LSI SAS LSISAS6160 User Manual

Sas switch
Hide thumbs Also See for SAS LSISAS6160:
Table of Contents

Advertisement

Quick Links

See also: User Manual
LSISAS6160 SAS Switch
User Guide
Revision 1.1
September 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAS LSISAS6160 and is the answer not in the manual?

Questions and answers

Related Manuals for LSI SAS LSISAS6160

Summary of Contents for LSI SAS LSISAS6160

  • Page 1 LSISAS6160 SAS Switch User Guide Revision 1.1 September 2010...

  • Page 2: Revision History

    LSI Corporation reserves the right to make changes to the product(s) or information disclosed herein at any time without notice. LSI Corporation does not assume any responsibility or liability arising out of the application or use of any product or service described herein, except as expressly agreed to in writing by LSI Corporation; nor does the purchase, lease, or use of a product or service from LSI Corporation convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Corporation or of third parties.

  • Page 3: Table Of Contents

    3.6.4 Manually Configure Zone Sets ..................46 LSI Corporation...
  • Page 4 Chapter 5: Troubleshooting .......................73 Page 4 LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 5: Chapter 1: Overview

    This document is the primary reference for the LSISAS6160 Serial Attached SCSI (SAS) switch. It describes the features of the switch and explains how to perform installation and physical configuration of the switch. The document also explains how to use both the web-based, and the command-driven SAS Domain Manager (SDM) utility interfaces to create storage configurations in the SAS domain.

  • Page 6: Serial Attached Scsi And The Sas6160 Switch

    SAS and SATA drives, and smaller cables and connectors. In SAS storage environments, the SAS6160 switch allows connection of multiple targets and initiators through a switched device for manageable scalability. The integrated SDM application provides a central management point to view the SAS topology, manage other switches or expanders in the domain, and to configure zoning to provide exclusive access between endpoints in the domain.
  • Page 7 In this simplified representation, the servers at the top of the diagram must access data on the storage devices in the lower part of the diagram. The SAS6160 switch manages the SAS configuration, allowing both servers to access all storage devices. Or, if zoning is used, single application servers can access specific storage devices exclusively.
  • Page 8 You can connect multiple SAS6160 switches in various topologies to provide failover support and to increase the number of connected devices in the SAS domain. The theoretical upper limit of SAS devices in a domain is 16,000. Each SAS6160 switch can handle 1000 SAS addresses.

  • Page 9: Sas Phys, Ports, And Connectors

    LSISAS6160 SAS Switch User Guide SAS Phys, Ports, and Connectors LSI Corporation September 2010 Flash Memory – Each LSISA2x36 expander connects to a parallel flash through the expander’s external memory interface. This flash is used for firmware storage and execution, as well as nonvolatile data such as Ethernet MAC address and SAS WWID.
  • Page 10 Figure 5: Narrow and Wide SAS Ports The SAS6160 switch has 64 phys, numbered 0 through 63. Each of the 16 SAS connectors on the switch case (numbered 0 through 15 in this document) contains four phys, making them wide ports.

  • Page 11: Sas Connectors And Cabling

    LSI Corporation September 2010 Use a separate crossover cable for each server, JBOD, RAID array, switch, or other device connected to the SAS6160 switch. Use Mini SAS 4x connectors (also called SFF-8088 connectors) on both ends of the crossover cables to connect the switch to all devices.

  • Page 12: Sas Routing And Zoning

    Page 12 SAS is a connection-oriented, point-to-point technology. When a host (initiator) issues a request to read or write data, the SAS6160 switch automatically determines how to route the connection request from the initiator to the correct data storage device (target).

  • Page 13: Creating Sas Zones

    LSISAS6160 SAS Switch User Guide 1.5.2 Creating SAS Zones LSI Corporation September 2010 The following figure shows a simple example of zoning. Figure 7: Simple Zoning Example You create SAS zones by first creating zone groups that include hosts or storage devices that share common access privileges, and zone sets that connect the zone groups together.
  • Page 14 The switch does not do this task automatically. Changes to the active zone set do not take effect until the zone set is updated and reactivated.

  • Page 15: Configuring Sas Zones

    LSISAS6160 SAS Switch User Guide 1.5.3 Configuring SAS Zones LSI Corporation September 2010 The following figure shows a sample configuration with three hosts and five JBODs. Figure 8: Configuration for Zoning Example Host 1 belongs to a local work group and accesses JBOD 1 as its primary resource. But Host 1 also accesses JBOD 2, JBOD 3, and JBOD 4, as a backup resource.

  • Page 16: Connecting Devices To The Sas6160 Switch

    Zone group 6 accesses zone groups 8 and 9, and vice versa. Zone group 7 accesses zone groups 9 and 10, and vice versa. The rules for connecting devices to the 16 SAS connectors on the SAS6160 switch are as follows: Any SAS initiator can be connected to any SAS connector on the switch.
  • Page 17 Figure 10: Example 1, Multiple Servers and JBODs A single rack can contain the switch and all the other devices. The configuration requires nine SAS cables with a Mini SAS connector on each end. Depending on the way in which zoning is set up for the devices, all servers could access data on all the JBODs, or servers could be restricted to accessing a subset of the JBODs.
  • Page 18 The third example (Figure 12) shows eight servers and one cascading switch connected to the SAS6160 switch. Several JBODs and RAID arrays connect to the other switch. NOTE: Example 5 and example 6 also show configurations with cascading switches.
  • Page 19 This dual porting configuration provides the server a redundant path through the switches for high availability. If one of the switches or connections fails, the server can still access the JBOD through the other connection. LSI Corporation September 2010 Page 19...
  • Page 20 You can use the SDM utility to modify and expand the storage configuration. NOTE: For zoning to function correctly, you must cable SAS6160 switches directly to one another, or through SAS 2.0 zoning expanders. Page 20 LSI Corporation September 2010...
  • Page 21 Example 6, Cascaded Switches Like in Example 3, the cables in this example can run from any connector of the downstream switch to any connector in the switch above it. The cascade sequence is limited to four switches. LSI Corporation...
  • Page 22 Example 7 (Figure 16) shows a star (tree) configuration of four switches, with switch B, switch C, and switch D connected directly to switch A. Like in Example 6, this example assumes that various SAS targets and SAS initiators are attached to the other connectors on the switches.)

  • Page 23: Chapter 2: Installation And Hardware Setup

    LED and an activity LED for each of the 16 SAS connectors. There is also a power status LED for the switch, and a rate LED and activity LED for the Ethernet connector. A reset pinhole allows reloading the factory defaults, which also requires power cycling the switch (see Chapter 5,...

  • Page 24: Sas6160 Connectors

    Install the SAS6160 switch in a site free from strong electromagnetic field generators (such as motors), vibration, and dust. Allow some space at the back of the switch (where the fans intake air) for proper ventilation. The AC power adapter is rated at 100 V to 240 V, and 50 Hz to 60 Hz.

  • Page 25: Installing The Sas6160 Self

    LSISAS6160 SAS Switch User Guide 2.3.1 Installing the SAS6160 Self LSI Corporation September 2010 Chapter 2: Installation and Hardware Setup A special shelf is available for mounting one or two SAS6160 switches in a standard rack. These options are shown in the following figure.
  • Page 26 4. Finally, place the SAS6160 switch and its inline power supply on the shelf. The switch enclosure fits onto a raised rib on the shelf to hold it securely in place. When power is available at the connector side of the switch, route power cords along the enclosure on the far left or far right of the shelf.

  • Page 27: Connecting To A Host

    — Use a crossover RJ-45 cable, if connecting directly to a computer. 2. Plug the other end of the RJ-45 cable into an Ethernet hub/switch or a computer. Use a web browser (Microsoft® Internet Explorer®, or Mozilla® Firefox®) on the host.

  • Page 28: Setting A Dynamic Ip Address

    3. Exit SDM-CLI and power cycle the switch. Using SDM-GUI 1. Login to SDM_GUI using the admin account. 2. From the Devices tab, select the switch. Write down the switch SAS address for possible reference and identification later. 3. Click on the Operations tab.

  • Page 29: Connecting Sas And Sata Hardware

    LSI Corporation, is not responsible for any radio or television interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by LSI.

  • Page 30: Canada Mark

    Chapter 2: Installation and Hardware Setup Safety Notices 2.7.2 Canada Mark 2.7.3 VCCI 2.7.4 BSMI Page 30 LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 31: Ccc

    LSISAS6160 SAS Switch User Guide 2.7.5 LSI Corporation September 2010 电池警示认证 注意事项: 如果电池未正确安装，可能有爆炸的危险。请选用与制造商所推荐相同或相等型式 的电池来进行替换。请依据制造商的指示处理使用过的电池。 Chapter 2: Installation and Hardware Setup Safety Notices Page 31...
  • Page 32 Chapter 2: Installation and Hardware Setup Safety Notices LSISAS6160 SAS Switch User Guide Page 32 LSI Corporation September 2010...

  • Page 33: Chapter 3: Sas Domain Manager Graphical User Interface

    The SAS6160 switch’s zone manager password is handled separately. Its default password is lynx. Follow these steps to start SDM-GUI: 1. Open a web browser and point it to the switch’s IP address or host name. Java Web Start downloads and launches the SDM-GUI automatically. The Password window appears.

  • Page 34: Summary Tab And Menu Options

    SDM-GUI, including the software version, the host name of the current server, and the login mode (admin or user). Embedded SDM only supports a single domain. LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 35: File, Server, And Help Menu Options

    LSISAS6160 SAS Switch User Guide File, Server, and Help Menu Options LSI Corporation September 2010 Chapter 3: SAS Domain Manager Graphical User Interface The menu bar at the top of the window provides you several options for managing the server. The available commands are as follows: Select File >>...

  • Page 36: Views Tab

    Zoned Portion of a Service Delivery Subsystem (ZPSDS), which is useful for zoning. Figure 2: End Device Table LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 37: View Alias Table

    LSISAS6160 SAS Switch User Guide 3.5.2 View Alias Table LSI Corporation September 2010 As shown in the following figure, the View Alias Table option displays a list of all aliases. Figure 3: Alias Table Chapter 3: SAS Domain Manager Graphical User Interface...

  • Page 38: View Zone Groups

    To view details about any zone group, select it in the list on the left. An asterisk at the end of a zone group name indicates that the zone group is currently active. Figure 4: View Zone Groups LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 39: View Zone Sets

    LSISAS6160 SAS Switch User Guide 3.5.4 View Zone Sets LSI Corporation September 2010 As shown in the following figure, the View Zone Sets option displays a list of zone sets. To view details about any zone set, select it in the list on the left. An asterisk at the end of a zone set name indicates that the zone set was active at the time of activation.

  • Page 40: Domain Tab

    To assign an alias, click on a node in the tree on the left of the window and type an alias of up to 24 characters in the field on the right. Click Apply to assign the alias. You can change existing aliases in addition to assigning new ones. LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 41: Automatically Configure Zone Groups And Zone Sets

    Automatically Configure Zone Groups and Zone Sets 3.6.2.1 Initiator Isolation Wizard LSI Corporation September 2010 Alias names must be unique and must not resemble valid SAS addresses (16 hexadecimal characters that start with the number 5). The only special characters you can use in an alias are pound (#), dash, and underscore.
  • Page 42 If phys on the edge of the ZPSDS are not associated with connectors, and have not formed into ports, individual phys are displayed in the selection list. Page 42 LSI Corporation September 2010...
  • Page 43 The wizard assigns to zone groups the names <zone set name> + #001, <zone set name> + #002, and so on. If the number of generated zone groups exceeds the maximum number of 248, the wizard displays an error message. LSI Corporation September 2010 Page 43...

  • Page 44: Manually Configure Zone Groups

    The list of unselected zone group members contains only the expanders that are inside the ZPSDS boundary. The unselected members list box contains only the phys that are inside the ZPSDS boundary. LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...
  • Page 45 Modify Zone Group 3.6.3.4 Delete Zone Group LSI Corporation September 2010 Use the View Zone Groups command to view information about zone groups. To view details about any zone group, select the group from the pull-down list on the left. An asterisk at the end of a zone group name indicates that the zone group was active at the time of activation.

  • Page 46: Manually Configure Zone Sets

    A phy can be a member of one zone group per zone set. To see the details of a particular zone group, click the zone group link in the left column of the matrix. Figure 10: Create Zone Set LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...
  • Page 47 View Zone Set 3.6.4.4 Modify Zone Set LSI Corporation September 2010 Use the View Zone Set command to view information about zone sets. To view details about any zone set, select it in the list on the left. An asterisk at the end of a zone set name indicates that the zone set was active at the time of activation.
  • Page 48 When activated, copies of the zone set and component zone groups are made. An asterisk at the end of a zone group name indicates that the zone group is currently active. Figure 12: Activate/Deactivate Zone Set LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...
  • Page 49 3.6.4.6 Delete Zone Set following figure, you delete a zone set by selecting the zone set from the list on the left of the window and then clicking Delete. Figure 13: Delete Zone Set LSI Corporation September 2010 Page 49...

  • Page 50: Devices Tab

    NOTE: If there is an active zone set, and if you click on an end device, all of the other end devices with which it has permission to communicate appear in blue. LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 51: Properties Tab

    LSISAS6160 SAS Switch User Guide 3.7.1 Properties Tab LSI Corporation September 2010 Figure 14 shows, the Properties tab displays information about the currently selected device in the tree in the left panel. Properties information includes SAS Address, Vendor ID, and Device Type. The rest of the displayed information varies, depending on the type of the selected device.

  • Page 52: Environmentals Tab

    The following figure shows an example of the type of data that appears on this tab. Environmental data, for each device that supports an SES target, is polled in a background loop. Figure 16: Environmentals Tab LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 53: Attached Devices Tab

    LSISAS6160 SAS Switch User Guide 3.7.3 Attached Devices Tab LSI Corporation September 2010 The Attached Devices tab appears for all expanders and end devices. This tab shows a list of devices directly connected to the selected device and the phys used in those connections.

  • Page 54: Phys Tab

    The following figure shows the Phys tab. Figure 18: Phys Tab To view detailed information about any phy, click on an entry in the Phy ID column. A pop-up window appears with detailed status information. LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 55: Zone Group Tab

    LSISAS6160 SAS Switch User Guide 3.7.5 Zone Group Tab LSI Corporation September 2010 The Zone Group tab becomes active if there is an active zone set, and if you click on an end device. In the following figure, the Zone Group tab is active because the selected initiator is a member of an active zone set.

  • Page 56: Operations Tab

    Figure 20: Operations Tab Use the Update Firmware command to update the firmware on LSI SAS expanders, LSI SAS2 expanders, and LSI SAS2 switches. SDM verifies that the product identification of the image matches the targeted device. SDM automatically resets the expander after a successful update.
  • Page 57 Figure 22: Enable/Disable/Reset Phys Use the Reset Switch command to reset the LSI SAS2 switch that is currently selected in the device tree. You must confirm the reset before it is executed. Chapter 3: SAS Domain Manager Graphical User Interface...
  • Page 58 Page 58 Devices Tab Use the Configure IP command to change the IP address for the LSI SAS2 switch that is currently selected in the device tree. You can set either a static or a dynamic IP address as shown in the following figures.

  • Page 59: Chapter 4: Sas Domain Manager Command Line Interface

    SDM-CLI has powerful, flexible commands that allow you to manage the host switch, and other switches or expanders within the domain in which the host switch resides. To start the embedded SDM-CLI, open a telnet session to the switch’s IP address or host name. You will be prompted to login.

  • Page 60: Sdm-Cli Commands

    (Extra-Domain) Use the help command to display the SDM-CLI command line help. Authority: User Syntax: help [<command>] Usage: help [<command>] Displays detailed help for a specific command if you provide the [<command>] name. Otherwise, it displays a list of all available commands. LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 61: Passwd Command

    4.2.4 Quit Command 4.2.5 Alias Command LSI Corporation September 2010 Chapter 4: SAS Domain Manager Command Line Interface (Extra-Domain) Use the passwd command to change the password for an account after prompting for the admin password. Passwords must have between four and 16 characters.

  • Page 62: Device Command

    Deletes all aliases. If you specify the [noconfirm] option, the deletion occurs immediately without an additional confirmation prompt. Otherwise, SDM first prompts you to confirm the action. (Intra-Domain) Use the device command to manage individual devices (LSI expanders) within the domain. Authority: Admin Syntax: device (<sas address>|<alias>) reset [noconfirm]...

  • Page 63: Show Command

    LSISAS6160 SAS Switch User Guide 4.2.7 Show Command LSI Corporation September 2010 Chapter 4: SAS Domain Manager Command Line Interface (Intra-Domain) Use the show command to display domain, device, and phy information. (See Section 4.3, Sample Output for Show the kind of information that is returned.)

  • Page 64: Zonegroup Command

    Otherwise, SDM first prompts you to confirm the action. zonegroup remove <name> (<sas address>|<alias>):<phy> Removes a phy from an existing zone group. zonegroup rename <old> <new> Renames an existing zone group. LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 65: Zoneset Command

    LSISAS6160 SAS Switch User Guide 4.2.9 Zoneset Command LSI Corporation September 2010 Chapter 4: SAS Domain Manager Command Line Interface (Intra-Domain) Use the zoneset command to manage zone sets and zone set membership. NOTE: Only the zoneset activate and zoneset deactivate commands affect the state of the active zone set.

  • Page 66: Sample Output For Show Command

    Alias ----------------------------------------------------- 500605b0006b75b0 Bacchus 50012be0000380ff Calhoun 500605b0000220bf Carrollton SDMCLI> show alias Calhoun SAS Address Alias ------------------------------------------ 50012be0000380ff Calhoun SDMCLI> show device NOTE: In the following example, ZExpander means zoning capable expander. LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 67: Show Device

    Zoning Expander: Yes Zoning Enabled: Yes Vendor Id: AstekCor Product Id: Snowcat-Brann Product Revision Level: 0100 Firmware Version: 3.1.0.0 Component Vendor Id: LSI Component Id: 547 Component Revision Id: 4 Table-to-Table Supported: Yes Sample Output for Show Com- mand Phys...

  • Page 68: Show Domain

    SAS6160 (500062b10000417f) SDMCLI> show phy NOTE: In the following example, T = Table, S = Subtractive, and D = Direct. 1.5|3.0|6.0 Gb/s - phy enabled but link uninitialized * phy disabled LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 69: Show Phy

    Rampart Rampart 4.3.7 show phy <alias> Notes: - RA - Routing Attributes - VP - Virtual PHY - Zone Grp LSI Corporation September 2010 Chapter 4: SAS Domain Manager Command Line Interface Alias / SAS Address Poydras Poydras Poydras Poydras...
  • Page 70 None 000000000 None 000000000 None 000000000 000000010 000000010 000000010 000000010 None 000000000 None 000000000 None 000000000 None 000000000 None 000000000 None 000000000 None 000000000 None 000000000 None 000000000 None 000000000 None 000000000 None 000000000 000000010 000000010 LSI Corporation September 2010...

  • Page 71: Show Phy :

    Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled 4.3.8 show phy <alias>: <phy> 4.3.9 show version LSI Corporation September 2010 Chapter 4: SAS Domain Manager Command Line Interface 5000c500176a32cd 5000c500176c9211 Poydras Poydras Poydras Poydras 50012be0000380fd ---------------- SDMCLI> show phy Lincoln:01...

  • Page 72: Show Zonegroup

    Zone Set Zone Group: Permitted Zone Group List Member Alias/SAS Address: Phy List ------------------------------------------ ZoneOne: ZoneOne#001: ZoneOne#002 Lincoln : 00 01 02 03 ZoneOne#002: ZoneOne#001 Lincoln : 08 09 10 11 LSISAS6160 SAS Switch User Guide LSI Corporation September 2010...

  • Page 73: Chapter 5: Troubleshooting

    September 2010 This chapter contains troubleshooting information for the LSISAS6160 SAS switch. The following table lists several common issues related to the SAS6160 switch and the remedies for them. Reset the switch to factory defaults by pressing the reset switch and power cycling the switch.

  • Page 74: Page 4 Lsi Corporation | September

    Chapter 5: Troubleshooting LSISAS6160 SAS Switch User Guide Page 74 LSI Corporation September 2010...
