Summary of Contents for Kaption Audio 570-SQLFW10D2
- Page 1 SQLFW Flat Woofer Owner’s Manual 570-SQLFW10D2 570-SQLFW10D4...
-
Page 2: Design Features
SQLFW Flat woofer series Introduction: Congratulations on your new purchase of Kaption Audio loudspeakers. These loudspeakers are engineered to reproduce music that is so detailed, you will hear music in a whole new dimension. State of the art technology, rigorous testing, superior materials, innovative design and painstaking quality control;... -
Page 3: Limited Warranty Information
In order to receive service, proof of purchase is required stating the customers name, dealer name, product purchased and date of purchase. Products found to be defective during the warranty period will be repaired or replaced with a product deemed to be equivalent at Kaption Audio’s discretion. What is not covered 1. -
Page 4: Specifications
SQLFW Flat woofer series Specifications Model 570-SQLFW10D2 570-SQLFW10D4 Speaker size 10” 10” Sensitivity (1w/1m) Power Handling (RMS/Peak) 400 / 800 400 / 800 Impedance Dual 2 ohm Dual 4 ohm Voice Coil Diameter (inches) 2.8” 2.8” Overall Diameter 10.63” 10.63”... -
Page 5: Recommended Enclosures
SQLFW Flat woofer series Diagram 9.25 10.63 1.02 3.08 Recommended Enclosures When building an enclosure, the most important thing to remember is that the enclosure should be airtight. You can seal all the seams with glue or any type of sealant. This should prevent any air leaks. The seams should also be nailed with finishing nails to add extra durability. -
Page 6: Wiring Configurations
SQLFW Flat woofer series Wiring 2Ω Dual Voice Coil Speakers configurations 2 (ohm) DVC Speaker = 4 Load You can create an impedance load to best suit your application. You can choose to run your 2 (ohm) DVC Speaker = 2 Load system in series, parallel or series- parallel to achieve the... -
Page 7: Warranty Registration Card
KAPTION AUDIO PRODUCTS COME WITH A ONE-YEAR PARTS AND LABOUR LIMITED WARRANTY. This warranty covers the original purchaser of a Kaption Audio product, purchased from an authorized Kaption Audio dealer. In order to receive service, proof of purchase is required stating the customers name, dealer name, product purchased and date of purchase. - Page 8 Kaption Audio 95 Cousins Drive Aurora, Ontario Canada, L4G 1B5 www.KAPTIONAUDIO.com 866-Kaption (527-8466) Design in Canada; Made in China R0 (03/16)
