Thank you for purchasing a Vilar IP Camera. The IP-001A is a high performance IP
Camera. The camera provides many features such as steady network connection,
powerful customer management, compatibility and security. You can use it simple and
convenient.
This guide explains how to install this camera fast. For more details, please refer to the [IP
Camera User Manual.doc] on accessory CD.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vilar VWC-300PT
Summary of Contents for Vilar VWC-300PT
- Page 1 Thank you for purchasing a Vilar IP Camera. The IP-001A is a high performance IP Camera. The camera provides many features such as steady network connection, powerful customer management, compatibility and security. You can use it simple and convenient. This guide explains how to install this camera fast. For more details, please refer to the [IP...
- Page 2 Connecting the LAN Connect the network cable to the RJ45 network connection port. Connect the power adapter to the IP Camera power socket and then insert the plug into an available power outlet. Start up your computer, and make sure it connects to the LAN successfully. Click Start>Running, and enter “command”...
- Page 3 Insert the accessory CD into the CD-ROM, copying the “VilarWizard_CN.exe” which is green software from the CD to your computer. Double-click it on your computer. The interface as follow will pup up. This window shows us all the IP Cameras in your LAN. You can press the refresh button to get a new list.
- Page 4 Please fill in the LAN parameters which were you recorded before such as Subnet Mask, Default Gateway and IP Address. Attention of IP Address is the front three sections of IP Address are the same as your recorded, but the last section you have to enter the number is different from your computer.
- Page 5 Click “OK”, the system starting assign a new IP address for your IP camera. Click “OK” after you saw the successfully prompt. Then new IP address of your camera has been shown in the interface.
- Page 6 Selecting this camera, and click “visit IPCam” option, the Internet explorer will connect your camera automatically. Above interface can be indicated means your IP camera is connect to network successfully. Also you can enter your camera IP address into the Internet explorer to access, such as http://10.0.8.210...
- Page 7 Click the “User Zone” button; you will enter the image view interface. The login window will be indicated at the first time. Please fill in the administrator’s username as “admin” and the administrator password as “123456” to enter the website. When you enter the ActiveX mode at the first time, you might be prompted to install the ActiveX control.
- Page 8 Note: You can not download the ActiveX Control without authorization until setup Internet Explorer security configuration properly. Setting Internet Explorer (IE) security configuration will execute following steps: 1. Select [Internet Options] in [Tools] menu of IE; 2. Switch to [Security] option card; 3.
- Page 9 The access from internet Sometimes you might need to visit your IP camera from internet. Such as you want to see your pets when you at office. You can control the home camera send the pets’ video to you by using internet. You have to do some configurations of your router before you visit your camera from internet.
- Page 10 The DDNS operating figure as follow: In order to use DDNS you have to apply a DDNS domain name first. Please visit http://www.vipcam.cn, enter the product serial number and original password login. You can find the serial number and password of your camera in the back cover of this guide. Setting your DDNS domain name and changing your password on this page.
- Page 11 IP address for DDNS server”, it means DDNS configuration is successful. Please attention that your LAN have to open the UDP port when you using DDNS. If you have any question, please contact your network administrator or the Vilar IP Camera customer’s center to get some help.
- Page 12 For open PPPoE function, please use network cable connects your camera to your PC network card directly, running “VilarWizard_CN.exe” or enter your camera’s IP address into IE to visit your camera. Select “Network setting” from the System setting option, and enter your “User name”...
