- Page 1 MQ-1132 / PCI Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 MQ-1132 / PCI Evaluation Board Users Guide Board Revision 2 Revision A 4/12/01 Preliminary 1...
-
Page 2: Table Of Contents
MQ-1132 / PCI Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 Introduction ..........................3 MQ-1132 Overview ........................3 Platform Description ......................3 The MQ-1132 / PCI Evaluation Board………………………………………………….3 MQ-1132 Board Layout…………………………………………………………………4 Connectors……………………………………………………………………………….4 Switches/Potentiometers/Miscellaneous…………………………………………………5 Platform se tup instructions....................5 Functional Description......................5 Flat Panel Interface……………………………………………………………………...5 MQ11xx initialization......................6... -
Page 3: Introduction
Board Revision 2 INTRODUCTION This guide is intended to give a brief overview of the MQ-1132 and describe the features and workings of the MQ-1132 / PCI Evaluation Board. This includes how to locate connectors, configure switches, configure jumpers, and the initialization and configuration of this evaluation board with the PC motherboard with PCI interface. -
Page 4: Mq-1132 Board Layout
MQ-1132 / PCI Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 MQ-1132 Board Layout The location of the connectors, jumpers, switches, LED and adjustable potentiometers are shown on the layout diagram below. These are described in the tables on the following pages. -
Page 5: Switches/Potentiometers/Miscellaneous
PLATFORM SETUP INSTRUCTIONS The MQ-1132 / PCI Evaluation Board is used in conjunction with a motherboard with a PCI interface. The followings components are required : § A complete PC motherboard system containing a PCI interface slot §... -
Page 6: Mq11Xx Initialization
MQ-1132 / PCI Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 3003022. Power is supplied by this connector for most panels. The pin assignments for the generic connector are shown below: Signal Signal Signal Signal FVSYNC FMOD DESPL ENVEE 3.3V*... -
Page 7: Touch Screen / Mmc
Two USB connectors are provided on the evaluation board. CN2 is a Type A USB connector and provides the USB Host functionality of the MQ-1132. CN1 is a Type B connector and provides the USB Device function. Since the MQ-1132 USB device is a high speed device, CN1 is configured as such. - Page 8 MQ-1132 / PCI Evaluation Board Users Guide MediaQ Incorporated Board Revision 2 • MQ11xxTest utility procedures. • MQ11xxpci document. Revision A 4/12/01 Preliminary 8...
