- Page 1 SRX Powered Sub-woofer series SRX POWERED SUB-WOOFER SERIES OWNERS MANUAL AND INSTALLATION GUIDE 570-SRX110PS 570-SRX112PS www.KAPTIONAUDIO.com (416) 525-2890 - 1 -...
- Page 2 SRX Powered Sub-woofer series Congratulations You now own a new Kaption Audio powered sub-woofer loudspeaker. These loudspeakers are engineered to reproduce music that is so detailed, you will hear music in a whole new dimension. State of the art technology, rigorous testing, superior materials, innovative design and painstaking quality control;...
- Page 3 SRX Powered Sub-woofer series arning nvestIgate the layout of your automobIle thoroughly before drIllIng or cuttIng any holes se extreme care when you work near the gas tanks gas or hydraulIc lInes and electrIcal wIrIng lways make sure the oofer Is securely mounted ountIng the woofer securely to the automobIle wIll prevent...
-
Page 4: Specifications
Parts List • Enclosure with sub-woofer • Wired Bass remote control • 2 Straps • High level-In wire harness Specifications Physical size (Measurements shown in Inches [Millimeters]) 570-SRX110PS 11.20 14.30 HIGH-INPUT POWER INPUT PROTECTION GAIN BASSBOOST POWER MIN MAX 40Hz... - Page 5 SRX Powered Sub-woofer series Controls and wiring locations POWER HIGH-INPUT INPUT PROTECTION GAIN BASSBOOST POWER MIN MAX 40Hz 220Hz 12dB BASS REMOTE 1. +12 Volt Power connection. Must be connect to the positive terminal on the vehicle’s battery . A fuse must be connected in-line between the powered sub-woofer and the battery.
- Page 6 SRX Powered Sub-woofer series the frame must be stripped of all paint to make a proper electrical connection. The distance to the ground should be as short as possible and no more than 18”. do not connect the powered sub woofer to ’...
-
Page 7: Installation
SRX Powered Sub-woofer series Installation 1. Input - The amplifier can use either a low or high level signal from the source unit. USE ONLY ONE TYPE OF INPUT from the source unit to the amplifier terminals on the sub-woofer. Be sure to lay the signal wire away from all power cables and vehicle computers. -
Page 8: The Amplifier
SRX Powered Sub-woofer series • Using Speaker Level Connections (High level input): Use the high level output from the source unit and the HIGH LEVEL-IN wire harness supplied with the sub-woofer. Splice SOURCE UNIT HIGH LEVEL-IN WIRE HARNESS the source unit LEFT (+) L (+), WHITE WIRE speaker wires to... - Page 9 SRX Powered Sub-woofer series Run the power wire through the interior of the vehicle, under the carpet, and to the sub-woofer’s amplifier. If this is something that you do not feel comfortable doing, please ask a professional to help you. Be sure to lay the power wire away from all signal cables.
-
Page 10: Troubleshooting Guide
SRX Powered Sub-woofer series If the vehicle’s source unit does not have current sensing technology while using the high level source input then connect the REM the same method as the low level input. Double check all the previous connection installation steps, in particular the speaker and power wiring. -
Page 11: Warranty Registration Card
KAPTION AUDIO PRODUCTS COME WITH A ONE-YEAR PARTS AND LABOUR LIMITED WARRANTY. This warranty covers the original purchaser of a Kaption Audio product, purchased from an authorized Kaption Audio dealer. In order to receive service, proof of purchase is required stating the customers name, dealer name, product purchased and date of purchase. -
Page 12: Limited Warranty Information
KAPTION AUDIO LOUDSPEAKERS COME WITH A ONE-YEAR PARTS AND LABOUR LIMITED WARRANTY. This warranty covers the original purchaser of a Kaption Audio speaker, purchased from an authorized Kaption Audio dealer. In order to receive service, proof of purchase is required stating the customers name, dealer name, product purchased and date of purchase.
