SPEED VISION DX20 DVR User Manual
www.aguriworld.co.uk
1.

Advertisement

Table of Contents
loading

Related Manuals for aguri PEED VISION DX20

Summary of Contents for aguri PEED VISION DX20

  • Page 1 SPEED VISION DX20 DVR User Manual www.aguriworld.co.uk...

  • Page 2: Table Of Contents

    12. Set volume 21. Service under warranty 13. Set time 13. Adjust touch tone What’s in the box? 1 x Aguri Speed Vision DX20 DVR 1 x USB cable 1 x Vehicle charger 1 x Windscreen bracket 1 x User guide...

  • Page 3: Product Overview

    Product overview 15 16 1. Reset 10. Menu/Return button 2. HDMI out socket 11. Video Playback/Up/Mute button 3. USB data/power socket 12. Camera/Down/SOS button 4. Windscreen bracket slot 13. Video Record/OK button 5. Video/Camera Lens 14. 2” Full colour LCD 6.

  • Page 4: Dvr Lcd Overview

    DVR LCD overview Combined speed trap detection and Full speed trap detection view Video recording view. User tip. Press the Menu button to switch between these different views 1 2 3 4 Resolution 10. SOS/Emergency lock recording button Charging status 11.

  • Page 5: Installation

    Installation Insert the 8GB micro SD card in to the SD card slot on the side of the unit and attach the windscreen bracket to the DX20. Mount your DX20 in a safe and convenient position in the front windscreen where it has an unobstructed view of the road ahead. We recommend mounting it at the top of the windscreen near to the rear view mirror.

  • Page 6: Basic Features

    Basic features. Your Aguri Speed Vision DX20 DVR comes as standard with all features set to their optimum settings, however the unit has certain user selectable features you can change to suit your own requirements. Switching views and entering the Setting menus.

  • Page 7: Video Playback

    Video playback and tracking using Aguri DX20 Viewbox PC companion. To view video recordings on your PC, install the Aguri DX20 Viewbox PC companion on your PC. The software can be found on the CD ROM supplied or downloaded from www.aguriworld.co.uk To install from the CD ROM.
  • Page 8 To view video and GPS track files recorded on your DX20, remove the micro SD card from the DX20 and insert it in to your computer. (Please note that you will need an appropriate micro SD Card reader for this task) Next, launch the Aguri DX20 Viewbox software by double clicking on the Aguri DX20 Viewbox icon that you should now find on the desktop of your PC.

  • Page 9: Video Recording Settings

    Double click on the ‘Removable disc’ folder and select either ‘Event’ or ‘Normal’ and press ‘OK’ to import the files in to the DX20 Viewbox software. The video/GPS track files recorded will appear in the two data lists at the bottom of the Aguri DX20 Viewbox as indicated above.
  • Page 10 Motion Detection If Motion Detection is switched on, your DX20 will stop recording when there is no activity in front of it. By only recording when the device senses any activity, your DX20 is able to ignore unimportant periods and save space on the SD card. To switch Motion Detection on or off, enter the additional settings menu, by pressing the menu button twice and use the ‘Up’...
  • Page 11 Date/Time/Driver ID Stamp Use this setting to add a date, time and driver ID stamp to all recordings and photographs. Enter the menu and use the ‘Up’ or ‘Down’ buttons to highlight ‘Stamp’. Select it by pressing the ‘OK’ button and use the ‘Up’, ‘Down’ and ‘OK’...
  • Page 12 EV Bias (Exposure) You can adjust the exposure you require. For example, during the winter you may want to change the exposure to account for the darker days. To change the exposure, enter the menu and use the ‘Up’ and ‘Down’ buttons to highlight ‘EV Bias’. Select it by pressing the ‘OK’ button and use the ‘Up’...
  • Page 13 Time Setup It is important to set the date and time, so that any accidents or incidents recorded are saved with the appropriate time and date information attached to them. To set the date and time, enter the menu and use the ‘Up’ or ‘Down’ button to highlight ‘Time Setup’. Select it by pressing the ‘OK’ button and use the ‘Up’...

  • Page 14: Format Sd Card

    Backlight Off You can control whether you would like the LCD to be on or off whilst you are driving. If you switch it on, it will display what it is recording at all times. If you switch it off, it will display what it is recording for a short period after you first power on your DX20 but will then switch off automatically.
  • Page 15 DX20 will display one last warning message ‘Caution! Delete All?’. Use the ‘Up’ and ‘Down’ buttons to make your final selection and press the ‘OK’ button. To exit the menu, press the Menu/Return button, button #1. User tip: Please remember that if you Format an SD card, any data or video recorded and saved to that card will be permanently deleted.

  • Page 16: Over Speed Reminder

    Over speed reminder Use this function if you would like your DX20 to alert you if you exceed the speed limit you select. Enter the additional settings menu by pressing the Menu button twice and use the ‘Up’ or ‘Down’ buttons until you highlight ‘Overspeed remind’...
  • Page 17 Speed trap alerts Use this setting to switch GPS speed trap alerts on or off. Enter the additional settings menu by pressing the Menu button twice and use the ‘Up’ or ‘Down’ buttons until you highlight ‘Speed unit’ and press ‘OK’. Next, use the ‘Up’ or ‘Down’ buttons to highlight your preferred setting and press ‘OK’ to make your selection and return to the menu.

  • Page 18: Park Mode

    Camera operation Your Aguri DX20 DVR has been designed primarily to function as a DVR, to record the road ahead and to save any incidents or accidents you may be involved in. However, in addition to the DVR function, your DX20 can also be used to take still photographs.

  • Page 19: Technical Specification

    4M Pixels Image Format JPEG Memory Card Supports Micro SD card up to 64GB MIC/Speaker Built-in Backlight Off ON/OFF Auto Power Off OFF/1 Minute/3 Minutes/5 Minutes USB Port USB2.0 Battery Capacity 250MAH 3C Aguri ViewBox PC software Windows XP2/Vista/Windows 7/Windows 8...

  • Page 20: Disposal Of Old Electrical & Electronic Equipment

    Disposal of Old Electrical & Electronic Equipment - applicable in the European Union. If you see this symbol on a product or its packaging, it indicates that the product should not be treated as normal household waste. If you see this symbol on any product or packaging it should be handed over to an applicable collection point for the recycling of electrical equipment.

  • Page 21: Service Under Warranty

    Try visiting the FAQ section at www.aguriworld.co.uk. We find that most issues can be resolved there. If you are still experiencing problems, your Aguri Speed Vision DX20 DVR comes with a standard 12 month warranty. To return your unit under...
