- Page 1 Alta2 Nera2 Ria2 INSTRUCTIONS FOR USE Alta2 Pro Ti, Nera2 Pro Ti, Ria2 Pro Ti...
- Page 2 Introduction to this booklet Indication for use This booklet guides you in how to use and maintain your new The hearing instrument is intended to amplify and transmit sound hearing instrument. Please read the booklet carefully including to the ear and thereby compensate for mild to severe-to-profound the Warning section.
-
Page 3: Table Of Contents
Replace dome About Identify your hearing instrument style and ear piece Thin tube with micro mould or LiteTip BTE with sound hook and mould Maintain the micro mould or LiteTip BTE with thin tube (Corda miniFit) Options Optional features and accessories... - Page 4 Identify your hearing instrument style and ear piece BTE with sound hook BTE with thin tube thin tube will have one of the There are two diff erent (Corda miniFit) attachments and several and mould following ear pieces - dome, An instrument with a GripTip, micro mould, or LiteTip.
-
Page 5: Bte With Sound Hook And Mould
BTE with sound hook and mould What it does What it is Sound hook Microphone Sound in openings Sound out Push button Change programs, volume and mute the Contains the battery. instrument Battery drawer is the Battery drawer on/off switch... -
Page 6: Bte With Thin Tube (Corda Minifit)
BTE with thin tube (Corda miniFit) What it does What it is Microphone Sound in openings Thin tube Push button Change programs, Sound out volume and mute the instrument Battery drawer Contains the battery. Battery drawer is also the on/off switch... -
Page 7: Identify Left And Right Instrument
Identify left and right instrument Battery It is important to distinguish between the left and the right Your hearing instrument is a miniature electronic device that runs on instrument as they might be programmed diff erently. special batteries. To activate the hearing instrument, you must insert a new battery in the battery drawer. -
Page 8: When To Replace A Battery
Turn the hearing instrument on and off When to replace a battery The battery drawer is also used to switch the hearing instrument When it is time to replace the battery you will hear two beeps on and off . To preserve the battery, make sure your instrument is repeated in moderate intervals until the battery runs out. -
Page 9: Replace The Battery
Replace the battery 1. Remove 2. Uncover 3. Insert 4. Close MultiTool Fully open the Remove the Insert the new Close the battery drawer. The The MultiTool can be used for battery drawer. sticky label from battery into the instrument will play a jingle battery change. -
Page 10: Caring For Your Hearing Instrument
Caring for your hearing instrument The MultiTool The MultiTool contains a brush and a wire loop for cleaning ear wax When handling your hearing instrument, hold it over a soft surface from the mould. The brush can be replaced and purchased from your to avoid damage if you drop it. -
Page 11: Sound Hook With Mould
Sound hook with mould Put on the instrument with mould Read the following pages if you have Step 1 Step 2 a hearing instrument with a sound hook and a mould. The mould is customised for you and fi ts your ear. Gently pull your ear outwards Place the hearing instrument and press the mould in the... -
Page 12: Clean The Mould
Clean the mould Wash the mould Replace the tube The mould should be cleaned Step 1 Step 2 Step 3 regularly. Use a soft cloth to The tubing between the mould clean the surface of the mould. and the instrument should be Use the MultiTool wire loop replaced when it becomes to clean the opening. -
Page 13: Thin Tube (Corda Minifit)
Thin tube (Corda miniFit) Put on the instrument with thin tube Read the following pages if your instrument has a thin tube (Corda Step 1 Step 2 Step 3 miniFit) with either a dome, GripTip, micro mould or LiteTip ear piece. Corda miniFit is a thin tube that brings the sound into your ear. -
Page 14: Clean The Thin Tube
Clean the thin tube The thin tube should be cleaned to keep it clear from moisture and Step 1 Step 2 Step 3 wax. If not cleaned it could become blocked with wax which means no sound will be able to come out. Pull the thin tube Push the cleaning Reconnect the thin... -
Page 15: Thin Tube With Dome Or Griptip
Thin tube with dome or GripTip Replace dome There are 4 diff erent types of domes, which are made of soft, rubber The dome should not be cleaned. When the dome is more or less fi lled material. If you have a dome check the type and size below. with wax, replace it with a new one. -
Page 16: Thin Tube With Micro Mould Or Litetip
Thin tube with micro mould or LiteTip Maintain the micro mould or LiteTip Read the following pages if you have a micro mould or LiteTip ear The ear piece should be cleaned piece.The micro mould and LiteTip are customised for your ear shape. regularly. -
Page 17: Mute The Hearing Instrument (Optional)
Optional features and accessories Mute the hearing instrument (optional) The features and accessories described on the following pages are Use the mute function if you need to silence optional. Please contact your Hearing Care Professional to fi nd out the instrument while wearing it. how your hearing instrument is programmed. -
Page 18: Change Programs (Optional)
Change programs (optional) To be fi lled out by the Hearing Care Professional Your hearing instrument can have up to 4 diff erent programs. Program Sound you will hear When to use These are programmed by your Hearing Care Professional. when activated “1 beep”... -
Page 19: Change Volume (Optional)
Change volume (optional) Quick reset If you wish to return to the standard settings of the instrument The push button allows you to adjust the volume. programmed by your Hearing Care Professional, simply open and then You will hear a click when you turn up or down the volume. close the battery drawer. -
Page 20: Tamper-Resistant Battery Drawer (Optional)
Tamper-resistant battery drawer (optional) Unlock the battery drawer Lock the battery drawer To keep the battery out of reach of infants, small children and people with learning diffi culties, a tamper-resistant battery drawer should be used. Use a small screwdriver to lock and unlock the drawer. Use the screwdriver to turn the Make sure the drawer is completely screw to unlock position (vertical). -
Page 21: Wireless Accessories (Optional)
Wireless accessories (optional) As an enhancement to your wireless hearing instrument a broad range of wireless accessories are available. ConnectLine Remote Control ConnectLine is a family of The Remote Control offers an Your hearing instrument For detailed information on products that allows you to opportunity to change program supports the option of attaching wireless accessories contact... -
Page 22: Other Options (Optional)
Other options (optional) Telecoil Direct Audio Input (DAI) Telecoil helps you hear better when using a allows your hearing instrument to receive signals directly from telephone with a built in loop or when you are in external sources such as TV, radio, music players, etc. The DAI adaptor buildings with teleloop systems such as theatres, is mounted to your instrument and via a cable connected to an external sound source. -
Page 23: Warnings Warnings
This option is Hearing Care Professional. Misuse available in BTE, miniBTE, RITE and can result in sudden and permanent miniRITE instruments. hearing loss. About Start up Handling Options... - Page 24 Warnings Dysfunction Active implants • If you have an active brain implant, X-ray, CT, MR, PET scanning and • Be aware of the possibility that • Caution must be taken with active please contact the manufacturer electrotherapy your hearing instrument may stop implants.
- Page 25 Warnings Avoiding heat and chemicals Power instrument Possible side effects Interference • Your hearing instrument must never • Special care should be excercised in • Hearing instruments, moulds or • Your hearing instrument has been be exposed to extreme heat e.g., left selecting, fitting and using a hearing domes may cause an accelerated thoroughly tested for interference,...
-
Page 26: Tinnitus Tinnitus Soundsupport (Optional)
Tinnitus SoundSupport (optional) Guidelines for tinnitus sound generator users Intended use of Tinnitus SoundSupport These instructions contain information about Tinnitus SoundSupport, Tinnitus SoundSupport is a tool intended to generate sounds to which may have been enabled in your hearing instruments by your provide temporary relief to patients suffering from tinnitus as part of Hearing Care Professional. - Page 27 Sound options and volume adjustment Prescription use only CAUTION: Tinnitus SoundSupport is programmed by your Hearing Care Good health practice requires that a person reporting tinnitus have a Professional to match your hearing loss and preferences for tinnitus medical evaluation by a licensed ear physician before using a sound relief.
- Page 28 Volume adjustments with Tinnitus SoundSupport 2) How to change Tinnitus SoundSupport volume in both ears simultaneously When you select a hearing instrument program where Tinnitus SoundSupport is activated, the push button on your hearing You can use one instrument to increase/decrease the sound in both instrument works as a volume control only for the sound produced by instruments.
- Page 29 Important information for Hearing Care CAUTION - daily use The volume levels of Tinnitus SoundSupport can be set to a level Professionals about Tinnitus SoundSupport which could lead to permanent hearing damage when used for a Device description prolonged period of time. Tinnitus SoundSupport is a module function that can be enabled in Your Hearing Care Professional will advise you of the maximum the hearing instruments by the Hearing Care Professional.
- Page 30 Important information for Hearing Care Instruct your patient accordantly and record your patient’s wearing time in the table “Tinnitus SoundSupport: Limitation on use”, page 56 Professionals about Tinnitus SoundSupport in this booklet. If the volume control is enabled By default the volume control for the sound generator is deactivated Maximum wearing time of Tinnitus SoundSupport in the instrument.
- Page 31 Warnings related to Tinnitus If your Hearing Care Professional has • Should you experience or notice • A Hearing Care Professional Visible congenital or traumatic activated the sound generator Tinnitus a change in hearing or tinnitus, or should advise a prospective sound deformity of the ear.
-
Page 32: Troubleshooting Guide
Troubleshooting guide for your hearing instrument Symptom Possible causes Solutions Worn-out battery Replace the battery No sound Clogged tube or earpieces (mould, dome, GripTip, micro mould or LiteTip) Clean mould Clean Corda miniFit (thin tube), replace dome or GripTip or replace wax filter Clogged sound outlet Clean mould Clean Corda miniFit (thin tube), replace dome or GripTip or replace wax filter... -
Page 33: Water Resistant
Water resistant Your hearing instrument is water 1. Gently wipe off any water resistant, not waterproof. Should your 2. Open the battery drawer and hearing instrument come in contact remove the battery and gently wipe with water and stop working, please off any water in the battery drawer follow these guidelines: 3. -
Page 34: Warranty Certificate
Warranty certificate International warranty Name of owner: _____________________________________________________ Your hearing instrument is covered might have under applicable national by an international limited warranty legislation governing sale of consumer Dispenser: _________________________________________________________ issued by the manufacturer for a goods. Your Hearing Care Professional period of 12 months from the date of may have issued a warranty that goes Dispenser address: __________________________________________________... -
Page 35: Mobile Phone
Mobile phone Some hearing instrument users hearing instrument rating of 2 (M2/ have reported a buzzing sound in T2) and a telephone rating of 3 (M3/ their hearing instrument when they T3) would result in a combined rating are using mobile phones, indicating of 5. -
Page 36: Technical Information
Technical information The hearing instrument contains a Operation is subject to the following The hearing instrument contains a Due to the limited space available on module with: two conditions: radio transmitter using short range the instruments all relevant approval 1. This device may not cause harmful magnetic induction technology markings are found in this document. - Page 37 Oticon declares that this hearing Declaration of conformity Power instrument instrument is in compliance with the is available at: Settings overview for your hearing instrument essential requirements and other relevant provisions of Directive Oticon A/S Left Right 1999/5/EC. Kongebakken 9 DK-2765 Smørum Volume control Denmark...
- Page 38 Hearing program description Program Option The volume control adjusts: (select one) Environmental sounds Tinnitus SoundSupport Environmental sounds Tinnitus SoundSupport Environmental sounds Tinnitus SoundSupport Environmental sounds Tinnitus SoundSupport The volume control in Tinnitus SoundSupport is enabled: Changing volume in each ear separately Changing volume in both ears simultaneously About Start up Handling Options Warnings Tinnitus Additionals...
- Page 39 People First is our promise to empower people to communicate freely, interact naturally and participate actively 0000151086000001...
