- Page 1 Electric Bicycle IMPORTANT: KEEP FOR FUTURE REFERENCE Owner’s Manual THIS MANUAL CONTAINS IMPORTANT SAFETY, PERFORMANCE, AND MAINTENANCE INFORMATION. READ THE MANUAL BEFORE TAKING YOUR FIRST RIDE ON YOUR NEW ELECTRIC BICYCLE, AND KEEP THE MANUAL HANDY FOR FUTURE REFERENCE.
- Page 2 Fifield directly. It is jurisdiction. extremely important that you If the owner is unable to fully follow the safety guidelines...
- Page 3 72 Sharp Street, Hingham, MA 02043 Along with registering online, for your own benefit, please also enter information about your bicycle below. Welcome to the Fifield e-Bike family! My bicycle model: _____________________________________________ My dealer and #: _______________________________________________ Date of purchase: ______________________________________________...
-
Page 4: Table Of Contents
Pg. 8 - 13 Switching ON/OFF LCD display screen Pedal assist Throttle Gears Proper battery usage Charging the battery Maintenance Pg. 14 - 16 Wheels Gears Throttle Rims Spokes Tires Handlebars Brakes General maintenance Warranty Pg. 17 Fifield Limited Warranty... -
Page 5: Know Your Electric Bicycle
Congratulations! on your bike; if any changes are You are now the proud owner of a noticed adjust your riding style Fifield Electric Bicycle! accordingly. When it is raining or snowing, please increase braking Your electric bicycle is like any distance as a safety precaution. -
Page 7: Taking Off
Check your e-bike before riding WARNING everytime Do not leave the key in the Before operating your electric battery lock while riding to avoid bicycle, inspect it carefully to avoid breaking the key. accidents or damage. Inspect your bike completely before each ride. Taking off CAUTION As the bike starts, accelerate... - Page 8 As you continue to ride, the battery will decrease porportionally based on the amount of power you are using. As the battery decreases, the bar will go down one by one. If the bar goes out completely, you can still pedal your e-bike just like a regular bike.
-
Page 9: Safe Riding
SAFE RIDING USE the correct hand signals when turning or stopping. If you do not Local riding laws know the proper hand signals, it is Most state and local areas important you learn them before have specific laws for cyclists. riding on the road. -
Page 10: Varying Riding Conditions
Varying riding conditions Wet conditions Like any other moving object, when it is wet or snowing, there is less traction. This applies specifically to the brakes on the bike; they will not perform as well as they do in dry climates. Be sure to brake earlier because it will take a longer distance to come to a full stop. -
Page 11: Assembly
ASSEMBLY When your Electric Bike is shipped, the handlebars will not be attached and the front wheel will be off. WE DO NOT RECOMMEND YOU ATTEMPT THIS ASSEMBLY YOURSELF. If assembly is done improperly you may damage the brakes, frame, and structural integrity of the bike. Please bring the bike to your closest local bike shop and allow a trained professional to assemble the bike for you. -
Page 12: Instructions For Use
INSTRUCTIONS FOR USE Switching ON/OFF Make sure your battery is secure and locked in place. Remove the key from the battery and switch it to ON. Underneath the handlebars there are three buttons; MODE, UP, and DOWN. To turn the device on, press and hold MODE for two seconds. - Page 13 Display Interface LCD Function Summary After starting up the display, The LCD screen provides a the default setting will show the wide range of functions and odometer. However, you are also indicators to the fit your needs. able to measure the distance of a The indicated contents are as single trip by pressing MODE once.
-
Page 14: Pedal Assist
Battery Indicator one speed throttle which will The five battery bars engage as soon as you start to represent the capacity of the apply pressure. To engage the battery. When the battery is low throttle, press down on the the battery frame on screen will throttle trigger with your thumb flash to notify that it needs to be while you are seated on the bike. - Page 15 Fifield is not responsible for Frequent braking/starting, damages caused by use of other riding uphill/against strong winds, products not specifically designed...
-
Page 16: Charging The Battery
dropping, or sudden jolts can The light on the battery will damage the charger and its appear RED to show that is not full. internal electronics. A full recharge typically takes 4 – 5 hours. When the battery is full, the Charging the battery light will change from red to It is important that you charge... - Page 17 DO NOT bump, drop, or damage charge cycle, the charger may reach temperatures up to 185°F the charger (85°C). BE SURE to keep out of the PRECAUTIONS while charging: reach of children ALWAYS use the charger IF you smell a peculiar smell or according to the instructions the temperature is too high, stop charging immediately by...
-
Page 18: Maintenance
MAINTENANCE “Assembly” section. If your gears Wheels are properly aligned and there are Wheels should be centered in issues with the derailleurs, please the fork or dropouts. If you hear bring the bike to your local any irregular noises from the mechanic for maintenance. -
Page 19: Tires
take it to a mechanic immediately. be properly in place; if your grips Riding with loose spokes may come off you could lose control of cause the wheel to be unbalanced your bicycle. and affect riding performance. Brakes Tires Riding with brakes and cables It is recommended that your that are worn or damaged, or tire pressure is at least 40 psi. - Page 20 smooth riding. When cleaning your electric bike, do not use a steady, direct, stream of water from a hose. Use a wet cloth instead to avoid short circuiting any electric components. Your electric bike has a durable finish and does not need to be waxed.
-
Page 21: Limited Warranty
LIMITED WARRANTY Every new Fifield e-bicycle comes with our warranty. Once your Fifield e-Bike is registered with Fifield Incorporated, we provide each original retail purchaser a warranty against defects in materials and workmanship, as stated below: 1 year Frame ... - Page 22 Welcome to the family.
