LSISAS6160 SAS Switch
User Guide
Version 1.9
February 2014
DB15-000636-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSISAS6160 and is the answer not in the manual?

Questions and answers

Related Manuals for LSI LSISAS6160

Summary of Contents for LSI LSISAS6160

  • Page 1 LSISAS6160 SAS Switch User Guide Version 1.9 February 2014 DB15-000636-11...

  • Page 2: Revision History

    LSI Corporation reserves the right to make changes to the product(s) or information disclosed herein at any time without notice. LSI Corporation does not assume any responsibility or liability arising out of the application or use of any product or service described herein, except as expressly agreed to in writing by LSI Corporation; nor does the purchase, lease, or use of a product or service from LSI Corporation convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Corporation or of third parties.

  • Page 3: Table Of Contents

    LSISAS6160 SAS Switch User Guide Table of Contents February 2014 Table of Contents Chapter 1: Overview ......................5 1.1 LSISAS6160 Switch Features .
  • Page 4 LSISAS6160 SAS Switch User Guide Table of Contents February 2014 3.7.5 Phy Counters Tab ......................57 3.7.6 Zone Group Tab .

  • Page 5: Chapter 1: Overview

    Chapter 1: Overview This document is the primary reference for the LSISAS6160 Serial Attached SCSI (SAS) switch. It describes the features of the switch and explains how to install and physically configure the switch. The document also explains how to use both the web-based interface and the command-driven interface of the SAS Domain Manager (SDM) utility to create storage configurations in the SAS domain.
  • Page 6 LSISAS6160 SAS Switch User Guide February 2014 SAS and the LSISAS6160 Switch The LSISAS6160 switch is a half rack width and uses an external power supply. The following figure shows the LSISAS6160 switch. Figure 1 LSISAS6160 Switch The LSISAS6160 switch uses two LSISAS2x36 6Gb/s SAS expanders, which are compliant with the ANSI Serial Attached SCSI specification and support SATA as defined in the Serial ATA: High Speed Serialized AT Attachment and the Serial ATA II: Port Selector Specification.
  • Page 7 LSISAS6160 SAS Switch User Guide February 2014 SAS and the LSISAS6160 Switch The following figure shows how the LSISAS6160 switch centralizes management of all application servers and data storage devices in the SAS domain. Figure 2 LSISASS6160 Resource Management LSI Corporation...
  • Page 8 In this simplified representation, the servers at the top of the figure must access data on the storage devices in the lower part of the figure. The LSISAS6160 switch manages the SAS configuration, allowing both servers to access all storage devices. Or, if zoning is used, single application servers can access specific storage devices exclusively.

  • Page 9: Sas Phys, Ports, And Connectors

    LSISAS6160 SAS Switch User Guide February 2014 SAS Phys, Ports, and Connectors SAS Phys, Ports, and Connectors Phys and ports are a basic concept of SAS. A phy is the basic physical connection point for a SAS device. A phy contains a single transmitter and receiver, which communicate across a SAS link to a single transmitter and receiver in another phy, as the following figure shows.

  • Page 10: Sas Connectors And Cabling

    SAS Connectors and Cabling Use a crossover cable to connect the LSISAS6160 switch to a server or to another host device. Use 4x Mini SAS connectors (also called SFF-8088 connectors) on both ends of the crossover cable to connect the switch to the device.

  • Page 11: Sas Routing And Zoning

    LSISAS6160 switch automatically determines how to route the connection request from the initiator to the correct data storage device (target). By default, any SAS initiator or target connected to the LSISAS6160 switch can access any other connected initiator or target in the SAS domain, without restrictions. However, because the SAS domain grows to include multiple hosts and multiple storage volumes, you can segregate one host from another host, or restrict one host from accessing storage owned by another host.

  • Page 12: Creating Sas Zones

    LSISAS6160 SAS Switch User Guide February 2014 SAS Routing and Zoning Initiators and targets see only the portions of the ZPSDS to which they are assigned in the zone permission table. These zoned portions are called zone groups. Zone groups are activated when they belong to a set. When the set is enabled, the zoning is enforced.

  • Page 13: Configuring Sas Zones

    Changes to the active zone set do not take effect until the zone set is updated and reactivated. Zoning is managed throughout the ZPSDS formed around the LSISAS6160 switch, used to manage zoning, and ...

  • Page 14: Connecting Devices To The Lsisas6160 Switch

    Switches can be cascaded by connecting any SAS connector of the downstream switch to any SAS connector on  the upstream switch. When SAS zoning is used, and multiple LSISAS6160 switches are used in the domain, the switches can be cabled  directly to one another.
  • Page 15 LSISAS6160 SAS Switch User Guide February 2014 Connecting Devices to the LSISAS6160 Switch Six cascaded expanders, with each switch counting as one expander — Four cascaded switches — A total of 64 total expanders in the topology — LSI Corporation...
  • Page 16 February 2014 Connecting Devices to the LSISAS6160 Switch The following examples show several ways in which you can connect devices to the LSISAS6160 switch. Example 1 shows four servers (host bus adapters) and five JBODs connected to the LSISAS6160 switch.
  • Page 17 Figure 12 Example 3, Multiple Servers and a Cascading Switch Example 3 shows how you can cascade two LSISAS6160 switches to increase the number of devices in the SAS domain. As in Example 1, all of the servers can access all the data storage devices, or you can implement a zoning configuration to restrict the access.
  • Page 18 LSISAS6160 SAS Switch User Guide February 2014 Connecting Devices to the LSISAS6160 Switch Example 4 shows a high-availability configuration in which a server is connected through two LSISAS6160 switches to two input connectors on a JBOD. Figure 13 Example 4, High Availability Configuration This dual porting configuration gives the server a redundant path through the switches for high availability.
  • Page 19 SAS devices during device discovery. You can use the SDM utility to modify and expand the storage configuration. NOTE For zoning to function correctly, you must cable LSISAS6160 switches directly to one another, or you must cable them through SAS 2.0 zoning expanders.
  • Page 20 February 2014 Connecting Devices to the LSISAS6160 Switch Example 6 shows a daisy chain, or cascaded, switch, configuration with four LSISAS6160 switches. This example assumes that various SAS targets and SAS initiators are attached to the other connectors on the switches.
  • Page 21 LSISAS6160 SAS Switch User Guide February 2014 Connecting Devices to the LSISAS6160 Switch Example 7 shows a star (tree) configuration of four switches, with Switch B, Switch C, and Switch D connected directly to Switch A. As in Example 6...

  • Page 22: Chapter 2: Installation And Hardware Setup

    Identifying Switch Components The following figure shows the connectors and LEDs on the LSISAS6160 switch. Each of the 16 SAS connectors has a corresponding fault status LED and an activity LED. The switch also includes a power status LED, and a rate LED and activity LED for the Ethernet connector.

  • Page 23: Lsisas6160 Connectors

    Installing the LSISAS6160 Switch 2.2.1 LSISAS6160 Connectors All 16 connectors on the LSISAS6160 switch accept standard passive SAS cabling. The connectors at Port 0 and Port 2 are active, which permits longer cable lengths when using active SAS cabling. See Chapter 1, Overview, for an explanation of SAS connectors and cables.

  • Page 24: Installing The Lsisas6160 Shelf

    The AC power adapter is rated at 100 V to 240 V, and 50 Hz to 60 Hz.  2.3.1 Installing the LSISAS6160 Shelf A special shelf is available for mounting one or two LSISAS6160 switches in a standard rack. The following figure shows these options. Figure 18 Mounting LSISAS6160 Switches on a Rack-Mounted Shelf LSI Corporation...
  • Page 25 The mounting ears on the shelf itself are not threaded, so mount them with clip nuts. Place the LSISAS6160 switch and its inline power supply on the shelf. The switch enclosure fits onto a raised rib on the shelf to hold it securely in place. Slide the power supply into the enclosure.

  • Page 26: Connecting To A Host

    When power is available at the connector side of the switch, route power cords along the enclosure on the far left or far right of the shelf. The LSISAS6160 switch is now ready to connect to a host. Connecting to a Host...

  • Page 27: Changing The Ip Address

    LSISAS6160 SAS Switch User Guide February 2014 Changing the IP Address Changing the IP Address The default IP address initially identifies the LSISAS6160 switch on a network. To change the IP address, use either the SDM-GUI application (see Chapter SAS Domain Manager Graphical User...

  • Page 28: Connecting Sas And Sata Hardware

    LSISAS6160 switch to individual SAS HDD drives or SATA HDD drives, but you can connect one direct attach tape drive to any odd-numbered port (the lower row). You can use any SAS port on the LSISAS6160 switch to cascade to any port on another LSISAS6160 switch to increase the size of the storage configuration.

  • Page 29: Fcc

    LSI Corporation is not responsible for any radio or television interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by LSI. It is your responsibility to correct interference caused by such unauthorized modification, substitution, or attachment.

  • Page 30: Bsmi

    LSISAS6160 SAS Switch User Guide February 2014 Safety Notices 2.7.4 BSMI 2.7.5 电池警示认证 注意事项: 如果电池未正确安装，可能有爆炸的危险。请选用与制造商所推荐相同或相等型式 的电池来进行替换。请依据制造商的指示处理使用过的电池。 LSI Corporation - 30 -...

  • Page 31: Chapter 3: Sas Domain Manager Graphical User Interface

    LSISAS6160 switch. The SDM-GUI utility is a Java® Web Start® application, and the LSISAS6160 functions as an HTTP server that launches the utility. To run SDM-GUI from a browser, point the browser to the switch’s IP address. SDM-GUI uses TCP/IP port 5573 to communicate with the LSISAS6160 switch.

  • Page 32: Summary Tab And Menu Options

    LSISAS6160 SAS Switch User Guide February 2014 Summary Tab and Menu Options Summary Tab and Menu Options The following figure shows the SDM main window, with the menu bar and Summary tab. Figure 21 SDM-GUI Main Window The Summary tab lists the Server Host Name (the IP address of the switch on which SDM-GUI is running), the domain status and domain ID, the overlay name, and other information.

  • Page 33: File, Server, And Help Menu Options

    LSISAS6160 SAS Switch User Guide February 2014 File, Server, and Help Menu Options File, Server, and Help Menu Options The menu bar at the top of the SDM-GUI window provides several options for managing the server. The available commands are as follows: Select File >...
  • Page 34 LSISAS6160 SAS Switch User Guide February 2014 File, Server, and Help Menu Options Figure 22 Graphical View To view a list of device properties, position the mouse on top of a device icon. To view a pop-up menu of possible actions, right-click the mouse on a device icon.

  • Page 35: Views Tab

    LSISAS6160 SAS Switch User Guide February 2014 Views Tab Views Tab The Views tab displays information about the domain, including the end device table, the alias table, zone groups, and zone sets. This information is available to both admin and user accounts.

  • Page 36: View Alias Table

    LSISAS6160 SAS Switch User Guide February 2014 Views Tab 3.5.2 View Alias Table As shown in the following figure, the View Alias Table option displays a list of all aliases. Figure 24 Alias Table LSI Corporation - 36 -...

  • Page 37: View Zone Groups

    LSISAS6160 SAS Switch User Guide February 2014 Views Tab 3.5.3 View Zone Groups As shown in the following figure, the View Zone Groups option displays a list of zone groups. To view details about any zone group, select it from the list on the left of the window. An asterisk following a zone group name indicates that the zone group is currently active.

  • Page 38: View Zone Sets

    LSISAS6160 SAS Switch User Guide February 2014 Views Tab 3.5.4 View Zone Sets As shown in the following figure, the View Zone Sets option displays a list of zone sets. To view details about any zone set, select it from the list on the left of the window. An asterisk at the end of a zone set name indicates that the zone set was active at the time of activation.

  • Page 39: Domain Tab

    LSISAS6160 SAS Switch User Guide February 2014 Domain Tab Domain Tab The Domain tab, which is available only in the admin account, has commands that manage aliases, zone groups, and zone sets. In addition, it has several wizards for domain configuration and management tasks. To use the specific commands described in this section, click the hyperlinks on the Domain tab.
  • Page 40 LSISAS6160 SAS Switch User Guide February 2014 Domain Tab Select alias names that are unique and that do not resemble valid SAS addresses (16 hexadecimal characters that start with the number 5). The only special characters you can use in an alias are # (pound), - (dash), and _ (underscore). The tree displays aliases only for the devices presently in the domain.

  • Page 41: Automatically Configure Zone Groups And Zone Sets

    LSISAS6160 SAS Switch User Guide February 2014 Domain Tab 3.6.2 Automatically Configure Zone Groups and Zone Sets Zoning wizards simplify zone set creation. The Automatically Configure Zone Groups command and Zone Sets command include three wizards that automate the configuration of zone groups and zone sets.
  • Page 42 LSISAS6160 SAS Switch User Guide February 2014 Domain Tab NOTE If phys on the edge of the ZPSDS are associated with connectors, their connectors are displayed in the selection list. If phys on the edge of the ZPSDS are not associated with connectors, but they have formed into ports (they are connected to a device), ports appear in the selection list.

  • Page 43: Manually Configure Zone Groups

    LSISAS6160 SAS Switch User Guide February 2014 Domain Tab 3.6.3 Manually Configure Zone Groups The Manually Configure Zone Groups commands enable you to manually create, view, modify, and delete zone groups. These commands provide greater control of zone set creation, and permit an administrator to edit an existing zone set or zone group.
  • Page 44 LSISAS6160 SAS Switch User Guide February 2014 Domain Tab 3.6.3.2 View Zone Groups The View Zone Groups command displays information about zone groups. To view details about any zone group, select the group from the pull-down list on the left of the window. An asterisk at the end of a zone group name indicates that the zone group was active at the time of activation.

  • Page 45: Manually Configure Zone Sets

    LSISAS6160 SAS Switch User Guide February 2014 Domain Tab 3.6.4 Manually Configure Zone Sets Use the Manually Configure Zone Sets commands to manually create, view, activate, deactivate, and delete zone sets. 3.6.4.1 Synchronize Zone Manager Password Before you can activate zoning, you must use the Synchronize Zone Manager Password command to synchronize the zone manager password of all the zoning expanders and switches in the domain, for example, in JBODs and other switches.
  • Page 46 LSISAS6160 SAS Switch User Guide February 2014 Domain Tab 3.6.4.2 Create Zone Set Use the Create Zone Set command to create a new zone set. You can click on the matrix to indicate that both zone groups in the associated row/column can communicate with one another. A blank cell indicates that the two zone groups are not allowed to communicate.
  • Page 47 LSISAS6160 SAS Switch User Guide February 2014 Domain Tab 3.6.4.4 Modify Zone Set Use the Modify Zone Set command to modify existing zone sets. As shown in the following figure, the Modify Zone Set window lets you give or revoke the permission to communicate among the zone groups. You also can rename an existing zone set.
  • Page 48 LSISAS6160 SAS Switch User Guide February 2014 Domain Tab 3.6.4.5 Activate/Deactivate Zone Set Use the Activate/Deactivate Zone Set command to activate or deactivate a zone set. Only one zone set can be active at a time, and a zone set must be active for its definitions to be applied to the domain. Changes to the active zone set or zone group permissions do not take effect until the next zone set activation.
  • Page 49 LSISAS6160 SAS Switch User Guide February 2014 Domain Tab 3.6.4.6 Delete Zone Set Use the Delete Zone Set command to delete an existing zone set. As shown in the following figure, you delete a zone set by selecting the zone set from the list on the left of the window and then clicking Delete.

  • Page 50: Devices Tab

    LSISAS6160 SAS Switch User Guide February 2014 Devices Tab Devices Tab The Devices tab displays the domain topology in the form of a tree. Select items in the tree to access a secondary set of tabs that can include Properties, Environmentals, Attached Devices, Phys, Operations, and SNMP. The tabs displayed on this row depend on both the account type and the device selected in the tree.

  • Page 51: Properties Tab

    LSISAS6160 SAS Switch User Guide February 2014 Devices Tab To view a list of the symbols used to represent devices in the domain, click the blue word legend in the upper left of the window. The following figure shows the list of symbols.

  • Page 52: Environmentals Tab

    When the temperature or voltage falls or rises to meet a set threshold value, the element enters either a noncritical warning state or a critical state. Temperature Threshold The temperature threshold range for the LSISAS6160 switch is 1 °C to 79 °C. Threshold values outside this range are not accepted. Voltage Threshold Enter voltage values as a percentage.
  • Page 53 Figure 38 Threshold Values The LSISAS6160 switch firmware does not support changing the overall threshold. Expand the temperature icon or the voltage icon to get the actual elements, as shown in the following figure. The actual elements support the overall threshold.
  • Page 54 LSISAS6160 SAS Switch User Guide February 2014 Devices Tab Figure 39 Supporting Threshold Elements LSI Corporation - 54 -...

  • Page 55: Attached Devices Tab

    LSISAS6160 SAS Switch User Guide February 2014 Devices Tab 3.7.3 Attached Devices Tab The Attached Devices tab appears for all expanders and end devices. This tab shows a list of devices directly connected to the selected device and the phys used in those connections.

  • Page 56: Phys Tab

    LSISAS6160 SAS Switch User Guide February 2014 Devices Tab 3.7.4 Phys Tab The Phys tab, which appears for expanders, lists information about the phys on the selected expander. The following figure shows the Phys tab. Figure 41 Phys Tab To view detailed information about any phy, click on an entry in the Phy Id column. A pop-up window appears with detailed status information.

  • Page 57: February

    LSISAS6160 SAS Switch User Guide February 2014 Devices Tab 3.7.5 Phy Counters Tab The Phy Counters tab, which appears for expanders, lists information about the phy error counters on the selected expander. The following figure shows the Phy Counters tab.

  • Page 58: Zone Group Tab

    LSISAS6160 SAS Switch User Guide February 2014 Devices Tab 3.7.6 Zone Group Tab The Zone Group tab becomes active if there is an active zone set and if you click on an end device. In the following figure, the Zone Group tab is active because the selected initiator is a member of an active zone set. In the device tree, the devices that can communicate with each other appear in blue.

  • Page 59: Operations Tab

    The Operations tab appears only when you select an expander from an admin account. The following figure shows the commands that are listed in this tab when the LSISAS6160 switch is selected. The commands vary depending on the selected device type.
  • Page 60 Upload Firmware Use the Upload Firmware command to upload the firmware from LSI SAS 2.0 expanders and LSI SAS 2.0 switches. The following figure shows the third step of the update process: saving the file as an expander firmware image.
  • Page 61 LSISAS6160 SAS Switch User Guide February 2014 Devices Tab 3.7.7.3 Enable/Disable/Reset Phys Use the Enable/Disable/Reset Phys command to enable, disable, or reset specified expander phys. To disable one or more phys, remove the check mark in the Enabled column and click Apply. To reset one or more phys, select the check box in the Reset column and click Apply.
  • Page 62 February 2014 Devices Tab 3.7.7.4 Reset Switch Use the Reset Switch command to reset the LSI SAS 2.0 switch that is currently selected in the device tree. You must confirm the reset command. 3.7.7.5 Configure IP Use the Configure IP command to change the IP address for the LSI SAS 2.0 switch that is currently selected in the device tree.
  • Page 63 LSISAS6160 SAS Switch User Guide February 2014 Devices Tab Figure 49 Set a Dynamic IP Address 3.7.7.6 Get Date Use the Get Date command to obtain the switch date. SDM-GUI shows the device date in a user-friendly format. 3.7.7.7 Set Date Use the Set Date command to set the switch date.
  • Page 64 3.7.7.9 Performance Monitoring The LSISAS6160 switch supports event counters for performance monitoring and error monitoring on all switch phys. An event counter can be configured to count one specific SAS event, such as transmitted SSP frames. Each phy can have up to four event counters configured at a time. A configuration that specifies four event counters is a config set.
  • Page 65 LSISAS6160 SAS Switch User Guide February 2014 Devices Tab Figure 51 Display Performance Monitoring Config List LSI Corporation - 65 -...
  • Page 66 LSISAS6160 SAS Switch User Guide February 2014 Devices Tab Set Config – The Set active Performance Monitoring Config command, shown in the following figure, lets you apply  a different monitoring configset. You can select the time base (in seconds) for monitoring. Changing the time base changes how often the switch firmware updates the monitored values.
  • Page 67 LSISAS6160 SAS Switch User Guide February 2014 Devices Tab Read – The Read performance and error monitor values command returns the current performance value and the  error monitor value. As shown in the following figures, SDM-GUI prompts you for the starting phy and a phy range.

  • Page 68: Snmp/Smtp Tab

    The MIB is stored in a set of files that are provided to an SNMP server to describe the SNMP interface for the switch. The file set is included on the CD with the switch and is available for download on the LSI website. This specification instead defines the high-level object identifiers (OID) tree.
  • Page 69 LSISAS6160 SAS Switch User Guide February 2014 Devices Tab Agent Security Use the Agent Security command to configure the SNMP agent. The application provides an option for whether the agent uses a community string/username. The SNMP agent has the following support: Supports enterprise objects, organized under the node 3582.200.
  • Page 70 LSISAS6160 SAS Switch User Guide February 2014 Devices Tab System MIB Use the System MIB command to change the settings in the SNMP system MIB configuration page. Any of the three strings can be set to empty. The following figure shows the System MIB screen.
  • Page 71 The string length is limited to 256 characters. Custom Subject Prefix – This field permits the user to add up to a 32-character prefix to the subject field. The  default for a standard LSI switch is LSI SAS 616X Alert. Authentication ...
  • Page 72 LSISAS6160 SAS Switch User Guide February 2014 Devices Tab The following figure shows the SMTP Server Configuration screen. Figure 59 SMTP Server Configuration Create/Modify Target Email Address Use this screen to create and modify emails. Target Email Address – This field contains a valid email address target for email alerts. Each valid target address ...

  • Page 73: Configuration Backup And Restore

    LSISAS6160 SAS Switch User Guide February 2014 Configuration Backup and Restore Figure 60 Create/Modify Emails View/Delete Target Email Address Use this screen to view and delete emails. NOTE The SMTP client in the switch requires an SMTP server in the network for sending and receiving emails.

  • Page 74: Restore

    LSISAS6160 SAS Switch User Guide February 2014 Configuration Backup and Restore 3.8.1 Restore Use this feature to restore zone groups, zone sets, and aliases without performing a topology match. You can bypass topology validation and restore configuration data on a new switch that can have a new SAS address. You can use this feature if the whole topology is not online and you can use it with only a switch without powering up other devices.

  • Page 75: Chapter 4: Sas Domain Manager Command Line Interface

    Use the up and down arrow keys to access a small command history buffer. Move the cursor with the left arrow key and right arrow key to edit commands. To start SDM-CLI, open a telnet session or an SSH session to the IP address or host name of the LSISAS6160 switch. Log in when you see the prompt.

  • Page 76: Help Command

    LSISAS6160 SAS Switch User Guide February 2014 SDM-CLI Commands 4.2.1 Help Command (Extra-Domain) Use the help command to display the SDM-CLI command line help. Authority: User Syntax: help [<command>] Usage: help [<command>]  Displays detailed help for a specific command if you provide the [<command>] name. Otherwise, it displays a list of all available commands.

  • Page 77: Device Command

    Deletes all aliases. If you specify the [noconfirm] option, the deletion occurs immediately without an additional confirmation prompt. Otherwise, SDM first prompts you to confirm the action. 4.2.5 Device Command (Intra-Domain) Use the device command to manage individual devices (LSI expanders) within the domain. Authority: Admin Syntax: device (<sas address>|<alias>) reset [noconfirm] device (<sas address>|<alias>):<phy>...

  • Page 78: Show Command

    Rescans the SES data, rescans the phy error counters, or both. device (<sas address>|<alias>) ip (dhcp|static <ip address> <mask> <gateway>)  Configures TCP/IP address and other TCP/IP settings for LSI switches and LSI expanders. 4.2.6 Show Command (Intra-Domain) Use the show command to display domain, device, and phy information. (See Section 4.3, Sample...

  • Page 79: Zonegroup Command

    LSISAS6160 SAS Switch User Guide February 2014 SDM-CLI Commands show zoneset  Displays a list of all zone sets. show zoneset active  Displays the name and detailed information for the active zone set. show zoneset data <name>  Displays detailed information about a single zone set.

  • Page 80: Zoneset Command

    LSISAS6160 SAS Switch User Guide February 2014 SDM-CLI Commands 4.2.8 Zoneset Command (Intra-Domain) Use the zoneset command to manage zone sets and zone set membership. Before you can activate zoning, you must use the zoneset passwd command to synchronize the zone manager password of all the zoning expanders and switches on the domain.

  • Page 81: Ses Threshold

    LSISAS6160 SAS Switch User Guide February 2014 SDM-CLI Commands zoneset delete all [noconfirm]  Deletes all zone sets. If you specify the [noconfirm] option, the action occurs immediately without an additional confirmation prompt. Otherwise, SDM first prompts you to confirm the action.

  • Page 82: Set Date

    LSISAS6160 SAS Switch User Guide February 2014 SDM-CLI Commands Usage: show device ({SAS address} | {alias}) date  Shows the device date in DAY YYYY-MM-DDThh:mm:ss format. For example, SUN 2011-11-28T23:56:55. 4.2.11 Set Date (Intra-Domain) Use the date command to set the switch date.

  • Page 83: Get Snmp

    LSISAS6160 SAS Switch User Guide February 2014 SDM-CLI Commands 4.2.13 Get SNMP (Intra-Domain) Use the snmp command to show the SNMP configuration. Authority: User Syntax: show device <sas-address|alias> snmp agentsecurity show device <sas-address|alias> snmp systemmib Usage: show device <sas-address|alias> snmp agentsecurity ...

  • Page 84: Get Smtp

    LSISAS6160 SAS Switch User Guide February 2014 SDM-CLI Commands 4.2.15 Get SMTP (Intra-Domain) Use the smtp command to show the SMTP configuration. Authority: User Syntax: show device (<sas_address> | <alias>) smtp outputconfig show device (<sas_address> | <alias>) smtp serverconfig show device (<sas_address> | <alias>) smtp email show device (<sas_address>...

  • Page 85: Configuration Backup

    LSISAS6160 SAS Switch User Guide February 2014 SDM-CLI Commands 4.2.17 Configuration Backup (Extra-Domain) Use the backup command to backup settings. See Section 3.8, Configuration Backup and Restore, for more information. Authority: Admin Syntax: config backup <file name> config backup <file name> <ip-address>...

  • Page 86: Display Sdm Event Log

    LSISAS6160 SAS Switch User Guide February 2014 Sample Output for Show Command 4.2.20 Display SDM Event Log (Intra-Domain) Use the log command to get the device log. Authority:User Syntax: show log show <domain id> log show <domain id> log (<failed|<critical>|<optimal>)

  • Page 87: Show Device

    LSISAS6160 SAS Switch User Guide February 2014 Sample Output for Show Command 4.3.3 show device SDMCLI> show device NOTE In the following example, ZExpander means zoning capable expander. Device Parent ================================================ ================================ Alias / Alias / Type Phys SAS Address...

  • Page 88: Show Device

    LSISAS6160 SAS Switch User Guide February 2014 Sample Output for Show Command 4.3.4 show device <alias> NOTE A Device Type of ZExpander means zoning capable expander. SDMCLI> show device Calhoun =============================================== Domain Device Information =============================================== Company Name: Astek Corporation SAS Address: 50012be0000380ff...

  • Page 89: Show Domain

    LSISAS6160 SAS Switch User Guide February 2014 Sample Output for Show Command 4.3.5 show domain SDMCLI> show domain Overlay Name Domain Access Point ---------------------------- --- --------------------------------------------- (Domain) SAS6160 (500062b10000417f) Note: (Name) denotes focused domain [Name] denotes domain overlays currently not bound to a physical domain 4.3.6...

  • Page 90: Show Phy

    LSISAS6160 SAS Switch User Guide February 2014 Sample Output for Show Command Tchoupitoulas ---------------- --- None 000000000 Tchoupitoulas ---------------- --- None 000000000 Tchoupitoulas ---------------- --- None 000000000 Tchoupitoulas ---------------- --- None 000000000 Tchoupitoulas ---------------- --- None 000000000 Tchoupitoulas ---------------- ---...
  • Page 91 LSISAS6160 SAS Switch User Guide February 2014 Sample Output for Show Command Enabled 5000c500176a867d 000000010 Enabled 5000c5001769ed95 000000010 Enabled 5000c500176d141d 000000010 Enabled 5000c500176cb319 000000010 Enabled ---------------- None 000000000 Enabled ---------------- None 000000000 Enabled ---------------- None 000000000 Enabled ---------------- None 000000000...

  • Page 92: Show Phy :

    LSISAS6160 SAS Switch User Guide February 2014 Sample Output for Show Command 4.3.8 show phy <alias>: <phy> SDMCLI> show phy Lincoln:01 =============================================== Phy Information =============================================== SAS Address: 500605b0000282bf Phy Identifier: 01 State: Enabled Link Speed: 6.0 Gb/s Virtual Phy: No Routing Attribute: Subtractive Minimum Link Speed: 1.5 Gb/s...

  • Page 93: Show Zonegroup

    LSISAS6160 SAS Switch User Guide February 2014 Sample Output for Show Command 4.3.10 show zonegroup <name> SDMCLI> show zonegroup ZoneOne#001 Zone Group Member Alias/SAS Address: Phy List -------------------------------------- ZoneOne#001: Lincoln : 00 01 02 03 4.3.11 show zoneset active SDMCLI> show zoneset active...

  • Page 94: Chapter 5: Troubleshooting

    LSISAS6160 SAS Switch User Guide February 2014 Chapter 5: Troubleshooting The following table lists several troubleshooting issues related to the LSISAS6160 switch and the remedies for them. Table 5 Common Troubleshooting Issues and Remedies Issue Remedy The password for the admin account is lost and you cannot access Reset the switch to factory defaults by pressing the reset switch and the switch-management capabilities.
