CE Labs HX70M Instruction Manual

CE labs can support many areas of your audio and video
distribution needs.
We manufacture:
- Digital Signage software and Media Players
- HD Matrix Switchers
- RF modulators
- RF ampli ers
- HDMI and Component HD distribution ampli ers
- CAT 5 Signal Extenders
- VGA Extenders and Splitters
- and cables of all types.
See our full product line at www.celabs.net
WARRANTY
Cable Electronics, Inc. warrants this product to be free from defects in
material and workmanship, under normal use and service, for a period
of one year from the purchase by the original purchaser. If this product is
defective or malfunctions, Cable Electronics will replace or repair this unit
(at their option) within a reasonable time. No expressed or implied warranty
is made for any defects caused by immersion or exposure to liquids, abuse,
neglect, improper operation of unit, excess wear and tear and defects
resulting from unauthorized disassembly and or modi cation.
3209 Wood Drive
Garland, TX 75041
Phone: (469) 429-9200
Toll free: (800) 767-6189
Fax: (469) 429-9205
www.celabs.net
.
Document: HX70M_Manual.pdf
930-3041-01 – Rev. A
HX70M
HDMI (HDBaseT) & IR
™
CAT5 Extender Series
HDMI™ (HDBaseT) CAT5 Extender uses only one cost effective
CAT5e/6 cable to extend your HDTV display up to 60 meters at
1080p, 70 meters by CAT6a cable. This model includes IR
function to allow exibility in con guring home and commercial
entertainment systems.
.
Features:
• Extends HDMI and IR signal over one CAT5/5e/6/6a cable
• Uncompressed high de nition video up to 1080p@60Hz@48bits
3D and 4K*2K capable
• Built in IR control
• IR signal able to send or receive at either TX/RX side
• Max. Data Rate – 10.2Gbps
• HDMI 1.4 and HDCP compliance
• Transmission range up to 60mM by CAT5e/6, 70M by CAT6a
cable at 1080p@60Hz@24bit & 40M at 4K*2K @30Hz
• Audio support up to LPCM7.1, Dolby TrueHD, DTS-HD MA
