.ZMICRO.COM Within this submenu, view firmware version and build date. FIRMWARE: ZDHC R.52...
  • Page 20: Maintenance

    maintEnanCE maintaininG tHE GCS DiSpLaY SEriES WARNING: Be sure to turn off the power before you perform any maintenance on the monitor. WARNING: To avoid risk of electric shock, do not disassemble the monitor cabinet. Users cannot service the monitor. User maintenance is restricted to cleaning as explained below.
  • Page 21: Troubleshooting

    When the standby LED is green, there is both power and a video signal. If there is no image on the main display, there is a possible hardware failure. Recovery: • Ensure the video signal coming from the computer is not a black screen. • Contact Z Microsystems’ Customer Support Department. 27-0043UM REV A 03/10...
  • Page 22: Display Image Has Vertical Bars

    troUBLESHootinG Display image Has Vertical Bars If the main image begins to display vertical bars, adjust the “Horz Coarse”. From the Main Menu, use the Up and Down buttons to highlight the “Graphics Mode” option. Press the “Menu” button to access the “Graphics Mode” submenu. Use the Left and Right buttons to adjust the screen until the number of bars is reduced.
  • Page 23: Replacing Parts

    Customer Service Representative will issue a Return Material Authoriza- tion (RMA) number. An RMA number is required to return a product to Z Microsystems, regardless of the reason for the return. The Z Microsystems Customer Service Department/RMA Request Form will ask the customer to provide the following information: •...
  • Page 24: Appendix

    SpECiFiCationS For GCS17t The GCS Display series is designed to host a choice of LCD’s from several manufactur- ers based upon customer requirements. The specifications unique to each particular LCD vary. These particular specifications are available through our sales department.
  • Page 25: Schematic Outline For Gcs17T

    SCHEmatiC oUtLinE For GCS17t 27-0043UM REV A 03/10...
  • Page 26: Specifications For Gcs21T

    appEnDix SpECiFiCationS For GCS21t General Display Specifications Display size 21 Inch Pixels 1280 x 1024 Colors 16.7 Million Control Control Panel or SoftMenu Options Touch Panel power Power Consumption 66 W AC Power Supply 100-240 VAC, 2.0 A, 50/60 Hz, 400 Hz interface VIDEO: 2x DVI-I connectors HOST: 1x USB Type B connector...
  • Page 27: Schematic Outline For Gcs21T

    appEnDix SCHEmatiC oUtLinE For GCS21t 27-0043UM REV A 03/10...
  • Page 28: Specifications For Gcs24T

    appEnDix SpECiFiCationS For GCS24t General Display Specifications Display size 24 Inch Pixels 1920 x 1200 Colors 16.7 Million Control Control Panel or SoftMenu Options Touch Panel power Power Consumption 101 W AC Power Supply 100-240 VAC, 2.0 A, 50/60 Hz, 400 Hz interface VIDEO: 2x DVI-I connectors HOST: 1x USB Type B connector...
  • Page 29: Schematic Outline For Gcs24T

    appEnDix SCHEmatiC oUtLinE For GCS24t 27-0043UM REV A 03/10...
  • Page 30: Disclaimer

    If the product is transferred to another user, the warranty service is available to that user for the remainder of the warranty period. Z Microsystems’ warranties are voided if the covered product is damaged due to an ac- cident or abuse. The warranty is voided if the product is shipped in sufficient packaging.
  • Page 31: Customer Support

    NOTE: If possible, stay by the computer. The Z Microsystems Technical Support Representative may wish to go through the problem If you are unable to correct the problem over the telephone. yourself, contact Z Microsystems at: Phone: (858) 831-7000 Fax: (858) 831-7001 Website: www.zmicro.com...
  • Page 32: Customer Feedback

    CUStomEr FEEDBaCK We value feedback on our products, their performance, problems found, and welcome all suggestions. Please send to: Customer Service Z Microsystems 9820 Summers Ridge Road San Diego, CA 92121 or www.zmicro.com 27-0043UM REV A 03/10...
  • Page 34 Z Microsystems, Inc. 9820 Summers Ridge Road San Diego, CA 92121 Phone: (858) 831-7000 Fax; (858) 831-7001 Website: www.zmicro.com Copyright 2010 Z Microsystems, Inc. All Rights Reserved...
