SHINDAIWA OWNER'S/OPERATOR'S MANUAL
DH232 HEDGE TRIMMER
WARNING!
Minimize the risk of injury to yourself and others! Read this manual and
familiarize yourself with the contents. Always wear eye and hearing
protection when operating this unit.

Advertisement

Table of Contents
loading

Related Manuals for Shindaiwa DH232

Summary of Contents for Shindaiwa DH232

  • Page 1 SHINDAIWA OWNER’S/OPERATOR’S MANUAL DH232 HEDGE TRIMMER WARNING! Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye and hearing protection when operating this unit. X7702242500 12/14...

  • Page 2: Table Of Contents

    Beware of high temperature areas. force in your area. If you have questions regarding your DH232 hedge trimmer, or if you do not understand something in this manual, your Shindaiwa dealer will be glad Wear eyes,ears and to assist you. You may also contact head protection.

  • Page 3: General Safety Instructions

    To reduce the risk of serious or fatal injury, persons with pacemakers should consult with their physician and the pacemaker manufacturer before operating this machine. In the absence of such information, ECHO does not recommend the use of Shindaiwa products by anyone who has a pacemaker.
  • Page 4 When transporting the hedge lead to personal injury trash or hidden debris to help ■ trimmer in a vehicle, tie it down Always use genuine Shindaiwa ensure good footing. securely to prevent fuel spillage or parts and accessories when ■...

  • Page 5: Safety Equipment And Labels

    1063 x 272 x 195 mm (41.9 x 10.7 x 7.7 in) Fuel Tank Capacity 0.37 liter (12.5 oz.) Fuel/Oil Ratio 50:1 Shindaiwa Red Armor® ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD, two-stroke, air-cooled engine oil. Carburetor Diaphragm type Ignition...

  • Page 6: Emission Control

    Emission Control (Exhaust & Evaporative) EPA 2010 and Later and/or C.A.R.B. TIER III The emission control system for the engine is EM (engine modification) and, if the second to last character of the Engine Family on the Emission Control Information label (sample below) is “C”, “K”, or “T”, the emission control system is EM and TWC (3-way catalyst).

  • Page 7: Mixing Fuel

    2-Stroke Oil is strongly recommended as it meets this standard and is specifically formulated for use in all Shindaiwa 2-stroke engines. Engine problems due to inadequate lubrication caused by failure to use an ISO-L- EGD (ISO/CD 13738) and J.A.S.O. M345/FD certified oil will void the engine warranty.

  • Page 8: Filling The Fuel Tank

    IMPORTANT! Spilled fuel is a leading cause of hydrocarbon emissions. Some states may require the use of automatic fuel shut-off containers to reduce fuel spillage. After use • DO NOT store a unit with fuel in its tank. Leaks can occur. Return unused fuel to an approved fuel storage contain- Storage - Fuel storage laws vary by locality.

  • Page 9: Starting Procedure

    Starting Procedure IMPORTANT! Engine ignition is controlled by a two-position on-off switch mounted on the throttle body. This switch is typically labeled “I” for ON and “O” for OFF. WARNING! The attachment will operate immediately when the engine starts and could result in loss of control and possible serious injury.

  • Page 10: Operation

    2. Move the ignition switch to the “O” or STOP position. See Figure 8. WARNING! If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your Shindaiwa dealer repair stop switch before using hedge trimmer again. Ignition...

  • Page 11: Maintenance And Adjustments

    NOTE: Using non-standard replacement parts could invalidate your Shindaiwa warranty. WARNING! WARNING!
