LST Series 65/XP95 Specifications

Detector Base Accesories
Series 65/XP95
• Detector base for fl ush mounting in
false ceilings
• Conduit box for surface mounting
• Detector base backplate
• Code cards for selection of the
detector address
• Detector mounting bracket
Detector base for fl ush mounting (ADM technology)
The detector base in fl ush mounting design (fi g. A) ac-
commodates automatic fi re detectors Series XP95 and
Discovery for use in ADM loops with Apollo/Discovery
protocol. It is specially designed for mounting in false
ceilings made of mineral fi bre.
Specifi cations
Dimensions ø × H
Colour
Weight
Order number
Order name
Detector base for fl ush mounting (conventional technology)
The detector base in fl ush mounting design (fi g. B) ac-
commodates automatic fi re detectors in addressable
conventional technology. It is specially designed for
mounting in false ceilings made of mineral fi bre.
Specifi cations
Dimensions ø × H
Colour
Weight
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
fi g. A
fi g. B
The detector address is selected by means of a code
card in the detector base. Therefore the detector can
be changed without additional tools. The package con-
tents includes a cover plate.
150 × 15 (mm)
white
70g
246034
Detector Base/Anal./XP95/Disc/Apo 45681-250
Individual detector addressing can be achieved by
connecting the optional Address Module NG60-1. The
package contents includes a cover plate.
150 × 15 (mm)
white
70g
246035
Detector Base/Conv./60/65/Apo 45681-251
fi g. C
fi g. E
A
MS-ZBH-Ap_DBL_LST_EN_0804.PDF • PAGE 1
fi g. D
fi g. F
