w
r
eather
esistant
CAM-53CIR
FeatureS
• 1/3" Color Sony HAD CCD Sensor
• 420 TV Lines
• 3.6 mm Lens
• Built-in Infrared - 20 LEDs -
Infrared Distance: 50 Feet
• Weather Resistant - IP55 Std.
• Built-in Audio (Weather Resistant)
• 1 LUX - 0 LUX (IR On)
• Adjustable Sun Shield
• Built-in Lens Separator (eliminates
reflection and cold condensation)
SPeCiFiCationS
Image Sensor
1/3" Color Sony HAD CCD Sensor
Resolution
420 TV Lines
S/N Ratio
>48dB
Video Output
Composite output 1.0V p-p at 75 ohm
White Balance
Mode: AUTO Range: 3200~10000º K
Gain Control
Auto
Min. Illumination
1 LUX
Sync. System
Internal
Lens
3.6mm
Electronic Shutter
1/50~1/20,000 sec.
Auto Iris
A.E.S.
Gamma Correction
0.45
IR Range
50 Feet
Dimensions
3.5" (L) x 2" (W)
Operational Temp.
-4ºF ~ 122ºF
Power
Power DC 12V (included)
Mace Security Products
(Toll Free) 877-585-6223 • www.macepro.com
Pantone 506C
i
C
nfrareD
amera with
a
uDiO
v.03.30.09
