The RGB-VW allows the user to add an aftermarket backup camera to the factory navigation
screen in select Volkswagen vehicles. Reverse activation is automatic, no reverse lamp
connection is required.
NOTE: The VW must be programmed for rear camera (VAG-Comm: Ross Tech) before
installing this product.
RGB Converter
NTV-INT005
:
Agreement
End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
th
Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760
www.nav-tv.com
info@nav-tv.com
RGB-VW
NTV-KIT389
Overview
Kit Contents
RGB Power Harness
NTV-CAB034
Plug & Play Video IN Harness
NTV-HAR209
BHM
01/05/14
NTV-DOC101
1 |
P a g e
Advertisement
Table of Contents
Related Manuals for Nav TV RGB-VW
Summary of Contents for Nav TV RGB-VW
- Page 1 RGB-VW NTV-KIT389 Overview The RGB-VW allows the user to add an aftermarket backup camera to the factory navigation screen in select Volkswagen vehicles. Reverse activation is automatic, no reverse lamp connection is required. NOTE: The VW must be programmed for rear camera (VAG-Comm: Ross Tech) before installing this product.
- Page 2 VW radio (it will only fit in one location). 6. Connect the power plug you previously wired up (step 2 & 3) to the RGB-VW. 7. Connect your camera’s signal to port on the RGB-VW labeled ‘VIDEO 1’.
- Page 3 If you only see a black screen when you put the vehicle in reverse, flip the attached toggle. Leave the toggle in the position where the RGB-VW works properly. The blue wire from the RGB-VW is not used.
