Asante 8001/P/W User Manual page 58

Add Schedule: Add Schedule setting page
The Add Event setting page and the Add Schedule setting page are basically the same except
that the Add Schedule setting page does not have the option "Trigger by" to indicate the
sources of the trigger event.
Click Save to save and activate your settings when you complete setting.
Delete: delete the event cluster setting.
Modify: modify the event cluster setting.
Note: Event response process will deliver to anyone of Input and Output. Please note that all
video messages could be large bulk file to be transmitted. Due to the limited network device
memory, the large storage file is not allowed. To make sure the alert video or image deliver
appropriately and precisely.
The following recommendation is for your reference if you want to store at least 10 seconds of
each event in any size. You may adjust the FPS/Vide size/Quality to record the alert message.
Recommend FPS for 10sec above storage
Video size
3M
1.5M
Fix Bit Rate
512K
128K
Best
Better
Fix Quality
Normal
Fast
Fastest
Note: Please note, SMTP mail, FTP server, TCP, and HTTP notification has very limited
©2007 Asante Networks Inc., All rights reserved. NetCam are registered trademarks of Asante Network, Inc.
All other names may be trademarks or registered trademarks of their respective owners. Specifications subject to change without prior notice.
3fps 4fps
D1 VGA
12 sec 12 sec N/A
24 sec 24 sec 24 sec
44 sec 40 sec 28 sec
48 sec 48 sec 50 sec
12 sec 15 sec 20 sec
20 sec 18 sec 28 sec
28 sec 30 sec 43 sec
48 sec 45 sec 60 sec
56 sec 48 sec 62 sec
30 fps 30fps
CIF QCIF
N/A
N/A
44 sec
53 sec
25 sec
25 sec
50 sec
60 sec
62 sec
58
