Asante Voyager I Quick Start Manual

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Quick Start Guide

Non-Internet Explorer Version
Thank you for choosing Asante
Voyager I megapixel IR IP Camera.
This guide offers the quickest way to install and begin using the Voyager megapixel IR IP Camera.
No advanced installation options are discussed here. For more detailed information,
please refer to the User's Manual on the supplied CD.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 1: Getting Started
Connecting to a Network
The IP camera can be connected to an Ethernet network using
the RJ-45 port as shown. Connect the camera to an Ethernet hub,
switch or a router by using a standard cable. The IP address
will be acquired automatically. Plug in the cables as shown.
Step 2: Initial Configuration
Insert the supplied CD-ROM into your CD-ROM drive.
1
Execute IP Finder.exe.
Click the Search button to scan for your IP camera.
2
Selecte Ethernet, click Submit and click Exit.
3
Step 3: Using a Web Browser
to Connect to The IP Camera
Enter the IP address of the camera in the browser address field.
1
(ex: on figure 3, "192.108.251.206")
When the login screen appears, enter your username and password.
2
The default username is root, the default password is also root.
Non-Internet Explorer Version
figure 1 figure 2
figure 3
figure 4
figure 5
Please note:
You might need to repeat the Log-in
for Quick Time.
When the username and password are confirmed, you will see the camera image.
3
As shown in figure 8. ( Allow a few seconds for video to load. )
Note: Select HTTP mode if you cannot see the image.
Continue for wireless setup.
Step 4: Basic Wireless Setting
1 Click on Setting.
On the left side menu bar, select: Network>Wireless.
2
Click on Scan. This scan the nearby wireless access points and routers.
3
4 Select the desired router for the camera to connect to by clicking on it.
5 Further down on the page, click on Show all.
Please Note: Configure the authentication type parameters to match
the wireless security settings of the router you selected in step 3.
4
2
3
5
figure 8
Click on Connect.
6
Once the status has shown Connected, you can unplug the cable
7
and mount the camera in your preferred location.
figure 6
figure 7
figure 9
Non-Internet Explorer Version
