Nitto MYTON MAG-25B Instruction Manual

PNEUMATIC ANGLE GRINDER
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
MYTON
Model
PROFESSIONAL TOOL
Model
Maximum Operating Pressure
Air Consumption
Rated Speed (No load)
Depressed Center
Grinding Wheel
Mass (Weight)
Sound Pressure Level
Sound Power Level
Vibration Level
Thread Size of Air Inlet
Due to continuous product development/improvement the specifications and configurations in this
document are subject to change without prior notice.
Keep the manual handy – so you can use it whenever necessary.
MAG-25B, MAGW-40, MAG-50, MAG-70
MAG-25B
MAG-50
Specifications
MAG-25B MAGW-40 MAG-50
MPa
3
(No Load) m /min
3
(Full Load) m /min
-1
min (r/min)
Diameter mm (inch)
Hole mm (inch)
kg
dB (A)
dB (A)
2
Body m/s
2
Handle m/s
MAGW-40
0.6
0.4 0.68
– 0.82
22,000 13,000 12,000
58 (2.3) 100 (4) 125 (5)
9.6 (3/8) 16 (5/8) 22 (7/8)
0.55 1.6
81 86
92 97
0.3 1.0
– –
Rc1/4 Rc3/8 Rc3/8
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
TEL : (81)-3-3755-1111
FAX : (81)-3-3753-8791
E-mail : overseas@nitto-kohki.co.jp
URL : www.nitto-kohki.co.jp
Original Instructions
MAG-70
MAG-70
0.87 0.69
– 1.15
7,100
180 (7)
22 (7/8)
2.2 3.4
84 80
95 91
0.9 0.8
1.3 5.2
Rc3/8
