- Page 1 FIELD-READY Glider User Manual Z Microsystems...
-
Page 2: Fcc Information
Part 15 of the FCC rules. These limits are designed to provide reasonable Doc# 27-0017UM Issued 08/03 Rev 1.0 own expense. Changes or modifications not expressly approved by Z Microsystems could void user’s authority to operate the equipment. protection against harmful interference in... -
Page 3: Table Of Contents
TABLE OF CONTENTS STARTING POINT Shipment Contents About User Manual System Requirements Features Product Description Tools Required for Installation Precautions INSTALLATION Slide Removal Install The Slides In Cabinet Frame 8 Installation Test Final Adjustments Install Cables SETUP Setting Up Glider PROTECTOR REMOVAL OPERATIONS Cable Connections... -
Page 4: Starting Point
ABOUT USER MANUAL The User Manual comes in two formats: printed hardcopy or CD- ROM. This Manual is also available on the Z Microsystems website (www.zmicro.com). We recommend you read this manual as follows: Carefully follow the instructions in the Installation chapter for hookup and initial control settings. -
Page 5: Doc# 27-0017Um Issued 08/03 Rev 1.0
The unique Glider design allows flat panels up to 21.3” to fold into a 2U (3.5”) drawer space in standard 19” racks and transit cases. display works effectively with any workstation. -
Page 6: Tools Required For Installation
STARTING POINT TOOLS REQUIRED FOR INSTALLATION WARNING: To avoid shock hazard: • Do not remove the covers around the Glider. • Do not connect or disconnect the Glider during an electrical storm. • The power cord plug must be connected to a properly wired and grounded power outlet. -
Page 7: Installation
INSTALLATION SLIDE REMOVAL With the Glider laid on a workbench, press down to release the Z-Locks on each side of the front of the Glider to slide the side rails back. Doc# 27-0017UM Issued 08/03 Rev 1.0 The slide rails will reach a stop about half way back. -
Page 8: Doc# 27-0017Um Issued 08/03 Rev 1.0
INSTALLATION INSTALL THE SLIDES IN CABINET FRAME Each slide unit includes the slide rail, the front Z- Lock mount and the rear mount. The top notch of the Z- Lock must align with the slide rail top ridge. On the rear of the cabinet frame, use three Phillips screws to loosely secure the right... - Page 9 INSTALLATION INSTALL THE GLIDER IN CABINET FRAME The Glider slides should move in and out easily. If not, check alignment of the slider and Z-Lock mount. Pull the two Glider slides out until they lock. Simultaneously press in the catches on each slider and move the Glider all the way into the cabinet frame.
-
Page 10: Doc# 27-0017Um Issued 08/03 Rev 1.0
INSTALLATION INSTALLATION TEST The Glider should easily close completely. FINAL ADJUSTMENTS Slide the Glider partially out. Use a flathead screw- driver to slightly move the Z-Locks in toward or out from the Glider, depnding on the need for best fit. While holding the Z-Locks at the proper setting, tighten the screws on the Z-... -
Page 11: Install Cables
INSTALLATION INSTALL CABLES WARNING: Be sure all electrical power to the cabinet is off before connecting any of the cables. WARNING: There is a key guide for alignment on the cables. Be sure the cable plug and receptacles are aligned properly using the key guide. -
Page 12: Setup
SETUP SETTING UP GLIDER The outer Z-lock bracket fits snuggly against the female Z-lock bracket attached to the cabinet frame. If your unit is equipped with lock down features, lift and slide the two display lock knobs at the back of the display to the open or inward posi- tions. - Page 13 SETUP SETTING UP GLIDER The display can be left in the vertical position or tilted back. The Glider can be slid back until the back of the display almost touches the cabinet. Doc# 27-0017UM Issued 08/03 Rev 1.0 The display can be rotated clockwise to angled positions.
-
Page 14: Doc# 27-0017Um Issued 08/03 Rev 1.0
PROTECTOR REMOVAL The Protective Outer Shield (optional equipment) is intended to protect the surface of the screen from damage while in transit or while stowed. The display protector is not intended to be used while the display is in operation. To remove the display protector, do the following: Rotate the display to the horizontal position, with... -
Page 15: Operations
OPERATIONS CABLE CONNECTIONS NOTE: Connecting to non- standard systems will require an adapter. To obtain a video adapter, contact Customer Services at Z Microsystem, Inc. NOTE: Make sure the DC connector is plugged in seated properly on the back side of the display head. -
Page 16: Doc# 27-0017Um Issued 08/03 Rev 1.0
OPERATIONS DISPLAY PANEL CONTROLS The controller features push-button controls on the lower front of the display screen to adjust the brightness of the display, to change the image positioning on the screen, and to refine the screen image. To complete the setup of the display, use the following controls to fine tune the image on the screen: Z : The Z button is used to switch between available channels. - Page 17 OPERATIONS The three LED lights on the right of the control panel are labeled A, B and C. Their lighted functions are: A — VIDEO A green — VIDEO A is selected B — VIDEO B (green) green — VIDEO B is selected If A &...
-
Page 18: Menus
OPERATIONS MENUS To access the onscreen display main menu, press the menu button on the front of the panel. All Glider functions are controlled using the Main Menu’s subtopics. Main Screen Picture Adjust Use the Up and Down buttons to highlight the “Picture Adjust” option. Press the “Menu”... - Page 19 OPERATIONS Main Screen Graphics Mode Use the Up and Down buttons to highlight the “Graphics Mode” option. Press the “Menu” button to access the “Graphics Mode” submenu. Press “Exit” to return to the Main Menu. The new adjustments will be applied automatically.
- Page 20 OPERATIONS Main Screen Information Use the Up and Down buttons to highlight the “Information” option. Press the “Menu” button to access the “Information” submenu. Main Screen Configuration Use the Up and Down buttons to highlight the “Configuration” option. Press the “Menu”...
-
Page 21: Display Head Removal
DISPLAY HEAD REMOVAL WARNING: Be sure all electrical power is turned off to the Glider before proceeding. To remove the Glider display head, follow these steps: Rotate the display to the horizontal position. On the back of the display, disconnect the power cable. -
Page 22: Maintenance
MAINTENANCE CLEAN MONITOR WARNING: Be sure to turn off the power before performing any maintenance on the monitor. WARNING: To avoid risk of electric shock, DO NOT dissemble the monitor cabinet. User maintenance is restricted to cleaning as explained here. Doc# 27-0017UM Issued 08/03 Rev 1.0 •... -
Page 23: Display Stowage
DISPLAY STOWAGE CLOSE GLIDER The following describes closing and stowage of the Glider in the cabinet. Pull the Glider all the way out. Make sure there is enough room to lower the top of the display head without hitting the cabinet. - Page 24 DISPLAY STOWAGE CLOSE GLIDER The display latch has now locked the side linkage. Slide the Glider into the frame until the Z Locks snap into the closed, secure position. Doc# 27-0017UM Issued 08/03 Rev 1.0 Lower the pivot latch into its recepticle.
-
Page 25: Troubleshooting
If there is no image on the main display, there is a possible hardware failure. Recovery: • Ensure the video signal coming from the computer is not a black screen. • Contact Z Microsystems’ Customer Support Department. Doc# 27-0017UM Issued 08/03 Rev 1.0... -
Page 26: Specifications
MTBF Maintainability Safety Quality/Workmanship * Unit will power up and is legible at -20°C; backlight life is reduced Doc# 27-0017UM Issued 08/03 Rev 1.0 21.3 Inch (432.0 mm x 324.0 mm) 1600 x 1200 16.7 Million 400:1 250 cd/m (max) 2 Ch. -
Page 27: Appendix
Doc# 27-0017UM Issued 08/03 Rev 1.0 If you are unable to correct any problem yourself, contact Z Microsystems at: (858) 657-1000 Fax: (858) 657-1001 Website: www.zmicro.com Before calling, please have available as much of the following information as possible: 1. -
Page 28: Replacing Parts
APPENDIX REPLACING PARTS PROVIDING FEEDBACK Doc# 27-0017UM Issued 08/03 Rev 1.0 If the Z Microsystems Technical Support Engineer determines that the product needs to be replaced, a Customer Service Representative will issue a Return Material Authorization (RMA) number and return address. -
Page 29: Mechanical Outline Drawings
APPENDIX MECHANICAL OUTLINE DRAWINGS Doc# 27-0017UM Issued 08/03 Rev 1.0... - Page 30 APPENDIX Doc# 27-0017UM Issued 08/03 Rev 1.0...
- Page 31 APPENDIX Doc# 27-0017UM Issued 08/03 Rev 1.0...
- Page 32 APPENDIX Doc# 27-0017UM Issued 08/03 Rev 1.0...
- Page 33 APPENDIX Doc# 27-0017UM Issued 08/03 Rev 1.0...
- Page 34 Z Microsystems, Inc. 5945 Pacific Center Blvd., Suite 505 San Diego, CA 92121 Phone: (858) 657-1000 Fax; (858) 657-1001 Website: www.zmicro.com Copyright 1999 Z Microsystems, Inc. All Rights Reserved...
