- Page 1 MQ-1168 Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 MQ-1168 Evaluation Board Users Guide Board Revision 2 Revision A 4/18/02 Preliminary 1...
-
Page 2: Platform Description
Board Revision 2 INTRODUCTION This guide is intended to give a brief overview of the MQ-1168 and describe the features and workings of the MQ-1168 / PCI Evaluation Board. This includes how to locate connectors, configure switches, configure jumpers, and the initialization and configuration of this Evaluation board with the PC motherboard with PCI interface as well as other platforms by using special adapters. -
Page 3: Evaluation Board Layout
MQ-1168 Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 EVALUATION BOARD LAYOUT The location of the connectors, jumpers and other notable features are shown on the layout diagram below. These are described in the tables on the following pages. -
Page 4: Stuffing Options
MQ-1168 Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 Miscellaneous Reference Type Description Used to test GPIO 54 functionality Jumpers Reference Type Description JP1, JP4, 2 pin header Power measurement jumpers for FVDD (flat panel), BVDD (Bus), PVDD JP3, JP2,... -
Page 5: Functional Description
LCD panels other than the Sharp HR TFT. Custom cables are required to map the panel signals onto the proper MQ-1168 pins, details of the LCD panels already verified by MediaQ can be obtained from our web site. A custom cable will require a matching female connector to mate with either of the 60-pin connectors J3 or J5, these connectors also supply various power rails. -
Page 6: Touch Screen / Mmc
Two USB connectors are provided on the Evaluation board. CN2 is a Type A USB connector and provides the USB Host functionality of the MQ-1168. CN1 is a Type B connector and provides the USB Device function. Since the MQ-1168 USB device is a high speed device, CN1 is configured as such. - Page 7 MQ-1168 Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 ADAPTERS CARDS The Evaluation board can be used with other platforms besides PCI. To accomplish this, adapters are used that interface to a special connector on the Evaluation board and mate with the unique connectors used on the various target platforms.
- Page 8 MQ-1168 Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 Jumpers J1 and J2 are used to select the 3.3V (J2) and 5V (J1) power sources for the Evaluation board. Jumpering 1-2 selects power directly from the bus while 2-3 selects power from the regulators on the adapter that receive their power from the AC adapter used by the platform.
-
Page 9: Software Download
§ Serial cable (10-pin female header to 9-pin female serial port connector) Please note that no compact flash adaptor should be installed in the SA1110 board socket, as it will cause damage to the card and the bus drivers used to drive the MQ-1168 & SA1111 board’s bus. Software Download After the hardware is assembled, connect the serial and ethernet connectors to a properly configured host PC. - Page 10 MQ-1168 Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 Following are the steps required to download a software image to the platform flash memory. 1. Download the Flash Memory Programmer (JFlash), version 1.2 from http://developer.intel.com/design/strong/swsup/ 2. Unzip and read the readme.doc to setup the JFlash application. Run “jfsetup.bat.”...
- Page 11 Development Platform. These connectors are keyed so cannot be installed incorrectly. J1 selects which IRQ the MQ-1168 will connect to on the platform. Setting 1-2 selects IRQ2 while 2-3 selects IRQ3. The Evaluation board requires 3.3V and 5V power from the adapter board. The Palm/Motorola adapter passes the 3.3V power supplied on the platform connector but does not provide 5V.
- Page 12 MQ-1168 Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 NEC VR4121 Platform (Falcon) Adapter The diagram above shows the adapter for the NEC VR4121 Development Platform (Falcon). J6 mates with the “Generic CPU” connector located on the back of the Evaluation board. Male 2mm pitch headers J2, J3 and J4 mate with matching connectors on the NEC Falcon Platform.
- Page 13 MQ-1168 Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 Hitachi SH7709/7750 Platform (S1/R1) Adapter The adapter for the Hitachi 7709/7750 based Development Platforms (S1/R1) is shown above. J2 mates with the “Generic CPU” connector located on the back of the Evaluation board. The Male 0.05” pitch connector J1 mates with the matching connector on the Hitachi platforms.
-
Page 14: Related Documentation
MQ-1168 Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 RELATED DOCUMENTATION • MQ-1168 Multimedia Platform Controller Datasheet • Flat Panel Support Application Note • MediaQ Software release notes • Intel® StrongARM® SA-1110 Microprocessor Developers Manual (278240-003) • Intel® StrongARM® SA-1110 Microprocessor Development Board User’s Guide (278278-005) •... - Page 15 C121 33pF R116 USB0_DP USB0_DP B_USB1_D R119 gnd en/st LED GREEN C108 33pF R114 EPSON SG-636PCV 48.000MCQ MVDD AVDDP18 BVDD FVDD CVDD USBVDD SDLOW AVDD18 SDLOW Title MQ-T2 Size Document Number MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet...
- Page 16 MD[1:0] BS_N CKIO PCIMDN MODE FRAME_N STOP_N STOP_N 47uF10V 47uF10V 0.01uf 0.01uf 0.01uf 0.01uf 0.01uf 0.01uf USB_G23 USB_G23 SDLOW SDLOW AD[31..0] Title PCI Interface and Generic CPU interface Size Document Number MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet...
- Page 17 4.7uF 0.1uF 2SC1815 MMDF2C02E FMOD FMOD 22uF16V 2.2uF CERAMIC 0.1uF 2SA1161 22uF16V 0.1uF 120K IR3E204N-SHARP V[9..0] V[9..0] -15V 0.1uF VCOM_AC_DC VCOM_AC_DC 4 VEE_AC_DC VEE_AC_DC Title HR-TFT interface #1 Size Document Number MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet...
- Page 18 FP_B0 FP_G[5..0] FP_B1 FP_B2 FP_B3 FP_B4 FP_B5 FP_B[5..0] FP_B[5..0] FP_PWM1 FP_PWM1 FP_LP FP_LP FP_SCLK FP_SCLK FP_HSCAN_DIR V[9..0] V[9..0] FCON50 SHARP HR TFT INTERFACE Title HR-TFT interface #2 Size Document Number <Doc> MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet...
- Page 19 HDR 2X30, 50 Mils HDR 2X30, 0.1 FP_G[5..0] 47uF10V FP_G[5..0] FP_ENVDD FP_ENVDD FP_ENVEE FP_ENVEE FP_DESPL FP_DESPL FP_LP TEST HEADER FP_LP GENERIC FLAT PANEL INTERFACE Title Generic Flat panel interface Size Document Number <Doc> MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet...
- Page 20 TEST1 Vref AUDIO_SYSCLK_G41 R110 AUDIO_SYSCLK_G41 SYSCLK 0.1uF 47uF10V 5VBUS 3.3VBUS AUDIO_BCLK_G42 AUDIO_MD_G3 AUDIO_DIN_G45 AUDIO_ML_G4 AUDIO_DOUT_G44 QMUTE_G40 AUDIO_SYSCLK_G41 AUDIO_MC_G0 AUDIO_L_R_G43 POR_N 1,2,7,8 POR_N HEADER 10X2(.1 SPACING) Title Audio DECODER Size Document Number MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet...
- Page 21 AUDIO AC 97 AUDOUL AUDOUR 5VAV C125 220uF16V 3.3AV 220uF16V PHONEJACK C124 C116 0.1uF 10uF16V DVdd1 AVdd1 DVdd2 AVss1 C126 C127 0.1uF DVss1 O_LINE_OUT_R DVss2 O_LINE_OUT_L I_HPCFG AC LINK SCLK AUDIO_BCLK_G42 O_BIT_CLK FLTO SOUT C122 AUDIO_DIN_G45 I_SDATA_OUT FLTI SINO AUDIO_DOUT_G44 O_SDATA_IN FLT3D FSYNC...
- Page 22 VACTIVE FIELD R107 I2CSS CLKX1 CLKX2 RST# DIG_H FRST# DIG_V TWREN DIG_CLK 3.3VBUS 3.3VBUS LVTTL# R104 TRST# 100K VHSYNC_G79 VHSYNC_G79 3.3VBUS VVSYNC_G80 VVSYNC_G80 R108 1,2,6,7 POR_N Title Video Size Document Number MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet...
- Page 23 0.1uF 0.1uF side 5VBUS 3.3VBUS 5VAV 3.3AV FB-40 @100MHZ FB-40 @100MHZ C128 0.1uF 0.01uF 47uF10V 100pF 0.1uF 100uF16V Title POWER Size Document Number <Doc> MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet GAURAV SETHI...
- Page 24 SDD3_G63 SDD3_G63 CD/DAT3 SDCMD_G65 SDCMD_G65 SD MEMORY CARD SDCLK_G64 SDCLK_G64 SDD0_G60 SDD0_G60 DAT0 SDD1_G61 SDD1_G61 DAT1 CDDETECT SDMEMORYCARD WRPROTECT SD_DETECT_G1 COM_SD G54_G24 Title SD interface- Touch screen- SPI Size Document Number MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet...
- Page 25 USB0_DP USB0_DP of the two socket 5VBUS CN2-1 I_VIN C_FLGA I_ENA LED RED I_ENB 0.1uF Type A USB 47uF10V C_FLGB 0.1uF 100uF16V MIC2026-1BM USB1_DN USB1_DN USB1_DP USB1_DP Title Size Document Number MQ-1168 Evaluation Design Date: Tuesday, April 16, 2002 Sheet...
