ARF35
User Guide
PRESENTATION
PRODUCT POWER SUPPLY
SERIAL LINK WIRING
MODEM / DTE RS232
DCE RS232
RS485 wiring
RS485 interface activation
RADIO COMMUNICATION
Communication channels
RSSI reading
WORKING MODE
Addressed mode
Serial commands
Set of commands
Description of the registers
Configuration of the serial interface
MODBUS compatibility
Sending a serial command using HYPERTERMINAL
SPECIFICATIONS
ANNEX 1 - Firmware updates
