Summary of Contents for Lazerlogic LL2424
- Page 1 Innovation By Design LAZERLOGIC LL2424 Programme Manual 01256 840927 sales@lazerlogic.com Kensington House, 21 Mill Road, Basingstoke, Hampshire RG24 9SN...
- Page 2 Enter/Exit Programming Mode (☆ represents the default value)
-
Page 3: Table Of Contents
Contents Contents ............3 Introduction ............ 4 Setup steps ............4 System setting ..........5 Sleep time selection ........8 Same code delay time ........12 Beeper sound selection ......... 14 Tone ............15 Duration ..........17 Volume..........19 Barcode identifier code setting ..... 20 Message Terminator ........ -
Page 4: Introduction
Introduction This is an advanced programming guide for omnidirectional laser barcode scanner. If you want to read the detailed user’s manual, please visit the official website to download or contact your dealer for detail. Setup steps In order to change the scanner setting, please follow the steps below: 1. -
Page 5: System Setting
System setting ☆Reset (Return to factory default) Reading of the “Reset” barcode label turns all parameters back to default values, and the scanner remains in the last interface set when it is reset. Abort (Exit Programming Mode) - Page 6 After the replacement of different types of data lines, please do the following interface settings according to your optional data line. ☆Return to PC/AT Default Return to RS-232 Default...
- Page 7 Return to USB Default Return as Customer Default...
-
Page 8: Sleep Time Selection
Save as Customer Default Sleep time selection In this section, user can set both laser and motor to either into sleep mode. The timeout programming labels will allow users to set the different time frame before entering into laser or motor sleep mode. The feature reduces power consumption and prolongs scanner life time. - Page 9 mode as motor enters sleep mode. Motor Sleep Mode Off Motor Sleep Time 10 Minutes...
- Page 10 ☆Motor Sleep Time 30 Minutes Laser Sleep Mode Off...
- Page 11 ☆Laser Sleep Time 10 Minutes Laser Sleep Time 30 Minutes...
-
Page 12: Same Code Delay Time
Same code delay time In order to avoid an unwanted reading the same barcode, the time interval of the same barcode should not set too short. 50ms 200ms... - Page 13 ☆300ms 500ms...
-
Page 14: Beeper Sound Selection
Infinite Beeper sound selection ☆Power up Tone Enable... -
Page 15: Tone
Power up Tone Disable Tone... - Page 16 ☆Medium High...
-
Page 17: Duration
Silent Duration 50ms... - Page 18 ☆100ms 200ms...
-
Page 19: Volume
Volume Medium... -
Page 20: Barcode Identifier Code Setting
☆High Barcode identifier code setting Code 39... - Page 21 ITF 2 of 5 Chinese Postal Code...
- Page 22 UPC-E UPC-A...
- Page 23 EAN-13 EAN-8...
- Page 24 Codabar Code 128...
- Page 25 Code 93...
- Page 26 RSS-14 RSS-14 Limited...
- Page 27 RSS Expanded Save Setting to Confirm...
-
Page 28: Message Terminator
Message Terminator RS-232 None ☆CR/LF... - Page 30 STX/ETX...
- Page 31 USB HID & Keyboard Wedge None ☆Enter...
-
Page 32: Rs-232C Interface Configuration
RS-232C interface configuration Baud rate 1200... - Page 33 2400 4800...
- Page 34 ☆9600 19200...
- Page 35 38400 57600...
-
Page 36: Capital Lock
115200 Capital lock hift... -
Page 37: Function Key Emulation
☆Reset Function key emulation Enable... -
Page 38: Data Edit
☆Disable Data edit Prefix and suffix The prefix and suffix section allows you to append a prefix or suffix to every message. There is no restriction in selecting prefix or suffix characters as far as the sum of the lengths of prefix and suffix is not greater than 10 digits. - Page 39 2. Select either prefix or suffix that you are going to program by scanning the corresponding label. If you want to add both prefix and suffix, you should operate separately; 3. Scan the characters you want to set as header or trailer from the full ASCII. 4.
- Page 40 Suffix Save Setting to Confirm...
-
Page 41: Truncate Header/Trailer Character
Truncate header/trailer character This setting allows you to truncate a number of header or trailer for symbology. As a result, the specific character you select is deleted from the symbology you want. 1. Scan the “Enter/Exit Programming Mode” label; 2. Select the “Truncate Header/ Truncate Trailer”... - Page 42 Truncate Trailer Save Setting to Confirm...
-
Page 43: Add Code Length
Add Code Length This setting is used to set whether the barcode length character can be used as header. Enable Disable... -
Page 44: Reading Code Selection
Reading code selection ☆Code 39 Enable Code 39 Disable... - Page 45 Codabar Enable ☆Codabar Disable...
- Page 46 ☆UPC/EAN/JAN Enable UPC/EAN/JAN Disable (Only can’t transmitted but can decode)
- Page 47 ITF 2 of 5 Enable ☆ITF 2 of 5 Disable...
- Page 48 Chinese Postal Code Enable ☆Chinese Postal Code Disable...
- Page 49 ☆Code 128 Enable Code 128 Disable...
- Page 50 Code 93 Enable ☆Code 93 Disable...
- Page 51 EAN-128 Enable ☆EAN-128 Disable...
- Page 52 EAN Convert to ISSN/ISBN Enable EAN Convert to ISSN/ISBN Disable...
- Page 53 Code 32 Enable ☆Code 32 Disable...
- Page 54 MSI Enable ☆MSI Disable...
