- Page 1 Jasmine Evolution-I Home Media Center Owner’s Manual...
-
Page 2: Safety Precautions
Never place the Jasmine EVOLUTION-I near heat sources such as radiators, fireplaces, stoves, or other appliances that produce heat. Avoid placing the Jasmine EVOLUTION-I where it will be subject to direct sunlight or low temperatures. AC extension cords are not recommended for use with this product. -
Page 3: Table Of Contents
Brief of Jasmine Introduction The Design Philosophy of Jasmine Installation Unpacking The Accessory Kit Choosing a Location for the Jasmine Evolution-I Connections Connecting to AC Power Connecting to AV amplifier or DAC device Connecting to Multi-channels amplifier Connecting to Display device... -
Page 4: Introduction
Introduction _______________________ All of us at Jasmine would like to offer thanks and congratulations purchasing Jasmine EVOLUTION-I. We sincerely believe that your Jasmine EVOLUTION-I is an intelligent purchase decision that will bring you many years of entertainment pleasure and satisfaction. While every new owner is anxious to begin trying,... -
Page 5: Installation
After carefully unpacking your Jasmine EVOLUTION-I, inspect for any shipping damage and call your dealer immediately if any is found. Do not plug your Jasmine EVOLUTION-I into any outlet if you find shipping damage. Please save all packing materials so the unit can be easily and safely shipped if the need arises. -
Page 6: Connections
Connections _______________________ This section provides instructions to connect the Jasmine EVOLUTION-I to the rest of your Audio/Video system. Below is an illustration of the Jasmine EVOLUTION-I rear panel, showing all inputs and outputs. Avoid allowing static shocks to be applied to the inputs or outputs. -
Page 7: Connecting To Multi-Channels Amplifier
S/PDIF interface. Of course, you can directly connect the FRONT analog output to your stereo amplifier from Evolution-I if you have not a DAC device. Connecting to Multi-channels Amplifier The EVOLUTION-I own all kind of decode functions, you can directly connect it to your multi-channels amplifier through 5.1... -
Page 8: Connecting To Display Device
Connecting to Display Device The Evolution-I support various display terminals. You can choice the most suitable connecting port according to your display device. If your TV only supports component connection (RGB), you can use the covert cable to connect it. -
Page 9: Turn On/Off Evolution-I
Jasmine EVOLUTION-I Home Media Center. Turn on/off EVOLUTION-I You can press the red button on right corner of remote control to power on/off the Evolution-I or press the power on/off button on the front panel of Evolution-I. -
Page 10: Using Remote Control
Using Remote Control Jasmine Evolution-I own all the features of normal computer. It equipped with keyboard and remote control for easy operation. You can finish most of entertainment operation in Media Center Software just by remote control. Power button : This button is used to turn On/Off PC. - Page 11 F.Fwd button : This button is used to generate ‘Fast Forward’ command various media applications. Prev. button : This button is used to generate ‘Previous’ command in the various media applications. Stop button : This button is used to generate ‘Stop’ command in the various media applications.
- Page 12 L. Click button : This button is used as same like [Left Click] button of the mouse. ENTER button : This button is used as same like [Enter] key of the keyboard. R. Click button : This button is used as same like [Right Click] button of the mouse.
- Page 13 Timer button : This button runs the iMON Timer. This iMON Timer feature could turn off the PC or set the alarm assigned by setup. At iMON VFD model, user can set the time for turning on the PC too. Numeric button : The numeric buttons from 0 to 9 are custom buttons that could be assigned by users.
-
Page 14: Setting Audio Output Model
Full Screen button : This button is used to generate ‘Full Screen’ command various media applications. My DVD button : This button is used to go to the DVD View directly on the Media Center. Menu button : This button is used to generate ‘DVD Menu’... - Page 15 Step two. Set up your audio configuration in Vista Media Center. Settings> General> Windows Media Center Setup> Set up Your Speakers. Step Three. Set up your audio configuration in Decode Center. 1. Run “SetCenter” as administrator...
- Page 16 2. Use right mouse button to click on the audio decoder. 3. Use left mouse button to open audio configuration menu. Then, choose your corresponding speaker environment. If you use AV amplifier or DAC to decode audio stream, Please choose “USE SPDIF” option.
- Page 17 Jasmine product. Jasmine will not pay for loss of use or inconvenience caused by the failure of a Jasmine product.
-
Page 18: Specifications
2.0, Printer,Gigabit Other Interface: Ethernet Wireless keyboard&Mouse, Remote control Accessories: Net Size 430(W) x 88.9 (H) x 440(D) mm @ 2005 Jasmine audio Block B1-5C, Digital Tech. Park, Southern Keji Rd., Shenzhen, GD, China 518057 Subject to change without notice.
