Mace CAM-73 Specification Sheet

S E C U R I T Y HIGH RESOLUTION VARIFOCAL CAMERA
P RO D U C TS
High Resolution
Vari-focal Super Sensitive
Model : CA M-7 3

Indoor/Outdoor Camera

with 1/3" Color Sony CCD
Super HAD Sensor
NTSC
1/3" Sony CCD, Super HAD (X-View Sensor)
480 TV Lines
3.5mm-8mm Vari-focal lens
.01 Lux
Internal Sync
Lens View
Auto White Balance
Auto Gain Control
S/N Ratio: >50dB (AGC off)
Electronic Shutter: 1/50-1/12000sec
Rear Camera
View
Gamma Correction: 0.45
Operating Temp.: 0C-50C
Weather Resistant
Power: DC12V +/- 1V, 210 mA
Composite Output: 1.0V p-p 75ohm
Mace Security Products
3233 SW 2nd Avenue, Ft. Lauderdale, Florida 33315
Ph: (877) 585-6223 FAX: (954) 585-6225 WEB: www.mace.com
