- Page 1 TABLE OF CONTENTS Fifield Fat Tire Owner’s Manual THIS MANUAL CONTAINS IMPORTANT SAFETY, PERFORMANCE, AND MAINTENANCE INFORMATION. READ THE MANUAL BEFORE TAKING YOUR FIRST RIDE ON YOUR NEW ELECTRIC BICYCLE, AND KEEP THE MANUAL HANDY FOR FUTURE REFERENCE.
- Page 2 Fifield directly. It is If the owner is unable to fully extremely important that you understand this information please follow the safety guidelines...
- Page 3 72 Sharp Street, Hingham, MA 02043 Along with registering online, for your own benefit, please also enter information about your bicycle below. Welcome to the Fifield e-Bike family! My bicycle model: _____________________________________________ My frame serial number: _________________________________________ My motor serial number: _________________________________________...
-
Page 4: Table Of Contents
Clearing the trip time and odometer Pedal assist Throttle Gears Integrated Bike Lock Proper battery usage Charging the battery Maintenance Pg. 20 - 21 Wheels Throttle Rims Spokes Tires Bike frame and handlebars Brakes General maintenance Warranty Pg. 22 Fifield Limited Warranty... -
Page 5: Before Your First Ride
If misused, the features of your using. electric bicycle may cause you to lose control of the e-bike. Before speeds up to 20MPH. Chain driven, the fat tire is Specifications equipped with 9-speed Shimano The Fat Tire comes standard with Alivio external gearing. This is... - Page 6 BEFORE YOUR FIRST RIDE Accessories The Fat Tire comes with an adjustable kickstand that can be extended or shortened. A USB charging outlet can also be found under theblack rubber cover at the base of the battery, labeled on page 3.
- Page 7 BEFORE YOUR FIRST RIDE...
-
Page 8: Taking Off
BEFORE YOUR FIRST RIDE Make sure that everything is Check your e-bike before riding fastened and secure. Be sure to everytime check that all quick releases are Before operating your electric locked and in good working order. bicycle, inspect it carefully to avoid accidents or damage. - Page 9 BEFORE YOUR FIRST RIDE turn the power off, it could easily damage the controller and motor. If you are not pedaling or using the throttle, there will be no power assist when traveling downhill. As you continue to ride, thebattery will continue to decrease proportionally based on the amount of power you are using.
-
Page 10: Safe Riding
SAFE RIDING KEEP both hands on the Always wear a helmet when handlebars at all times and do NOT riding on the road or off road hang objects from the handlebars. terrain as a safety measure. RIDE predictably and in a straight Local riding laws line. -
Page 11: Varying Riding Conditions
SAND/SNOW/MOUNTAIN Riding The fat tire bike has the capability of ring in the sand, snow, and on a mountain. Sand When riding in the sand. Keep your bike in a low gear and keep the bike moving. -
Page 12: Assembly
ASSEMBLY When the bike is delivered, it will come boxed partially assembled. We highly recommend bringing it to a bike shop for professional assembly. Un-boxing The bike will come with the front wheel detached and the handle bars detached as well. The pedals will be separate as well. Inside the box it will look like the image below. - Page 13 ASSEMBLY Pedals: The pedals will come in their own wrapping. Once unwrapped look inside the threaded section to determine what side of the bike the pedal goes on (depicted below). Attach the pedals by putting a washer on the threaded part o the pedal and using the provided wrench to tighten the pedals in their place.
- Page 14 ASSEMBLY Attach the front tire by lining the disc rotor on the same side as the brake caliper. Lift the front fork so it can come over the tire and rest on the skewer that goes through the front tire. Once the fork is resting on the skewer, tighten as needed.
- Page 15 ASSEMBLY located directly below the handlebars and above the front wheel on the front headset of the bike. The battery serial number can be found on the silver sticker on the battery itself.
-
Page 16: Instructions For Use
INSTRUCTIONS FOR USE Switching ON/OFF The fat tire comes with two varying LCD displays, depending on the model (350W or 500W). Refer to your model show below. 350W Mid-Drive Bike Display This model has a Bafang Display located in the center of the handle bars. - Page 17 ASSEMBLY To increase pedal assist, use the controller on the left side handle bar. Pressing the “+” button will increase the pedal assist, pressing the “-“ will decrease it. “0” pedal assist means the bike will provide no power assistance. Pedal Assist Adjustment LCD Backlight Power Button...
-
Page 18: Pedal Assist
INSTRUCTIONS FOR USE Pressing the “MODE” button will allow you to cycle through your average speed, maximum speed, and trip distance. To turn on the screen backlight, you must hold the “UP” arrow and the “MODE” button at the same time. To use the walk function of the bike (having the bike move while you walk next to it), press and hold the “DOWN”... - Page 19 INSTRUCTIONS FOR USE LCD Function Summary Push Cruise Control The LCD screen provides a wide Press and hold DOWN or “-“ to range of functions and indicators enable power assist while walking to the fit your needs. The indicated the bicycle. Your bike will go at a contents are as follows: ...
- Page 20 INSTRUCTIONS FOR USE 3. Press the “+” button to For more information on the LCD make the option “tc-y” screen, refer to our website to 4. This means “trip clear – download the extended version of yes” the manual. 5. Now double click the “I” button very fast (<0.3 Pedal assistance seconds in-between) to...
- Page 21 INSTRUCTIONS FOR USE temperature. Battery Frequent braking/starting, Your battery should be riding uphill/against strong winds, recharged after each use. The starting from a standstill, or riding battery is a 36V / 13.4 Amp lithium on rough/muddy roads will use ion battery The normal lifecycle of extra power and lower range.
-
Page 22: Charging The Battery
Do not attempt to access the Lithium battery in any way. Doing so may cause chemical, electric, and/or fire hazards. Fifield is not responsible for any damages caused by use of other products not specifically designed and tested for use with this electric bicycle. - Page 23 INSTRUCTIONS FOR USE and long battery life, unplug the replacement, please contact battery from the charger if you are Customer Service going to be gone for an extended DO NOT attempt to open or period of time. repair your charger if it is Do not leave the charger plugged malfunctioning into the battery for more than 10...
-
Page 24: Maintenance
Bike Frame and Handlebars Rims Before each ride ensure The Fat Tire comes with matte that the middle of the bike frame black finish rims for a sleek look, and the handlebars are straight and to hold the CST 4” tires. -
Page 25: General Maintenance
or wheels in poor condition, may General maintenance result in losing control of your Change the lubricating grease bicycle. Wet weather may hinder of the front axle, back-shaft, and the brake performance. Be sure pivot once every three months. you allow for more distance to Pour a small amount of mineral oil safely stop in the wet or icy every half a year into the brake... -
Page 26: Warranty
LIMITED WARRANTY Every new Fifield e-bicycle comes with our warranty. Once your Fifield e-Bike is registered with Fifield e-Bicycle Incorporated, we provide each original retail purchaser a warranty against defects in materials and workmanship, as stated below: 2 year ... - Page 27 Welcome to the family.
