Table Of Contents - Phonak FreeCom 7100 User Manual

earJack™ adapter (incl. ambient microphone and in-ear speaker)
Ear mold for right ear with red marking
Ear mold for left ear with blue marking
Boom microphone. Microphone sound inlet to be placed
always parallel to the mouth.
Connectors with safety break point.
Allow to put the microphone on the right or on the left side
Battery door and ON/OFF switch
Ambient sound ON/OFF Switch (short press)
Ambient sound volume control mode (long press)
Intercom Volume Control +/-
Ambient sound Volume Control +/-
QD connector
4
A EarJack
TM adapter
B Boom Microphone
C Control Box
D Connectors
6
9
10
E Important informations
F Technical Data
14
G Troubleshooting
H Miscellaneous
16
17
21
24
5
