Docomo L-01G Instruction Manual

Hide thumbs Also See for L-01G:
Table of Contents

Advertisement

Quick Links

Download this manual
L-01G
INSTRUCTION MANUAL
'15.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L-01G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Docomo L-01G

Summary of Contents for Docomo L-01G

  • Page 1 L-01G INSTRUCTION MANUAL ’15.2...
  • Page 2 In this manual, the operations are described by illustrations and marks to ensure the correct usage of this terminal. • Please note that "this terminal" indicates "L-01G" in this manual. • Images and illustrations used in this manual may differ from the real images displayed on this terminal or differ from the real product.

  • Page 3: Supplied Accessories

    ■ L-01G Terminal ■ Back cover L39 Up Manual (with warranty) (Japanese) ■ SSID/Security sticker For options (sold separately) compatible with this terminal, visit DOCOMO website. https://www.nttdocomo.co.jp/product/option/ (in Japanese only) ■ USB Cable L03 ■ Converter Cable for Charging L02 Contents/Precautions...

  • Page 4: Table Of Contents

    Before Using this Terminal …………… 30 Setting Network ……………………………………… 80 Part Names and Functions ………………………… 30 Advanced Settings of Wireless LAN …………… 82 Using docomo mini UIM card ……………………… 32 Setting Router ………………………………………… 91 Attaching/Removing Battery Pack ……………… 35 Managing System …………………………………… 96 Charging …………………………………………………...
  • Page 5 Appendix/Troubleshooting …………… 119 L-01G Connection Manager Menu Item/Setting Item List ………………………………………………… 119 Setting Menu Item/Setting Item List …………… 127 Troubleshooting ……………………………………… 131 Error message ………………………………………… 138 Warranty and After-Sales Service ……………… 141 Updating Software …………………………………… 144 Resetting this Terminal …………………………… 147 Main Specifications …………………………………...

  • Page 6: About Usage Of This Terminal

    (http://www.mopera.net (in Japanese only)). ( → P144) You can use Internet service provider of other • This terminal uses only docomo mini UIM card. companies. In that case, pay usage fee directly Bring your docomo nano UIM/UIM/FOMA card to to the provider you use. Consult a provider a docomo Shop to exchange it.

  • Page 7: Main Functions

    • Depending on the connection destination, user Main Functions authentication (ID and password) may require while attempting access. In that case, enter ID This terminal can be connected to more than and password and connect. one wireless LAN terminal via wireless LAN •...

  • Page 8: Wireless Lan

    Wi-Fi 5 GHz band, the DFS function device supports WPS"). activates and the terminal automatically • Use L-01G Connection Manager to restrict changes to another channel in the Wi-Fi 5 the number of devices available to connect. GHz band where there is no interference.

  • Page 9: Public Wireless Lan

    This is referred to as Xi data communication (LTE) or FOMA data DFS check in this manual. communication (3G), such as docomo Internet DFS check also activates when you turn connection service of mopera U, speed of data...

  • Page 10: Safety Precautions

    * Only part of the available settings can be ■ These precautions are intended to protect set up by L-01G Connection Manager. you and others around you. Read and follow them carefully to avoid injury, damage to Charging Mobile Device the product or damage to property.
  • Page 11 Precautions for Battery Pack ………………… P15 (prohibition). Precautions for Adapter, USB Cable, Converter Cable for Charging and cradle ………………… P17 Precautions for docomo mini UIM card …… P20 Denotes not to disassemble. Precautions for Using near Electronic Medical Equipment …………………………………………… P20 Material List …………………………………………...

  • Page 12: Precautions For This Terminal, Battery Pack, Adapter, Usb Cable, Converter Cable For Charging, Cradle And Docomo Mini Uim Card (Common)

    Battery Pack, Adapter, USB Cable, Fire, burns, injury, or electric shock Converter Cable for Charging, Cradle may result. and docomo mini UIM card (common) Do not get wet on charging terminal and external connection terminal with DANGER liquids such as water, drinking water, pet urine, sweat, etc.
  • Page 13 Do not let charging terminal and If the equipment starts giving off a external connection terminal touch strange smell, overheats, becomes any conductive metal such as metal discolored or deformed during use, piece, pencil lead, etc. Also do not charging or in storage, immediately put any of them inside.

  • Page 14: Precautions For This Terminal

    Accidental swallowing, injury or docomo mini UIM card insertion slot electric shock may result. of this terminal. Fire, burns, injury, or electric shock Be careful especially when using this may result.
  • Page 15 Follow the instructions when using Turn off this terminal in places near this terminal inside medical facilities. high precision electronic devices Power off this terminal in places or devices using weak electronic banning the use of it. signals. Electronic devices or electronic Electronic devices may be adversely medical devices may be adversely affected by reasons such as...
  • Page 16 When the display is accidentally If the display part is accidentally broken, be careful of broken glass broken and liquid crystal leaks out, or exposed internal parts of this do not make the material contact terminal. with your skin of face or hands. Since the plastic panel is used on It leads to blindness or skin problems.

  • Page 17: Precautions For Battery Pack

    Itching, rash or eczema may be Precautions for Battery Pack caused depending on your physical conditions or predisposition. If an ■ Confirm the battery type from the label of abnormality occurs, stop using this the battery pack. terminal immediately, and then seek Display Battery type medical attention.
  • Page 18 Blindness may result. may result. Tape the connector to isolate the battery pack and bring it WARNING to a docomo Shop or follow the local disposal regulations. Stop using when transformation or damage is found caused by dropping. Do not use or charge the wet battery Fire, explosion, getting heated or pack.

  • Page 19: Precautions For Adapter, Usb Cable, Converter Cable For Charging And Cradle

    When battery pack leaks liquid inside, Precautions for Adapter, USB do not touch your skin, such as your Cable, Converter Cable for face or hands. Charging and cradle It leads to blindness or skin problems. If such liquid gets into your eyes or mouth, if it adheres to your skin WARNING or clothing, please rinse with clean...
  • Page 20 Do not touch the adapter, USB Cable When this terminal or cradle is or Converter Cable for Charging connected with an adapter, do not during thunder. subject excessive force to any Electric shock may result. direction. Fire, burns, injury, or electric shock may result.
  • Page 21 Use the specified fuse when the fuse When removing USB Cable or of DC adapter blows. Converter Cable for Charging, do not Fire, burns, or electric shock may pull the cable with excessive force. result. Refer to the manual for Instead, hold the connector to pull.

  • Page 22: Precautions For Docomo Mini Uim Card

    Operations of electronic medical equipment may be adversely affected Precautions for docomo mini by radio waves. UIM card CAUTION Be careful not to touch the edge of docomo mini UIM card when removing it. Injury may result. Contents/Precautions...
  • Page 23 Patients using electronic medical Follow the instructions when using equipment other than implanted this terminal inside medical facilities. cardiac pacemakers or implanted defibrillators (using outside medical facilities for treatment at home, etc.) should check the influence of radio waves upon the equipment by consulting the manufacturer.

  • Page 24: Material List

    Material List Part Material/Surface Treatment ■ L-01G Terminal/Back Cover L39/Battery docomo Metal STS304, Ni/Plated Pack L23 mini UIM part coating card slot Part Material/Surface Terminal Corson Alloy Treatment Mold External case (side) PC/paint docomo mini UIM card Power button PC, gum/paint...

  • Page 25: Handling And Care

    This terminal, battery pack, adapter, USB Cable, Converter Cable for Charging and Label Synthetic paper/ docomo mini UIM card are not waterproof. laminate coating Do not use them in places with high humidity ■ Converter Cable for Charging L02 such as a bath or where rain may get it wet.
  • Page 26 PCBs and battery pack may be DOCOMO assumes no responsibility for the damaged or malfunction. loss of any of your data. Also, if an external connection device ■...
  • Page 27 ■ It is normal for this terminal to become Notes about Battery Pack warm during use. You can continue using without problems. ■ Battery pack is a consumable supply. ■ Do not use this terminal without its back Battery life varies depending on usage cover attached.
  • Page 28 • Near ordinary phone or TV/radio. mini UIM card clean. ■ Note that the adapter, USB Cable and ■ Clean the docomo mini UIM card with a dry, Converter Cable for Charging may become soft cloth (lens cleaning cloth), etc.
  • Page 29 Malfunction may result. - For using WLAN overseas, point of use etc. ■ Do not insert docomo mini UIM card into this may be restricted depending on country. terminal with labels or stickers attached on.
  • Page 30 "docomo Information Center" on the back cover of this manual for Available channels vary by the country. crosstalk avoidance, etc. (e.g. partition For use in an aircraft, contact the airline setup).
  • Page 31 Caution ■ Do not use a modified terminal. Using a modified terminal results in violating Radio law/Telecommunications Business Act. This terminal has been complied with the rules related to technical standard of wireless equipment stipulated by Radio law, as well as technical standard of device stipulated by Telecommunications Business Act.

  • Page 32: Before Using This Terminal

    Before Using this Terminal Power button: Part Names and Functions Press two seconds or longer to power on/off. Press shortly to turn on/off the display. LED indicator: Lighting red: charging this terminal Lighting green: finished charging Flashing red: starting charging of mobile device Display (touch panel) External connection terminal: Attach the supplied USB Cable L03, Converter...
  • Page 33 Wi-Fi by using multi antennas. Back cover You can see docomo mini UIM card slot after removing the back cover and the battery pack. Antennas are built in this terminal. Covering around the antenna by the hand may affect the quality.

  • Page 34: Using Docomo Mini Uim Card

    Attaching Using docomo mini UIM card Insert docomo mini UIM card docomo mini UIM card is an IC card stores a customer's information such as a phone underneath the docomo mini UIM number. In this terminal, data communication card slot guide in the direction of...
  • Page 35 Push out 2 to 3 mm of the docomo UIM card. mini UIM card in the direction of • Do not touch the IC of docomo mini UIM card and be careful not to get injured. while pressing the lock by your •...
  • Page 36 Fail three times in a row to prevent unauthorized use of docomo mini UIM card by a third party. When you have set the PIN1 code for docomo Enter PIN Unlock code mini UIM card, data communication is not Enter it from setting page ( → P97) available without PIN1 code verification.

  • Page 37: Attaching/Removing Battery Pack

    If you have subscribed at a place other than a docomo Shop, bring your identification document (driver's license, etc.), this terminal and docomo mini UIM card to a docomo Shop, or Back cover Groove contact "General Inquiries" provided on the back cover of this manual.
  • Page 38 Align the battery pack with the metal Confirm the orientation of the back terminals of this terminal and attach cover and align it with the main unit, it in the direction of with " " on press the arrow parts one by one to the battery pack facing up, and insert close the back cover firmly in the direction of...
  • Page 39 Put your finger in the groove of this Removing terminal against the battery pack and press in the direction of a. Lift Note up in the direction of and remove it • Make sure to turn off this terminal before in the direction of removing the battery pack.

  • Page 40: Charging

    ■ Do not charge this terminal for a prolonged Charging time with its power turned on. • If you charge this terminal for a prolonged time ■ Battery Charge with its power turned on, the battery pack will start • Do not apply excessive force when inserting supplying power to this terminal after finishing or pulling out the connector.

  • Page 41: Charging With Ac Adapter

    ■ AC adapter Charging with AC Adapter • For details, refer to the instruction manual of AC adapter 03/04/05/L02/L03/L04 It describes how to charge this terminal with (optional). AC adapter 05 (optional). • AC adapter can be used from AC 100 V to To AC 100 V outlet 240 V.

  • Page 42: Power On/Off

    When charging is completed, remove Power On/Off the power plug of AC adapter from the power outlet Power On Remove the microUSB connector of AC adapter from this terminal When the power is off, press the horizontally power button for over two seconds For first time activating, "Startup Wizard"...

  • Page 43: Viewing Display

    Xi area or FOMA area starts. When displayed on the screen (press the power connected to network, the mobile network name ("NTT DOCOMO" in Japan) is displayed. button when it is not displayed ( → P45)). Also when it is powered on, connection with a b c de f g h compatible Wi-Fi devices is available.
  • Page 44 Connected network type : Charging : LTE network connected Flashing : Battery is almost empty. Please charge. : 3G network connected (HSDPA/ HSUPA, W-CDMA) • While power save mode is activated ( → P103), the icon is displayed as : GSM network connected (green) / (low: orange).
  • Page 45 ■ Example of state display Note It displays information such as the charging • Not like other smart phones, L-01G shows state of the battery pack, the state of Wi- the current time only when it can receive the Fi function and network name (the following time information from the Internet.

  • Page 46: Basic Operations

    Basic Operations Operations of touch panel The following operations are available on the touch panel. How to Use Touch Panel • Tap: Touch the screen lightly This terminal adopts touch panel which allows • Touch and hold: Touch the screen for over one second you to operate by touching the panel.
  • Page 47 ( → P101). For detailed settings, terminal is launched. use L-01G Connection Manager on PC to set up. For details, refer to "Settings" ( → P72). Press and hold "...

  • Page 48: Entering A Character

    Input switch key Entering a Character Switch number/alphabet input. Input switch key Operate on the touch panel of this terminal to Switch number/symbol input. input the password (security key), etc. Tap keyboard area to input characters The selected characters are input in the text box.

  • Page 49: Setting Up

    Setting up Setup L-01G Connection OS/device Manager Using L-01G Connection Manager, you can operation change the wireless LAN or settings of each Mac OS X 10.8.5 64bit ○ function of the Wi-Fi compatible device you use depending on your usage environment.
  • Page 50 Using Wi-Fi Compatible Device OS/device iPhone/iPod touch/iPad • For Wi-Fi compatible devices which support Nintendo DS IEEE802.11a/n/ac (5 GHz) or IEEE802.11b/g/n (2.4 GHz), you can connect it with this terminal PlayStation ® Vita "PS Vita" and start use. ® "PlayStation ®...
  • Page 51 Mac OS X 10.8.5 64bit Japanese/English Mac OS X 10.7.5 32bit/64bit Japanese/English * Only Mac equipped with Intel CPU is supported. Data communication is possible when charging with USB Cable. For operating environment of the latest information, confirm DOCOMO website. Setting up...

  • Page 52: Setup Flow

    ・For Windows ( → P64) ・ Wi-Fi compatible device which supports ・For Mac ( → P68) Wi-Fi ( → P60) Setting up with L-01G Connection Manager ・For provider setting ( → P77) ・For public wireless LAN setting ( → P78) Connecting to the Internet...

  • Page 53: For Wireless Connection

    Note For Wireless Connection • To change the settings of this terminal, Setting procedures are different depending on the connect to a PC and change the settings Wi-Fi compatible device you use. Here it describes first before connecting to other Wi-Fi setting procedures of each terminal below.
  • Page 54 ■ Confirming SSID/Password (Security Key) Note On the Home screen, tap "Connection • For those settings, set them up when guide" → "Manual input" connecting each terminal for the first time. Once it is set up, auto connection starts SSID and password (security key), etc. are after turning on this terminal.
  • Page 55 ■ SSID/Password (Security Key) Connecting Wi-Fi Compatible You can use two SSID on this terminal. For Device Supports WPS default SSID, refer to the following. Primary SSID: Note Use the "SSID:" written on the sticker. It can • Setting method is different depending on be used in wireless LAN security mode which the Wi-Fi compatible device.
  • Page 56 (L-01G Connection Manager) connected Click "WPS" on the setting page Tap "WPS" on this terminal (L-01G Connection Manager) you logged in, select "PIN(From AP)" in the "WPS type" field Click "Create" in the PIN field on the WPS setting page and create WPS PIN An 8-digit WPS PIN code is displayed.

  • Page 57: Connecting Windows Pc

    Press the power button of this PIN field of WPS terminal for over two seconds setting page on the setting page (L-01G Connection Manager) you This terminal is turned on and Wi-Fi function is turned on. logged in, click "Start"...
  • Page 58 On the desktop screen, swipe from Enter the password (security key) the right side of the screen (point set in this terminal ( → P52) in the top right of the screen in case of "Network security key" and click "OK" mouse) →...
  • Page 59 Click the displayed SSID of this For Windows 7 terminal (default setting: "L01G_ XXXXXXXX_A" → P52) and click Press the power button of this "Connect" terminal for over two seconds This terminal is turned on and Wi-Fi function is turned on. Turning on Wi-Fi function on PC Click (Start) →...
  • Page 60 Select "Wi-Fi" and click "Turn Wi-Fi On" Connecting Mac Wi-Fi function on Mac is turned on. The setting procedures in Mac OS X 10.10.1 described here is an example when the security mode of this terminal is set to the default setting of "WPA/WPA2-PSK(AES+TKIP)"...
  • Page 61 Click "Network Name" and select Enter the password (security key) the displayed SSID of this terminal ( → P52) set in this terminal in (default setting: "L01G_XXXXXXXX_ "Password", select "Remember this A" → P52) network" and click "Join" Setting up...

  • Page 62: Connecting Android

    Connecting Android Connecting iPhone / iPod touch / iPad The setting procedures in Android described here is an example when the security mode The setting procedures described here is of this terminal is set to the default setting an example when the security mode of this of "WPA/WPA2-PSK(AES+TKIP)"...

  • Page 63: Connecting Nintendo Ds

    Enter the password (security key) Connecting Nintendo DS ( → P52) set in this terminal, touch " The setting procedures in Nintendo 3DS 決定 (OK)" described here is an example when the security "OK" mode of this terminal is set to the default setting of "WPA/WPA2-PSK(AES+TKIP)"...

  • Page 64: Connecting Psp

    Touch the displayed SSID of this Select "Infrastructure Mode" and terminal (default setting: "L01G_ press " ○ " button XXXXXXXX_A" → P52) Select "New Connection" and press Enter the password (security key) " ○ " button ( → P52) set in this terminal, touch Select "Scan"...

  • Page 65: For Usb Connection

    Select "Easy" and press the direction For USB Connection key of " " button Confirm the connection name Attaching to/Removing from PC displayed and press the direction key of " " button Use the supplied USB Cable L03 to attach to a Confirm the setting list displayed and •...
  • Page 66 • Always use the administrator's user account When connecting for the first time after to perform the installation. Installation with purchase, setup screen of L-01G driver is other account causes errors. displayed automatically via zero installation • For the operation of administrator setting, only for Windows version.
  • Page 67 This terminal is turned on and Wi-Fi function is click "CD Drive (X:) L01G" (X part differs turned on. depending on the PC). Click "CD Drive (X:) DOCOMO" (X part Select "English (United States)" and differs depending on the PC) on the click "Next"...
  • Page 68 Select "I accept the terms of the Select "Optimize communication license agreement" and click "Next" settings (W-TCP Setting) (Recommended)" and click "Next" When "Welcome to the InstallShield Wizard for docomo L01G" is displayed, Click "Finish" click "Next" Installation starts. Setting up...
  • Page 69 Click each device display and confirm Confirming the Installed L-01G Driver the installed driver name Confirm if L-01G driver is set in PC. Connect • Network adapters: docomo L01G USB NDIS L-01G with a PC via the supplied USB Cable Device beforehand.
  • Page 70 Click (Finder) → "Device" → "L01G" Note → "L01G USB Driver" • After inserting this terminal to the USB port of PC, if this terminal is not recognized, insert with another USB port and confirm it. Depending on the PC, this terminal may not be recognized with certain USB ports.
  • Page 71 Click "Continue" Click "Install" Authentication screen is displayed. Click "Continue" Enter the Mac name (user name) and password, and click "Install Software" • When you agree on "Software License Agreement", click "Agree". • When "Change Install Location" screen is displayed, select an installation destination and click "Continue".
  • Page 72 Click "Continue Installation" Confirming the Installed L-01G Driver Installation starts. "About This Mac" on apple menu → "Overview" tab Click "System Report..." Click "Restart" on the installation Click "USB" and check that "docomo complete screen L01G" is displayed PC restarts automatically. The installation is completed.

  • Page 73: Setting Each Item

    Setting Each Item Activate Web browser on the PC connected by Wi-Fi and display the setting page of this terminal. Change the settings according to the usage environment of settings on this terminal. • It can also be set via USB tethering on a PC. In that case, set "USB tethering"...

  • Page 74: Settings (Web Browser)

    Logging in to the Setting Page this terminal, some items are restricted settings (L-01G Connection Manager) of L-01G Connection Manager. Also, while setting with L-01G Connection Manager, the operation from the menu of this terminal may be Activate Web browser on the PC connected disabled.
  • Page 75 Enter key screens or items may not be able to "Login" screen is displayed. display. • When L-01G driver is installed on the * In browser settings, set Cookie to valid Windows PC, double click the shortcut of (Save, accept).
  • Page 76 Enter the login password (default: ■ When setting PIN1 code PIN1 code confirmation screen is displayed. "1234") in "Password" field and click Click "Refresh", unlock PIN1 code on this "Login" terminal and log in again. • "Admin" is displayed in "Username" field. You cannot change the setting.
  • Page 77 "Status" screen. Help is displayed. Top menu Note Click a menu item and switch to the setting • In L-01G Connection Manager, only single page. byte alphanumeric characters, part of You can select the following items. single byte symbols (~!@#$%^&*-_:,./;|()<>{} •...

  • Page 78: Confirming Connection State Or Setting State Of This Terminal

    Network name : The mobile network name being * When docomo mini UIM card is not inserted, connected is displayed. this item is not displayed. Also, "-" is displayed FOMA/Xi signal : The current reception level is in "Phone number"...

  • Page 79: Setting Provider

    U, the following settings are not range. necessary. • Up to 99 characters of single byte alphanumeric characters, symbol • For details about mopera U, visit DOCOMO (~!@#$%^&*-_:,./;|()<>{}[]+=`"'?\) and single website. byte space Click "PROVIDER" on the top menu...

  • Page 80: Setting Public Wireless Lan

    Authentication Setting Public Wireless LAN Select an Authentication for the access point. • None You can connect to wireless LAN router at • PAP home or at work, or connect to the public • CHAP wireless LAN service outside to access to the When registering a new access point, Internet.
  • Page 81 ■ When using ■ When setting to WEP Display mode Password Switch SSID display settings. Enter password (security key) for WEP. • Used networks: Displays all the access 5, 10, 13 and 26 single byte alphanumeric points. characters can be input as a key. •...

  • Page 82: Setting Network

    When selecting an access point Setting Network from "Searching result", enter the password (security key) Selecting an Access Point Click "Apply" to save the settings You can specify the mobile network of the access point. ( → P113) Displaying Data Communication Amount Data amount used for communication is displayed.
  • Page 83 For the following case, the usage amount is reset automatically. • First of each month 0 o'clock • When replacing docomo mini UIM card • When resetting this terminal Display mode • Used data only: Data communication amount is displayed on this terminal.

  • Page 84: Advanced Settings Of Wireless Lan

    Frequency band Advanced Settings of Set the frequency band you use. Wireless LAN • 2.4GHz • 5GHz SSID/Password Display on modem Note Set whether to display the password (security key) in "Basic setting" of the • When using Wi-Fi function overseas, confirm setting menu on this terminal.
  • Page 85 Wi-Fi MIMO "Wi-Fi mode" is set to "11n only" or "11b/g/ Select whether to use MIMO function. n". ■ 5GHz setting • On Wi-Fi mode • Off ■ 2.4GHz setting Select an operation mode of wireless LAN. Wi-Fi Channel • 11a only •...
  • Page 86 Setting Security Mode of Note Wireless LAN • It takes about one minute for DFS check. While DFS check is in progress, the network is temporarily disconnected. After confirming Click "Wi-Fi" of the top menu that there is no interference, the terminal is reconnected automatically.
  • Page 87 Security(Encryption type) ■ When setting to WPA2-PSK(AES) Setting security mode of wireless LAN. Password • Open(None) Enter an 8 to 64 characters for password • Auto(WEP) (security key) of WPA2. • WPA2-PSK(AES) • For key of 8 to 63 characters, single byte •...
  • Page 88 Max number of clients Setting Secondary SSID Select the number of devices connected to this terminal. Use secondary SSID function to connect the AP isolation Wi-Fi compatible devices with different security Set whether to allow the communication modes at the same time. For Wi-Fi compatible between devices connected to the same devices supporting WEP or Open, such as a SSID.
  • Page 89 Set up each item in setting screen Setting WPS Function Note • When "Security(Encryption type)" ( → P85) is set to "Auto(WEP)", WPS function cannot be used. • When the top number of clients set in primary SSID is displayed, WPS cannot be used. Click "Wi-Fi"...
  • Page 90 ■ When using Setting MAC Address Filter WPS type Select a type of WPS function. Click "Wi-Fi" of the top menu • Button: Use WPS button to connect. • PIN(From AP): PIN code (8 digits number) Click "MAC address filter" of the sub for WPS is generated in this terminal, enter menu the PIN code in the terminal you want to...

  • Page 91: Confirming Connected Client

    ■ When allowing or rejecting Edit Input field of MAC address is displayed. • : Save to permission list of MAC address filter. Enter the specified MAC address of this terminal. • : Save to rejection list of MAC address filter. Up to 10 MAC addresses can be specified.
  • Page 92 DHCP server Setting DHCP Function Select whether to use DHCP function. • On Click "Wi-Fi" of the top menu • Off Start IP address Click "DHCP" of the sub menu Set the smallest IP address assigned to this terminal. Set up each item in setting screen End IP address Set the biggest IP address assigned to this terminal.

  • Page 93: Setting Router

    DHCP lease time (min) Setting Router Set IP address lease time. • 30 • 60 Using Firewall • 120 • 240 Use Firewall function to prevent unauthorized • 720 access to the Internet. Also you can set IP • 1440 address filter.
  • Page 94 Firewall Protocol Set valid or not. Select a Protocol to apply. When "TCP", "UDP" • On: Set Firewall to valid. or "Manual" is selected, "Port number" field is • Off: Set Firewall to invalid. displayed. IP address filter list • All The setting list of the registered Firewall •...
  • Page 95 Abandoning Ping from WAN Side Setting DMZ It prevents IP information leak of both this One of the devices connected to network on terminal and the terminal of LAN side by this terminal can be set to DMZ. abandoning Ping request access from WAN The packet sent from the Internet side to the side and not answering.
  • Page 96 ■ When setting Setting Port mapping Click "Add". Set to allow (port convert) about the Forward the connection request from "From" communication starts from the Internet. automatically to the certain terminal (IP address and port number) of "To". Click "ROUTER" of the top menu From Click "Port mapping"...
  • Page 97 Set up each item in setting screen VPN connection This terminal provides VPN pass-through function. VPN pass-through function allows the client connected to this terminal supports connection via external VPN. PPTP, L2TP and IPsec are VPN protocol supported by this terminal. Also, this terminal provides VPN multiple pass- through (to multi clients at the same time is UPnP...

  • Page 98: Managing System

    When changing lock valid/invalid (PIN1 code input valid/invalid), enter the PIN1 code of Set up this function to lock network docomo mini UIM card. communication and the password (PIN1 code) Remaining times is required to enter when powering on this The number of available input times of PIN1 terminal.

  • Page 99: Changing Password

    "New PIN1 code" in "Confirm PIN1 code" field to confirm Click "Apply" to save the settings Current PIN1 code Enter the PIN1 code set in docomo mini UIM card. New PIN1 code Enter a new PIN1 code. Settings (Web browser)

  • Page 100: Changing Login Password

    Set up each item in setting screen Confirm PIN1 code Enter the same PIN1 code as you entered in "New PIN1 code" to confirm. Remaining times The number of available input times of PIN1 code is displayed. ( → P34) Click "Save"...

  • Page 101: Backing Up/Restoring The Setting Data

    Backup to file Backing up/Restoring the Click "Backup" and specify a file name Setting Data ("L01G_webcm_config.cfg" as default), save the current settings. The setting data of setting page can be saved * Depending on the browser you use, file in PC. Also, the setting data you saved can be name may not be able to specify.
  • Page 102 Initializing the Settings Confirming Version Information All the settings of the setting page can be Click "SYSTEM" of the top menu initialized to the status at the time of purchase. Click "Version" of the sub menu Click "SYSTEM" of the top menu Firmware and version information of this Click "Reset"...

  • Page 103: Settings (Setting Menu On This Terminal)

    Settings (setting menu on this terminal) "Add" Setting on the Display of this Terminal (Setting Menu) For details about the operations of setting menu, refer to "Menu Operations on this Terminal" ( → P45). Provider From the Home screen, " "...
  • Page 104 Wi-Fi Note • The registered profile name cannot be From the Home screen, " " changed. When changing profile name, delete the Display the setting menu. profile and register again. Tap "Wi-Fi" • The selected profile is displayed as (blue). (gray) displayed at the right edge of the profile to select the profile.

  • Page 105: Settings (Setting Menu On This Terminal

    Wi-Fi power save Set WPS to ON/OFF and set WPS type. The terminal saves battery by adjusting the signal strength automatically depending on Power save setting the Wi-Fi communication status. • When Wi-Fi turns off, operate the devices to reconnect as required. From the Home screen, "...

  • Page 106: Settings (Setting Menu On This Terminal

    Power saving items ( → P103) Displaying Data Usage Amount Estimates of network data usage can be displayed. You can also make settings by L-01G Connection Manager. ( → P80) From the Home screen, " " Display the setting menu. "Mobile Network"...

  • Page 107: Settings (Setting Menu On This Terminal

    "Mobile Data usage display" Searching Network You can also search networks with L-01G Connection Manager. ( → P113) From the Home screen, " " Display the setting menu. "Mobile Network" "Searching network" Display mode Switch the display mode of network data usage.

  • Page 108: Settings (Setting Menu On This Terminal

    Tap the access point network from list to access to the mobile network. The same setting can be operated in • : 3G mobile network L-01G Connection Manager. ( → P78) • : GSM/GPRS mobile network From the Home screen, " "...

  • Page 109: Settings (Setting Menu On This Terminal

    "PWLAN" Turn on "PWLAN". Select and tap an access point on the list to connect. When selecting an access point being connected, the connection is Public WLAN disconnected. Set whether to connect to the public Tap "Refresh" to search the available access wireless LAN.

  • Page 110: Settings (Setting Menu On This Terminal

    System Note • This terminal supports ASCII 128 characters From the Home screen, " " (single byte alphanumeric characters, and a part of symbols). The other characters Display the setting menu. (double byte characters, etc.) are displayed "System" as the special characters. Though the characters are not displayed correctly, connection is possible.

  • Page 111: Settings (Setting Menu On This Terminal

    "System" → "Basic information" • ON/OFF is toggled each time when tapping "USB tethering". Phone number The phone number of docomo mini UIM card is displayed. Set USB tethering to valid. Set USB tethering to invalid. Settings (setting menu on this terminal)

  • Page 112: Settings (Setting Menu On This Terminal

    "SSID/Password Display on Display the setting menu. modem" is set to "On" ( → P82) in "User Guide" L-01G Connection Manager. * Secondary SSID is only displayed when "Secondary SSID" is set to "ON" ( → P86) in L-01G Connection Manager.

  • Page 113: Settings (Setting Menu On This Terminal

    Connection manager Explanations about an overview of the Connection Manager. Power save setting Explanations about the operation of Power save setting. Settings (setting menu on this terminal)

  • Page 114: Overseas Use

    Data communication via pack use this terminal in the service areas conducted by communication communication is able to use. overseas operators affiliated with DOCOMO. ■ Available mobile network Note This terminal is placed in class 5. You can use it in LTE mobile network, 3G mobile •...

  • Page 115: Confirming Before Using

    Log in to the setting page 03/04/05/L02/L03/L04 (optional). ■ Charges For details, refer to "Logging in to the Setting Page (L-01G Connection Manager)" For overseas use, fees are charged differently ( → P72). (packet communication fee) from the charge in Japan. For details, refer to "Mobile Phone Click "MOBILE NETWORK"...
  • Page 116 ■ Setting Network Mode menu and set the items Log in to the setting page For details, refer to “Logging in to the Setting Page (L-01G Connection Manager)” ( → P72). Click "MOBILE NETWORK" on the top menu Click "Network mode" on the sub...
  • Page 117 Click "Apply" to save the settings ■ Inquiries Note • If this terminal or docomo mini UIM card is lost or stolen overseas, contact DOCOMO • Using overseas immediately from your current location and - Some services are not able to use carry out the procedures to suspend usage.
  • Page 118 After Returning to Japan When you return to Japan, this terminal automatically connects to docomo mobile network. If it is unable to connect, change the following settings. • Set "Searching network" to "Auto". ( → P105) Overseas Use...

  • Page 119: Charging Mobile Devices

    Charging Mobile Devices Insert the microUSB connector of Charging Mobile Devices the Converter Cable for Charging into the external connection terminal You can charge another mobile device using the power supply function of this terminal. of this terminal with the USB mark facing up How to Connect Insert the USB connector of the USB...
  • Page 120 Select charging mode on the display • 60% • 40% of this terminal and tap "OK" • 20% Charging of the mobile device starts. • 0% (Only displayed when "Charging Only" is displayed and the LED indicator is is selected) flashing red for five seconds.

  • Page 121: Appendix/Troubleshooting

    Appendix/Troubleshooting L-01G Connection Manager Menu Item/Setting Item List Menu item/ Backup/ Default value Setting range Initialize Setting item Restore Username Admin (unchangeable) Password 1234 4 to 32 characters of single byte ○ alphanumeric characters, single byte space and symbols (~!@#$%^&*- _:,./;|()<>{}[]+=`"'?\)
  • Page 122 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore Username (None) Up to 64 characters of single byte ○ ○ alphanumeric characters, single byte space and symbols (~!@#$%^&*- _:,./;|()<>{}[]+=`"'?\) Password (None) Up to 32 characters of single byte ○...
  • Page 123 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore Network LTE/3G/GSM(Auto) LTE/3G/GSM(Auto), LTE/3G, 3G/GSM, ○ mode 3G, GSM Network data usage Display Used data only Used data only, Used data with max ○ ○ mode data, Off Maximum 1 to 99 ○...
  • Page 124 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore 5GHz setting Wi-Fi mode 11a/n/ac 11a only, 11n only, 11ac only, 11a/n, ○ ○ 11a/n/ac Wi-Fi 20/40/80MHz 20MHz, 20/40MHz, 20/40/80MHz ○ ○ bandwidth SSID setting Primary SSID SSID L01G_XXXXXXXX_ Up to 32 characters of single byte ○...
  • Page 125 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore Wi-Fi Protected Setup (WPS) On, Off ○ ○ WPS type Button Button, PIN(From AP), PIN(From client) ○ ○ (None) (enter the issued PIN on Wi-Fi ○ compatible device side) MAC address filter Restrict Off, Allow, Deny...
  • Page 126 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore Primary 0.0.0.0 IP address available to DNS ○ ○ For 0.0.0.0, the IP address of DNS server provided by the operator is applied. Secondary 0.0.0.0 IP address available to DNS ○...
  • Page 127 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore On, Off ○ ○ IP address (None) 0.0.0.1 to 255.255.255.255 ○ ○ Port mapping Port On, Off ○ ○ mapping From Port number TCP TCP, UDP ○ ○ (None) 1 to 65535 ○...
  • Page 128 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore New PIN1 (None) Single byte numbers of 4 digits to 8 code digits Confirm (None) Single byte numbers of 4 digits to 8 PIN1 code digits Modify password Current (None) 4 to 32 characters of single byte password...

  • Page 129: Setting Menu Item/Setting Item List

    Setting Menu Item/Setting Item List Menu item/ Backup/ Default value Setting range Initialize Setting item Restore Provider Provider mopera U ○ ○ Profile name (None) Up to 15 characters of single byte ○ ○ alphanumeric characters, single byte space and symbols (~!@#$%^&*- _:,./;|()<>{}[]+=`"'?\) Access point (None)
  • Page 130 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore Wi-Fi Frequency band 2.4GHz 2.4GHz, 5GHz ○ ○ Primary SSID Primary L01G_XXXXXXXX_ Up to 32 characters of single byte ○ ○ SSID alphanumeric characters, single byte space and symbols (~!@#$%^&*- _:,./;|()<>{}[]+=`"'?\) Security WPA/WPA2-PSK...
  • Page 131 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore Power save setting Power save Battery : 30% Do not use, Battery : 10%, Battery : ○ mode 20%, Battery : 30% Power saving (Selected All) Wi-Fi power save, Network sleep, ○...
  • Page 132 Menu item/ Backup/ Default value Setting range Initialize Setting item Restore Mobile network Mobile Data usage display Display Used data only Used data only, Used data with max ○ ○ mode data, Off Max data (not set) 1 to 99 ○...

  • Page 133: Troubleshooting

    Is the battery dead? check items, contact "Repairs" (in Japanese ( → P39, P42) only) on the back cover of this manual or a repair counter specified by DOCOMO. Cannot Confirm the following things. charge • Is battery pack inserted correctly? ( →...
  • Page 134 Depending on the mobile device, it charging time becomes short. may not be able to charge fully. For details, visit DOCOMO website. Charging Are the supplied USB Cable L03 and time of Converter Cable for Charging L02 ■...
  • Page 135 Check item Symptom Check item Battery life Confirm the following things. docomo Is docomo mini UIM card inserted in is short ( → P38) mini UIM the right direction? ( → P32) • Has this terminal been out of the...
  • Page 136 Symptom Check item Symptom Check item This Uninstall the L-01G driver and This ■ For Windows 7 terminal connect again. terminal Click (Start) → "Control Panel" → "Programs" → is not is not ■ How to uninstall driver "Program and Features"...
  • Page 137 ■ Wi-Fi function related Symptom Check item Symptom Check item Cannot When this terminal is set to a connect security mode other than WPA/ Cannot Confirm if the Wi-Fi function on this to Wi-Fi WPA2-PSK(AES+TKIP), the same connect terminal and the Wi-Fi compatible compatible setting is necessary on the Wi-Fi to Wi-Fi...
  • Page 138 WPS function on this terminal ( → P87 If a password is set for docomo mini "Setting WPS function"), then UIM card, when this terminal is powered connect again.
  • Page 139 L03, optimization of the PC ( → P114) communication setting is necessary. It may recover after turning off this When installing L-01G driver, confirm terminal and then turning it on again. if "Optimize communication settings (W-TCP Setting) (Recommended)" is selected.

  • Page 140: Error Message

    PIN1 code is locked after Power on again, or insert the battery code entered for 3 failing entering three times pack or docomo mini UIM card again. times. in a row. Click "OK" and enter Back cover Align the back cover with the main Please enter PIN PUK in "PIN unlock code".
  • Page 141 Terminal L-01G is locked If you fail entering the because user correct PIN unlock code ten failed to input times, the docomo mini UIM Error Message Description correct PIN unlock card will be locked. Contact code for 10 times.
  • Page 142 • Checking the number of number of the number of the connection turn it on again. connected Wi-Fi devices, connection of of primary SSID on L-01G when the shortcut is primary SSID. Connection Manager. generated ( → P86) Appendix/Troubleshooting...

  • Page 143: Warranty And After-Sales Service

    Error Message Description Warranty and After-Sales Service High temperature Stop the running functions detected. Wi-Fi will or wait until this terminal Warranty be off. cools down. High temperature When the Wi-Fi connection • Be sure to receive a warranty at the time of detected.
  • Page 144 Bring your terminal to a repair counter • When, as the result of inspection, corrosion is found due to exposure to water, condensation specified by DOCOMO. Repairs are accepted or sweat, or any of the internal boards are during business hours of a repair counter.
  • Page 145 However, repairs may be refused depending on the battery pack, then bring it to the DOCOMO- the modifications. specified repair office as soon as possible. The following cases may be considered as However, note that it may not be repaired modifications.

  • Page 146: Updating Software

    Wi-Fi is connected. The NTT DOCOMO website provides • Software update (download, installation) may information about required software updates. take time. There are two methods of checking the •...
  • Page 147 • During a software update, your L-01G Confirming Software Update information (model and manufacturing numbers) are automatically sent to a software update From the Home screen, " " server managed by DOCOMO. DOCOMO shall not use this information for any purpose other "Software update"...
  • Page 148 When a message appears to show Setting Download Method there is a update notification, "Update" From the Home screen, " " "OK" "Software update" Software download starts and software is "Download setting" updated. This terminal restarts once or twice Download setting screen is displayed. during installation.

  • Page 149: Resetting This Terminal

    Resetting this Terminal Main Specifications Follow the operations below to reset this ■ Terminal terminal to the default settings. Model name L-01G From the Home screen, " " Size (H×W×D) Approx. 107mm × Approx. "System" 65mm × Approx. 20mm Weight Approx.
  • Page 150 Charging time AC adapter 03: approx. 360 Wireless IEEE 5GHz (W56), max. minutes 802.11a transmission speed AC adapter 04: approx. 250 compatible (standard) 54 Mbps minutes standard IEEE 2.4 GHz, max. transmission AC adapter 05: approx. 250 802.11b speed (standard) 11 Mbps minutes IEEE 2.4 GHz, max.
  • Page 151 FOMA HIGH-SPEED the factory default settings and with no devices area depending on the places. connected to L-01G via Wi-Fi. For FOMA area outside of both Xi area and • Charging time is an estimate of the time required...

  • Page 152: Export Administration Regulations

    ■ Battery Pack L23 Export Administration Battery type Lithium-ion battery Regulations Nominal 3.8V voltage Japan Export Control Regulations ("Foreign Exchange and Foreign Trade Law" and Nominal 4,880 mAh relevant laws and regulations) may apply to capacity this product and its accessories. U.S. Re- export Regulations (Export Administration ■...

  • Page 153: Specific Absorption Rate (Sar) Of Mobile Terminals

    The actual SAR of this terminal while operating can be well below that indicated above. This is This model L-01G complies with Japanese due to automatic changes to the power level of technical regulations and international the device to ensure it only uses the minimum guidelines regarding exposure to radio waves.

  • Page 154: Declaration Of Conformity

    Ministry of Internal Affairs and Declaration of Conformity Communications Website: http://www.tele.soumu.go.jp/e/sys/ele/ The product "L-01G" is declared to conform index.htm with the essential requirements of European Association of Radio Industries and Union Directive 1999/5/EC Radio and Businesses Website: Telecommunications Terminal Equipment http://www.arib-emf.org/index02.html...
  • Page 155 The SAR limit for wireless routers used by the European Union Directives public is 2.0 watts/kilogram (W/kg) averaged Conformance Statement over ten grams of tissue, recommended by The Council of the European Union. The limit Hereby, LG Electronics Inc. incorporates a substantial margin of safety to declares that this product give additional protection for the public and to is in compliance with:...

  • Page 156: Important Safety Information

    INTERFERENCE Important Safety Care must be taken when using the wireless Information router in close proximity to personal medical devices, such as pacemakers and hearing aids. AIRCRAFT Pacemakers Switch off your wireless device when boarding Pacemaker manufacturers recommend that a an aircraft or whenever you are instructed to minimum separation of 15 cm be maintained do so by airline staff.
  • Page 157 • Consult the dealer or an experienced radio/TV FCC Regulations technician for help. Change or Modifications that are not expressly Part 15.105 statement approved by the manufacturer could void the This equipment has been tested and found user's authority to operate the equipment. to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Part 15.19 statement...
  • Page 158 while operating can be well below the maximum Consumer Information on SAR value. This is because the device is designed (Specific Absorption Rate) to operate at multiple power levels so as to use only the power required to reach the network. In THIS DEVICE MEETS THE GOVERNMENT'S general, the closer you are to a wireless base REQUIREMENTS FOR EXPOSURE TO RADIO...

  • Page 159: Intellectual Property Right

    Apple Inc. in the • "FOMA", "mopera U", "WORLD WING", "Xi" and "Xi" United States and/or other countries. logo are trademarks or registered trademarks of NTT DOCOMO, INC. • Android is a registered trademark or trademark of Google Inc. • Microsoft ®...

  • Page 160: Unlocking Sim

    • Unlocking SIM is available at a docomo Shop. In addition to the source code, all referred license terms, warranty disclaimers and • A fee is required to unlock the SIM.

  • Page 161: Index

    Removing ……………………………………… 37 DFS Function ……………………………………… 6 DHCP ……………………………………………… 90 Display ………………………………………… 30, 41 CE …………………………………………………… 153 docomo mini UIM card ………………………… 32 Changing Login Password …………………… 98 Attaching ……………………………………… 32 Charging …………………………………………… 38 Changing Password ………………………… 97 Charging mobile devices …………………… 117 Removing ………………………………………...
  • Page 162 Error message …………………………………… 138 Overseas use European Union Directives Conformance Available Services …………………………… 112 Statement ………………………………………… 153 Confirming before Departure ……………… 113 Export Administration Regulations ………… 150 International Roaming (WORLD WING) … 112 External connection terminal ………………… 30 Searching operator …………………………… 113 FCC Regulations …………………………………...
  • Page 163 Setting Page Wi-Fi antenna …………………………………… 31 (L-01G Connection Manager) ……………… 72 WPS ………………………………………………… 87 Compatible Browser ………………………… 72 Setting Security Mode of Wireless LAN … 84 Setting up ………………………………………… 47 Confirming the Compatible Device ……… 47 Software Update Updating Software of this Terminal …… 144 Supplied Accessories ……………………………...
  • Page 164 Procedure List) (In Japanese only) on a PC * When using a PC, you need your "docomo ID/password" to access this page. * If you do not have or you have forgotten your "docomo ID/password", contact "General Inquiries" on the back of this manual.
  • Page 165 Business hours: 9:00 a.m. to 8:00 p.m. (open all year round) ● Please confirm the phone number before you dial. ● For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo Shop etc. near you on the NTT DOCOMO website. NTT DOCOMO website http://www.nttdocomo.co.jp/english/...

Table of Contents
