TD-W8951ND
•
Current Pool Summary: Click the button, then you can view the IP addresses that the
DHCP Server gives out.
•
IP Pool Count: The max user pool size.
•
Lease Time: The length of time for the IP lease. After the dynamic IP address has
expired, the user will be automatically assigned a new dynamic IP address. The default is
259200 seconds.
•
Physical Ports: If a physical port is unchecked, the client connected to that port will not
be able to obtain IP address automatically although the DHCP function is enabled. All the
ports are checked by default.
DHCP Table: The information of the DHCP clients will be displayed here
•
Hostname: Display the name of the DHCP client.
•
IP Address: Display the IP Address of the DHCP client.
•
MAC Address: Display the MAC Address of the DHCP client.
•
Status: Display the status of the assigned IP Address, either Static or Auto. Static
indicates that the IP Address is bounded to the MAC Address, while Auto indicates that
the IP Address is assigned to the MAC Address automatically.
How to assign a static IP address to the client?
1). Select an IP Address from the drop-down list.
2). Enter the MAC Address of the client in the table.
DNS Relay: If you want to disable this feature, you just need to set both Primary and
secondary DNS IP to 0.0.0.0. If you want to use DNS relay, you can setup DNS server IP to
192.168.1.1 on their Computer. If not, the device will perform as no DNS relay.
•
Primary DNS Server: Type in your preferred DNS server.
•
Secondary DNS Server: Type in your preferred DNS server.
Note:
If Use Auto Discovered DNS Server Only is selected in DNS Relay, this modem router will
accept the first received DNS assignment from one of the PPPoA, PPPoE or MER/DHCP enabled
PVC(s) during the connection establishment. If Use User Discovered DNS Server Only is
selected in DNS Relay, it is necessary for you to enter the primary and optional secondary DNS
server IP addresses. After type in the address, click SAVE button to save it and invoke it.
Radvd: Radvd (Router Advertisement Daemon) is provided to assign IPv6 addresses to the
computers in your LAN. Enable this function if you need.
