  • Page 1 User manual 21554 Video touch screen 4,3in Full Flat.

  • Page 2: Table Of Contents

    Table of Contents TABLE OF CONTENTS 1. The touch screen video ……………………………………………………………………………………… 2. Description ……………………………………………………………………………………………………… 3. Main menu ……………………………………………………………………………………………………… Date and time …………………………………………………………………………………………………… Display ……………………………………………………………………………………………………………… 4 Keys Tone …………………………………………………………………………………………………………… 4 Temperature Unit …………………………………………………………………………………………………… 4 Protection …………………………………………………………………………………………………………… 5 Video settings ……………………………………………………………………………………………………… 5 Temperature probe …………………………………………………………………………………………………...

  • Page 3: The Touch Screen Video

    Table of Contents 1. THE TOUCH SCREEN VIDEO The 21554 is a touch screen device comprising a display through which, by the mere touch of the finger on the icons displayed, you can select the home automation system management functions.

  • Page 4: Description

    Description - Main menù 2. DESCRIPTION. The touch screen include control of lights (on/off/adjustment), shutters, thermostats (traditional and for fan-coil) and scenes; control and monitoring of burglar alarm devices (specially through ‘Partialisation’ menu it is possible to display the state of partialisations; automatic monitoring and control of power consumption of appliances (over- load prevention).

  • Page 5: Date And Time

    • Date and Time By touching the icon it is possible to adjust the time and date displayed. With the icons set the blinking value until the desired day, month, year and time are shown. The confirmation of transactions by touching...

  • Page 6: Display

    Main menù • Display When the icon is touched the display shows the screen that allows you to adjust the back- lighting and the contrast of the display. This is set by holding your finger on the icons until the desired level is reached. LED Life Time: 20.000 hours (at 25 °C) The LED life time define as the estimated time to 50% degradation of initial luminous.

  • Page 7: Protection

    Main menù • Protection With this option you set a password (from 4 to 6 digits) that inhibits displaying certain pages and therefore all the controls associated with them. This application is useful, for example, to distinguish the use of the video touch screen according to the current user.

  • Page 8: Temperature Probe

    Main menù • Temperature probe By tapping the icon you can, by using , compensate for the value of the temperature measured by the external probe (where applicable). • Information When the icon is touched the display is shown which gives the software release and the main characteristics of the touch screen.

  • Page 9: Area Management

    Area management 4. AREA MANAGEMENT. From the main menu, when the icon , is touched the display is shown which allows you to select the different areas of the system and to control the devices associated with them (lights, roller shutters, climate, etc.).
  • Page 10 Area management • Touching the icon switches on/off and adjusts the lighting called “Picture Light”. • Touching the icon lifts and lowers the roller shutter called “Lounge left roller shutters”. • Touching the icon gives access to the screen which allows you to adjust the temperature in the area called “Lounge”.

  • Page 11: Management Monochrome And Rgb Lamps

    The new RGB functions (patented by Vimar) enable creating colour changes and elegant, sophisticated light effects. You can also call up scenarios involving different functions in the home automation system such as, for example, combinations of lights and colours matched to your favourite music to create a personalized, comfort- able environment.
  • Page 12 Area management - With on Saturation you set the percentage of "vividness" of the colour. - With on Brightness you set the percentage of "contrast" of the colour. - Tapping confirms the settings you have made. • Tapping the icon opens the screen where you make the Fading-Show settings. The function of Fading-Show allows to set a cyclical sequence of colors (up to a maximum of 6) for color changes and the play of light in the environments where the lamps are installed RGB.
  • Page 13 Area management - With you set the tone of color that will match the position of the cursor to the position desired color. - With you set Saturation and Brightness. - Tapping confirms the settings you have made. - Tapping you remove the color selected by the sequence of Fading-Show and the screen will become as follows: - Tapping...

  • Page 14: Hvac Management

    Area management Example for setting the Fading-Show with 4 colors. - With the icon set the desired 4 colors; with remove the 2 colors that you want to include in the sequence. - With set the Persistance and Transition (for example, 2 min and 15 s respectively). - Tapping confirms the settings you have made.
  • Page 15 Area management The icons are associated with the following modes of operation: • = thermostat off. • = thermostat off for a selectable number of hours (then it switches back on returning to the previous operation). • = the thermostat switches on in HEATING mode only if the ambient drops under the set antifreeze temperature (e.g.
  • Page 16 Area management • Touching selects the time slot for changing the temperature level. • Touching selects the desired temperature level; the histogram will be updated. The procedure must be repeated for all the time slots to be changed, then confirm with •...

  • Page 17: Events Programs

    Events Programs 5. EVENTS PROGRAMS. From the main menu, touching the icon shows the screen that allows you to change the automated functions previously configured on the control panel. The Events Programs menu enables: - stopping and restarting the selected event manually; - changing the event on and/or off times.
  • Page 18 Events Programs  Weekly clock. Enables, for every day of the week, setting activation of the event at intervals of 10 minutes (minimum time). Touching selects the desired range; the option activates the program for 10 minutes while deactivates it (the histogram will be updated). The procedure must be repeated for all the ranges to be changed and lastly confirm with ●...
  • Page 19 Events Programs  Period clock. Enables activating and deactivating the event at most two times each day of the week setting the time in steps of 1 minute. Select the desired day of the week with the icon. Touching sets the beginning and end time of each of 2 events or of just one. N.B.
  • Page 20 Events Programs In similar manner, set the OFF duration (h:min). At the end, confirm the settings made by touching  Timing. Used to set the duration of the program in hours and minutes. This function must always be linked to 1 or 2 inputs and 1 or 2 output groups through an On-Off or Off-On type message.

  • Page 21: Burglar Alarm

    Burglar alarm 6. BURGLAR ALARM. From the main menu, touching the icon displays the screen which allows you to view the status of the burglar alarm system and to switch the system on/off. For example, the partialized active system screen (the green colour represents active partialization) is of the type: while the alarm system screen (the red colour represents the zones in alarm) will be of the type:...
  • Page 22 Burglar alarm The touch screen allows the burglar alarm system to be switched on/off with modes similar to those of the digital keypad and therefore by typing in PIN codes; the screen is as follows: Once the PIN code has been typed in, the touch screen will display the following screen: •...
  • Page 23 Burglar alarm To include an area in partialization, it is sufficient to touch the corresponding icon and the edge of the latter will become yellow in colour. To confirm the settings made, touch the icon...

  • Page 24: Load Control

    Load control 7. LOAD CONTROL. From the main MENU, tapping the icon takes you to the screen where you can view the status of the controlled loads and the power consumption. Indicator of consumption with respect to the thresholds. If you have the full-scale production changes dyna- mically, taking into account the energy produced.
  • Page 25 Load control • Tapping the icon corresponding to the desired load, forces that load. The above icon is only displayed if the load can be forced. During configuration your installer will set which loads can be forced and which cannot (see an example of the screen below). ...

  • Page 26: Energy Monitoring

    Energy monitoring 8. ENERGY MONITORING. From the main menu, tap the icon and you access the menu that, depending on the structure of the system, displays the following options: • Global consumption (always present) • Energy production (optional) • Energy flows (optional) •...

  • Page 27: Global Consumption

    Energy monitoring 8.2 GLOBAL CONSUMPTION Tapping brings up the screen for viewing and managing the energy consumption of the house (Energy Guard) with: - an indication of the instantaneous power in kW or CO or cost in euro; - an indication of the accumulated energy in kW/h or CO or cost in euro;...
  • Page 28 Energy monitoring Average quantitative Estimated quantitative con- Consumption time slot consumption sumption indicator Consumption histogram Instantaneous consumption Values displayed in the consumption quantity icon Current quantitative consumption Dynamic Mode: Pressing the area that displays the instantaneous power for 2 min after the reading of the will value every 2 s thus increasing the frequency of update of the data represented.
  • Page 29 Energy monitoring • By tapping the icon you can change the reference time interval (daily, weekly, monthly and yearly) for the bar chart of the production log. The quantitative consumption displayed is: - daily if the time scale set for the consumption histogram is in hours; - weekly if the time scale set for the consumption histogram is in days;...
  • Page 30 Energy monitoring - Actual consumption: displayed in green (single shade). The icon turns yellow if the threshold is exceeded. - Exceeding the monthly threshold is signalled by a small red icon that appears above the icon Quantitative consumption (this happens only if the monthly consumption is displayed). •...
  • Page 31 Energy monitoring • The icon is used to clear the data displayed on the screen. 8.3 ENERGY PRODUCTION When present, tapping brings up the screen for viewing and managing the energy production of the house with: - an indication of the instantaneous power generated in kW or CO or cost in euro;...
  • Page 32 Energy monitoring Average quantitative production Histogram of the accumulated energy Indication of average Instantaneous production production Values displayed in the production quantity icon Current quantitative production Dynamic Mode: Pressing the area that displays the instantaneous power for 2 min after the reading of the will value every 2 s thus increasing the frequency of update of the data represented.
  • Page 33 Energy monitoring The quantitative production displayed is: - daily if the time scale set for the histogram is in hours; - weekly if the time scale set for the histogram is in days; - monthly if the time scale set for the histogram is in weeks; - yearly if the time scale set for the histogram is in months.

  • Page 34: Energy Flows

    Energy monitoring 8.4 ENERGY FLOWS The energy flow screens quickly and intuitively show the energy exchanges in progress and let you at any time see the state of your consumption, production and any tapping off from or feeding in to the power grid. The direction of the arrows indicates the direction of the energy while their colour indicates respectively: : Energy fed in : Energy self-consumed...
  • Page 35 Energy monitoring Conversely, the following screens illustrate situations that are shown less frequently:...

  • Page 36: Single Load Consumption

    Energy monitoring 8.5 SINGLE LOAD CONSUMPTION From the consumption monitoring menu (chapter 8), tapping the icon of the desired load (e.g. Fridge) brings up the screen (quite similar to that for global consumption) for viewing and managing power consumption with: - an indication of the instantaneous power in W or CO or cost in euro;...

  • Page 37: Pulse Counter

    Energy monitoring Dynamic Mode: Pressing the area that displays the instantaneous power for 2 min after the reading of the will value every 2 s thus increasing the frequency of update of the data represented. At the end of 2 min, the reading will repeat every 30 seconds until an eventual new pressure.
  • Page 38 Energy monitoring • By tapping the icon you can set the type of measurement with which the touch screen shows the data (consumption in m , cost in euro); • By tapping the icon you can set the time scale (hours, days, weeks, months) for measuring the con- sumption.

  • Page 39: Settings

    Energy monitoring 8.7 SETTINGS From the main menu, by tapping the icon you access the Settings menu; then by tapping the icon you access the menu for selecting the parameters related to the type of consumption/pro- duction. 8.7.1 POWER CONSUMPTION SETTINGS •...
  • Page 40 Energy monitoring • Tap the icon and, using , set the currency and cost of the electric energy in Time Slot 1. ■ CONTRACT WITH TWO TIME SLOTS In the case of a contract with two time slots, the screens are similar to those of the contract with 1 time slot. They are then followed by those for assigning the time slots to the days of the week.
  • Page 41 Energy monitoring The screen for setting the monthly threshold must be disabled. • Tap the icon and, using , set the currency and cost of the electric energy in Time Slot 1 and in Time Slot 2. • Tap the icon to set the weekdays/holidays according to the time slots.
  • Page 42 Energy monitoring When setting the weekdays and holidays associated with the relevant time slots it is also possible with copy/paste the time slots as illustrated in the following example. Example. The following screens illustrate the association of the time slots related to the days of Friday and Sunday.
  • Page 43 Energy monitoring Tapping the icons scrolls through the hours while with you set the relevant time slot. With the icon you can copy the current time slot (highlighted with green) to the following hour. ■ CONTRACT WITH THREE TIME SLOTS The operations to carry out are absolutely identical to those illustrated for the contract with two time slots;...
  • Page 44 Energy monitoring 8.7.2 POWER GENERATION SETTINGS • By tapping the icon you access the screens for selecting the parameters related to the power generated by the system and delivered over the network. The parameters that can be entered with the icons are: - Maximum production in kW - Tariff for the energy introduced in €/kWh...
  • Page 45 Energy monitoring 8.7.3 PULSE COUNTER SETTINGS • By tapping the icon you access the screens for selecting the parameters related to the consumption of utilities such as, for example, Water, Gas, etc. The parameters you can enter with the icons, which depend on the service controlled each time, may be the following: - Tariff for the consumption of water or gas in €/m - Emissions of gCO2 linked to the consumption of water or gas in €/m...
  • Page 46 Energy monitoring • Tapping confirms the setting and takes you back to the home screen of the power consumption menu.

  • Page 47: Speaker System

    Speaker System 9. SPEAKER SYSTEM. If the By-me system contains the speaker system and an audio zone is included on a page of the touchscreen, the screen displayed will be similar to the one shown below. This screen is used to control switching the audio zone on/off and adjusting the volume. •...

  • Page 48: Control For Ipod, Iphone And Auxiliary Sources

    Speaker System The screen displays all the relevant information on the tuned frequency, at the level of signal reception, and any RDS text broadcast by the station you are listening to. The icons enable setting the method of selecting the station you want to listen to: •...
  • Page 49 Speaker System ■ PLAYBACK MENU The Playback menu is displayed in two separate forms depending on whether the device is enabled for remote control. Playback menu with remote control enabled In this case, on touching the Details button on the zone page, the touch screen will display the Playback menu that provides information on the operating status of the Apple device and its control.
  • Page 50 Speaker System With the playback menu it is therefore possible to: • select track play/pause (icons • shift playback to the previous track or the next one (icons • cyclically vary the Shuffle and Repeat (icons • access the device navigation menu (incon •...
  • Page 51 Speaker System Access from Playlist category Browsing through this category enables selecting one of the playlists saved on the iPod/iPhone and selecting the track in the playlist from where to start playing. When accessing the Playlist category (left screen), the corresponding field will show the wording of the first item in this category saved on the Apple device.

  • Page 52: Control For Rca Transmitter With Ir Interface

    Speaker System 9.2 CONTROL FOR RCA TRANSMITTER WITH IR INTERFACE When a transmitter is configured together with an IR interface on an audio zone, it is possible to control the sound source connected to the transmitter by means of its RCA input. The screen relating to this zone will show the icon for accessing the Details page associated with the transmitter.

  • Page 53: Video Door Entry

    Video door entry 10. VIDEO DOOR ENTRY In the case where the touch screen is also used as internal video (integrated in the By-me system or in the implant only Two Wires) can be managed also all the functions of the video entry. From the main menu by touching icon , you enter the screen management functions configured video entry.
  • Page 54 Video door entry In the event that a call arrives from the external, the video display touch the image of someone who made it to the right and the icons will be placed management such as lights, volume, etc..

  • Page 55: Alarm Clock

    Alarm clock 11. ALARM CLOCK When combined with the speaker system, the touchscreen can also function as an alarm clock. The alarm clock control/setting screen is the following: The touchscreen displays the following alarm clock settings: - alarm clock on/off; - activation time;...

  • Page 56: Screen Saver

    Screen Saver - Cleaning - Compliance with regulations Alarm clock operation. When the time of day coincides with the time set on the alarm clock, the touchscreen switches on to display the relevant screen and the system activates the selected audio zone or scenario. The Snooze function is available whenever the alarm clock is activated and it can only be used until the following intervention of the screensaver;...
  • Page 58 Viale Vicenza, 14 - 36063 Marostica VI - Italy Tel. +39 0424 488 600 - Fax (Italia) +39 0424 488 188 Fax (Export) +39 0424 488 709 21554 user EN 03 1409 www.vimar.com VIMAR - Marostica - Italy...
