Janam CR-XP-1M Quick Start Manual

Parts List
1 - CR-XP-1M USB & Modem Charging Cradle
1 - Power Supply and Power Cord
1 - USB Type-A to Type-B Cable (7 ft / 2.1 meters)
1 - Quick Connect Guide (this document)
1 - RJ11 Telephone Cord (6 ft / 1.8 meters)
Connect USB
For Local Communication:
Connect the USB Type-A connector to a Type-A
connector on the Host Computer.
Connect the USB Type-B connector to the USB
connector on the cradle.
Local
Host
Computer
Connect XP20/XP30
Place the XP20/XP30 into the cradle to
charge the device.
Problems?
Download the User's Guide and
Troubleshooting Tips from the Janam
website at: www.janam.com.
Click on the Support link and then the
Product Manual link.
Still having problems?
Contact Technical Support at:
www.janam.com. Click on the
Contact Us link.
USB Type-A
to
Type-B Cable
Modem
& USB
Quick Start Guide
Choose
OR
To use the modem for HotSync operations you must disconnect the
USB cable. The USB cable cannot be connected to the cradle and the
computer during modem operations. If the USB cable is connected, the
modem HotSync will fail.
Need More Help?
Contact Janam Technical Support for more help at:
Telephone: +1.877.JANAM.99
Email: inquiries@janam.com
More information can be found in the CR-XP-1M User Guide. Download
the User Guide from our website at: http://www.janam.com. Click on the
Support link and then the Product Manual link.
CR-XP-1M
Connect Power
Plug the barrel connector
into the Cradle's Power
Connector
Connect Modem
Connect one end of the standard RJ11
telephone cord to the cradle's RJ11 connector
and the other end to a standard analog wall
telephone outlet.
Part Number: 184338-400 Rev A
Charging
Cradle
Plug the
Standard
115V
Power Cord
into the Power
Adapter
