VnM 4 SignMaker Setup
Connecting VnM®4 Keypad and Power Up
1. Place printer on a flat and secure surface.
2. Make sure the power switch is OFF.
3. Connect VnM4 Keypad to the VnM4 SignMaker RS-232 serial port.
4. Plug power cord into AC power cord socket at the rear of printer then
plug power cord into a properly grounded power outlet.
Plug
USB
Power Switch
Power Cable
Paralle RS232
Power Supply
Optional Battery Pack
7
