Stealthbox SB-F-MUCUPE/13W3v3 Installation Manual

I N S T A L L A T I O N G U I D E
for the
SB-F-MUCUPE/13W3v3
2005-2009 Ford Mustang Coupe
SB-F-MUCONV2/13W3v3
2005-2009 Ford Mustang Convertible
Thank you for choosing a JL Audio Stealthbox
proper installation, your new vehicle-specific enclosed subwoofer system will deliver years
of listening pleasure.
We strongly recommend that you have your new Stealthbox
JL Audio dealer. The installation professionals employed by your dealer have the necessary
tools and experience to disassemble and reassemble your vehicle properly. Also, keep in
mind that your warranty coverage extends to 2 year if your system is installed or approved
by your authorized JL Audio dealer. If you prefer to perform your own installation,
please read this installation guide completely before beginning the process.
for your automotive sound system. With
®
installed by your authorized
®
SB-F-MUCUPE/13W3v3_SB-F-MUCONV2/13W3v3 INSTR_SKU# 011216
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
INSTALLATION
1
D I F F I C U L T Y :
S T E P 1
Remove any contents from the trunk.
S T E P 2
Flip up the passenger's side corner of the trunk flooring and
remove the exposed a black rubber grommet.
S T E P 3
Lay the trunk flooring back into the corner. Feel for the hole
exposed in STEP 2 and cut the flooring at the hole.
Continued on Next Page
OUT
5
OF
