DVD Player

Service
Service Manual
Copyright 2006 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by TCL-HY 0639 Service Audio
Version 1.0
Printed in The Netherlands
Subject to modification
DVP5150/94
CLASS 1
LASER PRODUCT
GB
3139 785 32330
PHILIPS

Advertisement

Table of Contents

   Also See for Philips DVP5150/94

   Related Manuals for Philips DVP5150/94

   Summary of Contents for Philips DVP5150/94

  • Page 1: Dvd Player

    Service Service Manual CLASS 1 Copyright 2006 Philips Consumer Electronics B.V. Eindhoven, The Netherlands LASER PRODUCT All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
  • Page 2: Power Supply

    DVP5150/94 WIRING DIAGRAM REAR R R SURR FRONT R COAX REAR R L SURR FRONT L CVBS AUDIO CS4360+AK4382 VIDEO LPF & AUDIO DRIVE AMP&LPF POWER SUPPLY 24PIN*0.5 3.3V MTK1389C +12V AGND CN202 -12V -24V 8PIN*2.5 LIMIT LOAD+ FLASH LOAD-...
  • Page 3 DVP5150/94 Front Board & Switch Board Electrical Diagram C300 R300 C301 R301 +12V C302 R302 K301 POWER C303 R303 R320 C304 R304 VFD-54 C317 C305 R305 R341 C306 R306 R317 R321 Q301 -24V 3904 C307 R307 Q306 C310 3904 C319...
  • Page 4 Front Board Print-layout (Top Side) for DVP5150/94 Front Board Print-layout (Bottom Side) for DVP5150/94 Switch Board Print-layout (Bottom Side) for DVP5150/94...
  • Page 5 DVP5150/94 Power Board Electrical Diagram T2AL/250ac NTC 10 0.1uF/250Vac 1N4007 1N4007 471/400Vac 30mH RV1(NU) 10K471 CON1 AC INPUT 471/400Vac 1N4007 1N4007 FR102 33uH CON1 10uF/50V R2(NU) C6(NU) ZD1(NU) ZD2(NU) CON2 220 1/2W 333/400V 15V 1/2W 15V 1/2W FR102 33uH 47uF/25V...
  • Page 6 Power Board Print-layout (Bottom Side) for DVP5150/94...
  • Page 7 DVP5150/94 Main Board Electrical Diagram:Index INDEX & POWER, RESET RF, SERVO & MPEG MT1389C&MT1389EE MEMORY - SDRAM, FLASH/EEPROM,VIDEO OUT URST# AUDIO DAC & AUDIO OUT URST# [ 2 ] [ 2 ] DV33 DV33 [ 2,3,4,5 ] AVCC AVCC RFV33...
  • Page 8 DVP5150/94 Main Board Electrical Diagram:MPEG & SERVO JITFO 390pF JITFN 750k DVP3040K,5140K/93 for RFV33 PLLVDD33 TO FRONT PANEL CN5(2-13) + CE12 2200pF 47uF/16V 0.1uF +12V -24V CE16 DV33 DV33 10uF/16V +P33V 2200pF VSDA V2P8 VSTB ADIN 0.1uF 100k VSCK 680k...
  • Page 9 DVP5150/94 Main Board Electrical Diagram:SDRAM/FLASH/VIDEO OUT SD33 FLASH_VCC DV33 DV33 C153 C154 C155 C156 C157 + CE19 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF + CE20 47uF/16V 0.1uF 47uF/16V 0(OPEN) AA20 0(OPEN) AA21 U8(OPEN)
  • Page 10 R153 C122 200p DVP5150/94 Main Board Electrical Diagram: AUDIO OUT -12VA 3906 +12VA CE33 R143 R151 U13A R159 CE35 DAC_L LOUT- R123 100 1N4148 5.6K DV33 10uF 10uF R145 R124 0(OPEN) R125 R120 C118 NJM4560 OPA R205 [ 2 ]...
  • Page 11 Main Board Print-layout (Top Side) for DVP5150/94...
  • Page 12 6-10 6-10 Main Board Print-layout (Bottom Side) for DVP5150/94...
  • Page 13 DVP5150/94 Exploded View...
  • Page 14: Remote Control

    MAIN ENCASING & ACCESSORIES PARTS LIST DVP5150/94 9965 000 42340 ASSY-MAIN BD 9965 000 34178 ASS’Y-SW BD 9965 000 35361 ASS’Y-FB BD 9965 000 34180 ASS’Y-PW BD RC 9965 000 34176 REMOTE CONTROL 9965 000 34182 ASS’Y-LOADER 9965 000 22495...
