- Page 1 UHX70M MANUAL CE Labs, LLC.
- Page 2 Thank You! Thank you for your purchase. CE Labs manufactures a full line of commercial-grade products. For more information about our products and services please visit www.celabs.com. We strive to provide superior support through out the product lifecycle. For technical assistance please call 1-800-767-6189 or scan the QR code.
- Page 3 UHX70M Product Introduction: The UHX70M is a commercial-grade Ultra-High Definition HDMI Extender kit. The UHX70M supports 4K/60 @70M. With a ultra-compact and rugged chassis the UHX70M is ideal for professional environments that require 24/7 performance. Extends HDMI 4K UHD @60Hz, HDR and IR signal over one CAT6 cable.
- Page 4 Panel Descriptions: Transmitter I/O Panels Reset Button HDMI Input RJ45 Signal Output IR In Power/Signal Indicator IR Out DC5V Input HDMI 2.0 Output Receiver I/O Panels Reset Button S/PDIF Out Audio Switch HDMI 2.0 Output RJ45 Signal Input IR In Power/Signal Indicator IR Out DC5V Input...
- Page 5 Up to 4096x2160@ 5M MAX 5M MAX 60Hz 4:4:4 Cat6a/ Cat7 Cable: CE labs recommendation: TIA/EIA-568-B. high quality CAT6, CAT6a, CAT7 UTP (Un-shielded Twisted Pair)/STP (Shielded Twisted Pair) or FTP (Foiled Twisted Pair) cables. RJ45 Define: Video Link (TIA/EIA-568-B) 1. Orange-white DATA0+ 2.
- Page 6 2) Check if the HDMI cables are connected well. 3) Reconnect the network cable. CE Labs can support many areas of your video playback and distribution needs. We manufacture UHD media players, Digital Signage Solutions, HDTV compatible Video Scalers, UHD distribution amplifiers, and cables of all types.
- Page 7 CE Labs LLC warrants this product to be free from defects in material and workmanship, under normal use and service, for a period of three years from the purchase by the original purchaser.
- Page 8 CE Labs, LLC. email: techsupport@celabs.com Phone: (469)429-9200 3209 Wood Drive Garland, Texas 75041-9205...
