Page 1: Service Manual
S/M No : DSD9420001 Service Manual Digital Satellite Receiver MODEL :DSD-9420 March. 2006... - Page 2 CONTENTS PRODUCT SPECIFICATION ....................2 BOM LIST..........................3 SCHEMATIC DIAGRAM ......................7 EXPLODED VIEW........................14...
-
Page 3: Product Specification
Product Specification Tuner & Service Decoder Antenna 75 ohms(UHF) Channel Coverage UHF : Ch21 - Ch69 RF Frequency Range 474 - 858 MHz Channel Bandwidth 8MHz RF Input/Output Connector IEC connector 169-2(female),diameter 9.5mm Modulator COFDM MPEG Transport Stream A/V Decoding Transport stream MPEG2 compatible Profile level... -
Page 4: Bom List
SCREW TAPPTITE TT2 BIN 3X8 MFZN 3CR C139 HCBK103KBA C CHIP CERA X7R 50V 10NF 10% 1608 97PP349500D02 FRONT PANEL DSD-9420 DAEWOO NO SLOT C140 HCBK103KBA C CHIP CERA X7R 50V 10NF 10% 1608 M2001 97FUS7090D09 BOX CARTON DSD-9420 BOX... - Page 5 BOM LIST PART CODE PART NAME PART DESC REMARK PART CODE PART NAME PART DESC REMARK C171 HCFH104ZBA C CHIP CERA Y5V 25V 100NF (-20% +80%) 1608 D125 DBAV99 -B DIODE CHIP BAV 99 / S0T23 C172 HCFH104ZBA C CHIP CERA Y5V 25V 100NF (-20% +80%) 1608 D802 D B A T 5 4...
- Page 6 BOM LIST PART CODE PART NAME PART DESC REMARK PART CODE PART NAME PART DESC REMARK Q107 T B C 8 5 7 TR CHIP BC857 LOW NOISE TR PNP R157 HRFS101JBA R CHIP 1/16 100R OHM 5% 1608 Q109 T B C 8 5 7 TR CHIP BC857 LOW NOISE TR PNP...
- Page 7 SMD XTAL QUARTZ 20M48 20PPM HC49/4H SMX 30PF R252 HRFS102JBA R CHIP 1/16 1K OHM 5% 1608 Z0013 PSMPJRP571 PCB MAIN RADIAL AS DSD-9420 EU R253 HRFS102JBA R CHIP 1/16 1K OHM 5% 1608 C313 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP...
-
Page 8: Schematic Diagram
SCHEMATIC DIAGRAM... - Page 9 SCHEMATIC DIAGRAM...
- Page 10 SCHEMATIC DIAGRAM...
- Page 11 SCHEMATIC DIAGRAM...
- Page 12 SCHEMATIC DIAGRAM...
- Page 13 SCHEMATIC DIAGRAM...
- Page 14 SCHEMATIC DIAGRAM...
-
Page 15: Exploded View
EXPLODED VIEW SCREW TAPPTITE 7273300812 TT2 RND 3X8 MFZN BK T/COVER FIX COVER TOP 97P0488500 SECC T0.5+PCM PANEL FRONT AS 97PP349500 DSD-9430 SCREW TAPPTITE 7174300811 TT2 RND 3X8 MFZN PCB MAIN FIX PCB MAIN MANUAL AS CUSHION LEG 97P4220000 EVA T4.0 COVER BOTTOM 97P0488600 SECC T=0.8... - Page 16 DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG, MAPO-GU, SEOUL, KOREA. C.P.O. BOX 8003 SEOUL KOREA PRINTED DATE: March. 2006...
