Optical-Thermal Radio Detector
2100RFT-AS
• Combination of optical and thermal
characteristics of fi re
• Alarm temperature 58°C
• High range of radio transmission
• 2 frequency bands with
24 bidirectional data channels
• Communication with RF Interfaces
M500RFE-AS and M400RFE-AS
• Base included
Description
The Optical-Thermal Radio Detector 2100RFT-AS uses
both an optical sensing chamber based on the scattered
light principle as well as a separate thermal max detec-
tion unit with an alarm temperature of 58°C. The detec-
tor communicates with the RF Interfaces M500RFE-AS
or M400RFE-AS via a secured radio protocol. The ac-
tivated condition of the detector is optically indicated
by an LED. The radio detector is especially suitable for
areas, where cabling is impossible or uneconomical.
4 data channels in the frequency band 868MHz as well
as 20 channels in the frequency band 434MHz are avai-
Specifi cations
Operating voltage
Alarm temperature
Range of radio transmission (free air)
Frequency band
Ambient temperature
Dimensions ø × H
Colour
Weight (without batteries)
Approval
Order number
Order name
Lithium battery 3V
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
lable for the bidirectional data transmission. The avai-
lability of the channel is checked regularly. During the
learning phase of the detector, i.e., when the detector
is registered at the radio interface, a unique key, based
on a choice of several million codes, is created, which
allows the unambiguous identifi cation of the detector.
Regular status messages, monitoring of the battery vol-
tage and the long life of the batteries ensure the high
reliability of the system.
The detector is designed for indoor mounting and is
delivered with a mounting base, however, batteries are
not included.
2 lithium batteries 3V, type CR123, battery life approx. 1.5 years
58°C
300m
868MHz or 434MHz
0°C to +40°C
140 × 55 (mm)
white
187g
VdS G204105
241036
Optical-Thermal Detector/RF/complete 2100RFT-AS
249215
Battery for 2100RFT-AS CR123
A
2100RFT-AS_DBL_LST_EN_0804.PDF • PAGE 1
