SHINDAIWA OWNER'S/OPERATOR'S MANUAL
M2510 MULTIPURPOSE
TOOL CARRIER
Read this manual and the manuals provided with the Shindaiwa Splitboom
Attachment series and familiarize yourself with its contents.
Do not operate or service this machine unless you clearly understand this manual.
This machine is designed for cutting branches, grass, weeds and brush. Use only
for designated purpose.
WARNING!
Minimize the risk of injury to yourself and others.
Always wear eye protection and a safety helmet when operating this machine.
Keep this manual available at all times so that you can reference it whenever you
have a question about the use of this unit.
Part Number 65040-94310 Rev. 2/08

Advertisement

Table of Contents
loading

Related Manuals for Shindaiwa M2510

Summary of Contents for Shindaiwa M2510

  • Page 1 SHINDAIWA OWNER’S/OPERATOR’S MANUAL M2510 MULTIPURPOSE TOOL CARRIER Read this manual and the manuals provided with the Shindaiwa Splitboom Attachment series and familiarize yourself with its contents. Do not operate or service this machine unless you clearly understand this manual. This machine is designed for cutting branches, grass, weeds and brush. Use only for designated purpose.

  • Page 2: Table Of Contents

    IMPORTANT! drugs, medication or any other substance that could affect your A statement preceded by the word Shindaiwa Inc. reserves the right to make ability or judgement. “IMPORTANT” is one that possesses changes to products without prior notice, special significance.

  • Page 3: Safety Instructions

    Shindaiwa for use on this unit. Stay Alert cation or any other substance that could affect your ability or judgement.

  • Page 4: Product Description

    Outer Tube Shoulder Strap Figure 2 Fuel tank capacity ..............600 cm Engine Name ..............M2510/EC2 Engine model................SF2510EC2 Fuel/oil ratio ..........50:1 with ISO-L-EGD or JASO FC class 2-cycle mixing oil* Engine type ........ .4-cycle, vertical cylinder, air cooled Dry weight (less attachments) ..........4.3 kg Carburetor .........

  • Page 5: Assembly

    Strap Installing a Tool Attachment Place the M2510 Multipurpose Tool Car- Latch protector (extended) Tube assembly rier and the Tool Assembly on a clean, flat surface so that both assemblies fit end to end.

  • Page 6: Mixing Fuel

    Shindaiwa engine. is a registered JASO FC clas- sified oil and also meets or exceeds ISO-L-EGD performance requirements. Shindaiwa One is recommended for use in all Shindaiwa low emissions engines. Shindaiwa One also includes a fuel stabilizer. Filling the Fuel Tank WARNING! Place the unit on a flat, level surface.

  • Page 7: Starting The Engine

    Starting the Engine WARNING! WARNING! WARNING! Never start the engine with- The cutting attachment may Never start the engine from out the tool assembly and cutting rotate when the engine is started! the operating position. attachments installed to the engine. Failure to do so could damage the engine and increase unexpected risk to the operator and any bystander.

  • Page 8: Stopping The Engine

    If the attachment rotates when the return the unitmachine to your engine is at idle, reduce the idle speed Shindaiwa dealer for inspection. by turning the idle adjustment screw counter-clockwise. See Figure 12. If a tachometer is available, the engine idle Figure 12 speed should be final adjusted to 3,000...

  • Page 9: Maintenance

    BE PERFORMED BY A DEALER OR maintenance work. SERVICE CENTER AUTHORIZED BY Spark Plug SHINDAIWA CORPORATION AND USE OF PARTS THAT ARE NOT EQUIVA- Keep the spark plug and wire connections WARNING! LENT IN PERFORMANCE AND DURA- tight and clean.
  • Page 10 filter from inside the fuel tank. See Fig- is noted, the unit should be removed ure 18. Remove and replace the filter from service until it can be inspected element. or repaired by a Shindaiwa-trained ser- Hooked vice technician. Wire CAUTION! Make sure you do not pierce the fuel line with the end of the hooked wire.

  • Page 11: Long Term Storage

    Combustion chamber should be decar- Cover bonized, and the valve clearance should be adjusted. It is highly recommended that this is done by a Shindaiwa-trained service technician. Replace the spark plug annually: Use only NGK CMR5H or equivalent resis- tor type spark plug of the correct heat range.

  • Page 12: Troubleshooting Guide

    Fuel incorrect, stale, or a pump octane of 87 or higher mixed with 50:1 grade? contaminated; mixture incorrect. Shindaiwa Premium 2-cycle mixing oil or with an equivalent high quality 2-cycle mixing oil. Is fuel visible and moving in the return Check for clogged fuel filter and/...
  • Page 13 Troubleshooting Guide (continued) LOW POWER What To Check Possible Cause Remedy Operator is overworking the unit. Cut at slower rate. Is the engine Carburetor mixture is too lean. Consult with an authorized servicing overheating? dealer. Improper fuel ratio. Refill with clean fresh unleaded gasoline with a pump octane of 87 or higher, mixed with Premium 2-cycle mixing oil at a 50:1 gasoline/oil ratio.
  • Page 14 Troubleshooting Guide (continued) ADDITIONAL PROBLEMS What To Check Possible Cause Remedy Clogged air filter. Clean or replace the air filter. Clogged fuel filter. Replace the fuel filter. Poor acceleration. Lean fuel/air mixture. Consult with an authorized servicing dealer. Idle speed set too low. Adjust: 3,000 (±300) min Switch turned off.

  • Page 15: Declaration Of Conformity

    Declaration of Conformity No. 0104 DECLARATION CONFORMITY We hereby declare the Shindaiwa Pole Pruner, Model SBA-P24 (SBA-P24/EU with M2510/EC2), meets the following respective requirements. Council Directives: Standard taken: 2004/108/EC as amended ISO 12100 - 1&2 98/37/EC as amended ISO 11680 - 1...
  • Page 16 Declaration of Conformity No. 0102 DECLARATION CONFORMITY We hereby declare the Shindaiwa Brushcutter, Model SBA-TX24 (SBA-TX24/EU with M2510/EC2), meets the following respective requirements. Council Directives: Standard taken: 2004/108/EC as amended ISO 12100 - 1&2 98/37/EC as amended ISO 11806 2000/14/EC as amended...
  • Page 17 Declaration of Conformity No. 0103 DECLARATION CONFORMITY We hereby declare the Shindaiwa Articulated Hedge trimmer, Model SBA-AH2422 (SBA-AH2422/EU with M2510/EC2), meets the following respective requirements. Council Directives: Standard taken: 2004/108/EC as amended ISO 12100 - 1&2 98/37/EC as amended ISO 11680 - 1...
  • Page 18 Head Office: Part Number 65040-94310 Tualatin, Oregon 97062 6-2-11, Ozuka-Nishi Revision 2/08 Telephone: 503 692-3070 Asaminami-Ku, Hiroshima Shindaiwa is a registered trademark of Shindaiwa, Inc. Fax: 503 692-6696 731-3167, Japan Specifications subject to change without notice. www.shindaiwa.com Telephone: 81-82-849-2220 Fax:...
