P
roduct Overview
SST-LC13
ST-LC13

Specification:

ecification:
Material: Aluminum front panel, 1.0mm SECC body
Material: Aluminum front panel, 1.0mm SECC body
EC
b
Color: Black & Silver
Color: Black & Silver
Motherboard: Extended ATX*, ATX, Micro ATX
Drive Bay: External - 5.25" x 2 / 3.5" x 2
Internal - 3.5" x 2
Cooling System: Front - 92mm intake, 2100rpm, 21dBA
Rear - 2 x 60mm exhaust, 3000rpm, 25dBA
Expansion Slot: 7
Front I/O Port: USB2.0 x 2, IEEE1394 x 1, audio x 1, MIC x 1
Power Supply: Optional standard PS2 (ATX)
Net Weight: 9 kg
Dimension: 430 mm (W) x 163 mm (H) x 430 mm (D)
* LC13 has mounting holes for extended ATX motherboards, but it does not fully support all available extended ATX motherboards
on the market. The use of extended ATX motherboard will also require the removal of 3.5" drive bay

Disassemble Chart

TOP PANEL
6025 FAN * 2
PS2 POWER SUPPLY
STANDARD ATX M/B
9225 FAN
3.5 BAY * 1 (HIDDEN)
3.5 BAY * 2
3.5 BAY * 1 ( HIDDEN )
5.25 BAY * 2
DOOR
FRONT IO (USB * 2+1394 + AUDIO)
5.25 BAY * 2
POWER SW
February , 2005
ation
LC13
NO:11400110
